Navigating the Settings Submenu

Keypad button presses are shown as
selections are shown as
This submenu allows you to select:
Measure, System Lock, or

Selecting the Units of Measure

If your enclosure is equipped with an airflow sensor,
the units of measure can be set for
minute) or M/S (meters per second). Select the
appropriate units of measure, then [OK/Mute].

Activating the Security Lock

The Security Lock "locks" the keypad to prevent
unauthorized use of the enclosure. To enable /
disable select Protected
[OK/MUTE]. When enabled, the keypad is locked
immediately after the blowers are turned off. The
security lock is deactivated by holding
three seconds. If blowers are not turned on within 5
minutes of unlocking, the keypad will relock.
The feature remains enabled until it is disabled in this screen.

Setting the USB Output Rate

This menu option selects the rate that enclosure
status data is exported out of the mini USB port on
the side of the top electrical box. Data can output at
a rate of once per second,
once per 30 seconds, or
Make the appropriate selection, then [OK/MUTE].
[BLUE WITH
green italics.
Units of
Data Output.
Units of Measure
System Lock
Data Output
FT/MIN (feet per
/ Unprotected, then
[DOWN]
once per 10 seconds,
once per 60 seconds.
78
BRACKETS]. Menu screen
Figure 6-13
Figure 6-14
METRIC (M/S)
IMPERIAL (FT/MIN)
Figure 6-15
PASSWORD
for
Figure 6-16
OUTPUT DATA
1 / SECOND
1 / 10 SECONDS
1 / 30 SECONDS
1 / 60 SECONDS
