TM
6: MyLogic
The Logic Vue enclosure features the MyLogic operating system, which provides clear
status information on the LCD display and user control with the keypad (Figure 6-3).
Read this section along with
features and controls of this product.

Home Screen

The Home Screen will display the following information (Figure 6-1).
Filter Life
Remaining
Light Status
Current Time
When the sashes are closed, the blower icon may change as follows:
Operating System
Section 10: Using Your Logic Vue
100%
12:39 PM
Airflow Sensor Current
Reading (optional)
Figure 6-1
50
80
Blower Status = Reduced Speed
(NightSmart Enabled)
72
to fully understand the
Filter Life Bar
Blower Status
