Figure 4-26
Acceptance Criteria
Aerosol penetration shall not exceed 0.01%.
Reinstall the diffuser. Make sure the slots in the diffuser flange are oriented to the front
of the Logic Vue.
Reinstall the pre-filter and pre-filter brackets. Close the Front Hatch.
57
