Step 6 – Exhaust Guard Removal
Reference Figure 4-14. Remove the Screws underneath the Exhaust Guard. Remove
the Exhaust Guard.
The Logic Vue is now prepared to move through a narrow doorway. Once through,
reassemble the parts in the reverse order.
Figure 4-14
Before moving the Logic Vue through a narrow
doorway, temporarily remove this wire connector by
squeezing the two connector tabs and push the
connector back through the wall. Reinsert the
connector after the product is through the doorway.
38
EXHAUST
GUARD
SCREWS
