4: Installation & Certification
With the installation site properly prepared, you are ready to unpack and install the
equipment. This section covers how to:
• Unpack and move the product
• Install the product
• Connect electrical service
• Connect service utilities (if accessory service fixtures are installed)
• Connect to an exhaust system (optional)
• Arrange certification for the product
This product is extremely heavy. Use a forklift or the included scissor jack to
raise/lower the product to remove from shipping pallet and/or install levelling feet.

Unpacking

The following tools are required to unpack the equipment:
• Box knife
• Flatblade screwdriver
• #2 Phillips screwdriver (Cordless Drill and Phillips bit recommended)
• 5/16", 7/16", 1/2", 3/4", and 7/8" wrenches (socket set and ratchet recommended)
• Hammer and Crowbar (to remove skeletal crating)
• Carpenter's level
The following safety precautions must be followed by all personnel unpacking the
equipment.
• Two (2) persons minimum required for unpacking
• Wear safety glasses and protective gloves
• No loose fitting clothes
• Wear close-toed shoes
• Follow safe-lifting practices (do NOT attempt to lift this product without
specialized lifting equipment certified to lift up to 2000 lbs.)
