Computer Mount - Labconco Logic Vue User Manual

Computer Mount

All Logic Vue models include a mounting point for a computer arm to support computer-
driven automated instruments. The mounting point is designed to accept most
TM
Ergotron wall-mount arms.
The following tools and supplies are required to install the Airflow Sensor Kit:
• 3/16" Allen Wrench
Hex Head
Mounting Bolts
Step #1
To attach an arm, remove the (2) hex-head bolts from the inside lower left of the Logic
Vue's front side (reference Figure 12-11 above).
Step #2
Attach the computer arm (supplied in kit 3339000 or other customer-supplied
TM
Ergotron product) and secure to the Logic Vue with the provided fasteners before
attaching peripherals (monitors, keyboards, etc.). For more information about
compatible arms, contact Labconco.
Kit
TM
Ergotron PC Mount
155
Table 12-3
Catalog Number
3339000
Figure 12-11
PRIMARY
SERIAL TAG
SECONDARY
SERIAL TAG
