Congratulations on your purchase of a Labconco CentriVap Concentrator System. Models are available for operation on 115V or 230V. The CentriVap Concentrator, when combined with the CentriVap Cold Trap, uses centrifugal force with heat and vacuum to rapidly evaporate and condense solvents from biological and analytical samples.
Chapter 1: Introduction As the companion to the Concentrator, the CentriVap Cold Trap protects the vacuum pump by trapping moisture, vapors and corrosive fumes as they evaporate from the samples. The CFC free refrigeration system reduce the temperature of the Cold Trap to –55°C. The stainless steel trap is used for aqueous and organic applications.
Chapter 1: Introduction Chapter 7: Troubleshooting contains a table of problems you may encounter while using your CentriVap, including the probable causes of the problems, and suggested corrective actions. Appendix A: CentriVap Components contains labeled diagrams of the components of the CentriVap. Appendix B: CentriVap Dimensions contains comprehensive diagrams showing the dimensions for the CentriVap.
Chapter 1: Introduction Your Next Step If your CentriVap needs to be installed, proceed to Chapter 2: Prerequisites to ensure your installation site meets all of the requirements. Then, go to Chapter 3: Getting Started for instructions on how to install your CentriVap and make all of the necessary connections.
Page 9
Before you install your CentriVap, you need to prepare your site for installation. Carefully examine the location where you intend to install your CentriVap. You must be certain that the area is level and of solid construction. In addition, an exhaust means must be provided.
Chapter 2: Prerequisites Electrical Requirements The CentriVap Concentrator requires a dedicated grounded electrical outlet. This outlet requires a 15 Amp circuit breaker or fuse for models rated at 115V (60 Hz). An 8 Amp circuit breaker or fuse is required for models rated at 230V (50/60 Hz).
Chapter 2: Prerequisites Vacuum Pump Requirements A vacuum pump must be provided by the user. A vacuum pump with a free air flow rate of 113 liters per minute and 0.2 x 10 mbar blank off pressure is adequate for aqueous samples. More volatile samples can be satisfactorily processed using a diaphragm pump with a free airflow of 42 liters per minute and 200 mbar vacuum.
CentriVap are made from stainless steel or aluminum and can be degraded if exposed to acids. Before evaporating acids, be sure to contact Labconco. A moisture trap, solvent trap and radioisotope trap are also available. Refer to Appendix D: CentriVap Accessories for ordering information.
Page 13
Now that the site for your CentriVap is properly prepared, you are ready to unpack, inspect, install, and test your CentriVap. Read this chapter to learn how to: • unpack and move your CentriVap. • set up your CentriVap. • connect the electrical supply source to your CentriVap.
(15) days of delivery. DO NOT RETURN GOODS WITHOUT THE PRIOR AUTHORIZATION OF LABCONCO. UNAUTHORIZED RETURNS WILL NOT BE ACCEPTED. IF YOUR CENTRIVAP WAS DAMAGED IN TRANSIT, YOU MUST FILE A CLAIM DIRECTLY WITH THE FREIGHT CARRIER.
Page 15
Chapter 3: Getting Started Concentrator Catalog # Product Description 78100-00 CentriVap Concentrator – 115V 78100-10 CentriVap Concentrator – 230V 78100-02 CentriVap Concentrator with Heat Boost – 115V 78100-03 CentriVap Concentrator with Heat Boost – 230V Plus the Following: Part # Component Description 74614-00 User’s Manual...
Page 16
Chapter 3: Getting Started Systems Catalog # Product Description 79820-00 Aqueous System – 115V 79820-01 Aqueous System – 230V Plus the Following: Part # Component Description 78100-00 CentriVap Concentrator – 115V 78100-01 CentriVap Concentrator – 230V 78110-00 CentriVap Cold Trap – 115V 78110-01 CentriVap Cold Trap –...
Chapter 3: Getting Started If you do not receive one or more of the components listed for your CentriVap, or if any of the components are damaged, contact Labconco Corporation immediately for further instructions. Setting Up Your CentriVap After you verify receipt of the proper components, move your CentriVap to the level and sturdy location where you want to install it.
Page 18
Chapter 3: Getting Started wall surfaces. Restriction of the airflow through the cabinet during operation could adversely affect performance. Secondary Trap Vacuum Pump Cold Trap Concentrator After positioning the components, it is necessary to join the system together using the hoses provided. Attach one hose to the .50 diameter tube that extends out the back of the Concentrator.
Chapter 3: Getting Started Secondary Trap. Clamp securely. Attach another hose from the remaining connector on the Secondary Trap to the inlet port on the vacuum pump and clamp securely. Exhaust Port If the CentriVap is not located in a fume hood, attach one end of a user supplied hose to the exhaust port on the vacuum pump.
Chapter 3: Getting Started Ground Wire Attach one end of the included ground wire to the stainless steel elbow on the drain tubing on the left side of the Cold Trap. When draining the CentriVap Cold Trap always attach the other end of the grounding clip to the solvent catch pot to eliminate the risk of electrostatic spark ignition.
Page 21
Use care when using aggressive liquids which can damage the CentriVap and thoroughly clean the CentriVap after each use. Contact Labconco before evaporating acids. WARNING: The disposal of substances used in connection with this equipment may be governed by various Federal, State or local regulations.
Chapter 3: Getting Started Your Next Step The installation and setup of your CentriVap is now complete. To learn how to load and operate your CentriVap, proceed to Chapter 4: Using Your CentriVap. To make a modification to the configuration of your CentriVap, proceed to Chapter 6: Modifying your CentriVap.
Page 23
After your CentriVap has been installed as detailed in Chapter 3: Getting Started, you are ready to begin using your CentriVap. Read this chapter to learn how • set operating parameters. • operate the controls. • properly select and position glassware inside your CentriVap.
Chapter 4: Using Your CentriVap Planning Thoroughly understand procedures and the equipment operation prior to beginning work. The unique performance of the CentriVap is dependent upon the proper balance of heat, vacuum and centrifugal force. If the proper balance is not established, it is possible to damage or lose a portion of the sample.
Chapter 4: Using Your CentriVap As a general guideline, to speed the evaporation process, the CentriVap temperature should be set as high as possible as long as the temperature will not damage the sample or cause the sample to bump. Time Setting Guidelines The CentriVap Concentrator has two timers.
Chapter 4: Using Your CentriVap CentriVap Controls The control panel for the CentriVap is shown below with a description about its function. 1. Display – The liquid crystal display (LCD) shows set point parameters and actual measured conditions. 2. Program Buttons – Used to initiate the start of a run with the use of just one button.
Chapter 4: Using Your CentriVap Operating The CentriVap Controls Preheat: To preheat the chamber, press the “PREHEAT” button. The display will show: XXX ACT: XXX Press the increase or decrease button until the desired set point (SP) is displayed. The actual chamber temperature, (ACT) is displayed to the right.
Chapter 4: Using Your CentriVap Change heat set point: To change the heat set point, press the set point “SELECT” button until arrows point to the temperature set point which can be changed from -- (OFF) up to 99° by pressing the increase or decrease buttons. The set point is 100°C if the display shows “HI.”...
Chapter 4: Using Your CentriVap Do not operate the CentriVap if the lid is scratched of nicked, or shows signs of damage. Never lean on the CentriVap when it is operating. 1. Press the Cold Trap “ON” switch. The “READY” indicator will illuminate when it reaches operating temperature.
Chapter 4: Using Your CentriVap Depending on which solvent is used, the volume of the sample and the system operating parameters, the Cold Trap may warm up sufficiently to cause the “READY” indicator to turn off. As the sample reaches completion, the load on the Cold Trap will decrease and its temperature will decrease.
Page 31
Under normal operation, the CentriVap requires little maintenance. The following maintenance schedule is recommended: As needed: 1. Clean up all spills; remove liquids from the chamber. Clean or decontaminate all surfaces using agents suitable for the substance spilled. 2. Clean lid and gasket using soft cloth, sponge or chamois and a mild, non-abrasive soap or detergent.
Chapter 5: Maintaining Your CentriVap IF THE ICE HAS MELTED, THE GLASS TRAP INSERT MUST BE EMPTIED BEFORE THE COLD TRAP IS STARTED AGAIN. 7. If the Glass Trap is used, check to see that the ethanol in the stainless steel trap is free of ice or water.
The configuration of your CentriVap can be changed to accommodate your needs. If the solvents used in the CentriVap degrade the acrylic lid it may be replaced with an optional glass lid to gain added chemical resistance. You may wish to add a secondary trap to trap vapors exhausted from the vacuum pump.
Chapter 6: Modifying Your CentriVap Installing a Secondary Chemical Trap An accessory secondary chemical trap is available to minimize the exhausting of solvents into the atmosphere. It may be attached to either side of the Cold Trap. After selecting the side, remove the two small plastic hole plugs.
Page 35
THIS RADIOCHEMICAL CARTRIDGE DOES NOT MEET NRC FILTER DESIGN RECOMMENDATIONS. AFTER OPERATING, PROPERLY DISPOSE OF ALL HAZARDOUS MATERIALS IN COMPLIANCE WITH ALL APPLICABLE CODES. LABCONCO IS NOT RESPONSIBLE FOR IMPROPER DISPOSAL OF ANY MATERIALS. Product Service Domestic 1-800-522-7658, International 816-333-8811...
Chapter 6: Modifying Your CentriVap Installing a CentriZap™ Strobe Light An accessory strobe light is available to enable you to see the samples as they are rotating in the rotor. Attach the holder to the right hand side of the CentriVap Concentrator using the screws provided.
Chapter 6: Modifying Your (Product Name) Installing a Glass Trap in the Cold Trap An accessory Glass Trap is available for use in the Cold Trap for use when corrosive chemicals are used that could attack the stainless steel chamber of the Cold Trap.
Page 38
MEM FAIL P1 Memory failure Push program button #1 New memory IC chip Push program button #1. Bad memory IC chip Call Labconco – Replace IC chip or control PCB. MOTOR ERROR Defective motor Replace motor. Hall effect sensor Replace sensor.
Vent hose exhausting into Redirect hose to fume hood. Sample odor in lab area Heater inoperable Contact Labconco. Evaporation rate is reduced Vacuum pump failure Check pump. Obstruction in hose Remove obstruction or replace hose. Lack of adequate vacuum See below.
Page 40
Chapter 7: Troubleshooting PROBLEM CAUSE CORRECTIVE ACTION No vacuum Ice formed on Cold Trap Defrost and wipe dry. poor vacuum lid sealing surface (cont.) Secondary Trap Cannister Tighten all connections to and from the not fitted properly Secondary Trap Cannister. Secondary Trap Insert is Replace with new insert.
Page 41
The following pages list components that are available for your CentriVap. The parts shown are the most common replacement parts. If other parts are required, contact Product Service. Product Service Domestic 1-800-522-7658, International 816-333-8811...
Appendix C: CentriVap Specifications Environmental Conditions • Indoor use only. • Maximum altitude: 6562 feet (2000 meters). • Ambient temperature range: 41° to 104°F (5° to 40°C). • Maximum relative humidity: 80% for temperatures up to 88°F (31°C), decreasing linearly to 50% relative humidity at 104°F (40°C).
Page 53
Appendix C: CentriVap Specifications Wiring Diagram Concentrator (115V Model) Product Service Domestic 1-800-522-7658, International 816-333-8811...
Appendix C: CentriVap Specifications Evaporation Rates Methylene Chloride bp 40 Number Heater Time to Rate Tube Size Sample Temp Heat Vacuum Cold Overall (ml) Samples Size (ml) Boost Pump (min) Trap (ml/min) Diaphragm 3.75 Diaphragm 3.85 Diaphragm 4.00 Diaphragm 4.00 Toluene bp 111 Diaphragm...
Page 58
Appendix C: CentriVap Specifications Water bp 100 Number Heater Time to Rate Tube Size Sample Temp Heat Vacuum Cold Overall (ml) Samples Size (ml) Boost Pump (min) Trap (ml/min) Diaphragm 1397 0.21 Diaphragm 0.67 Diaphragm 0.70 Diaphragm 0.19 Diaphragm 0.30 Diaphragm 0.44 Diaphragm...
Page 59
The following accessories are available for the CentriVap Concentrator and Cold Trap System. PART # DESCRIPTION 74629-00 Rotor (DNA) Holds (72) 0.5 ml microcentrifuge tubes (60) 1.5 ml microcentrifuge tubes or (60) 2.0 ml microcentrifuge tubes 74507-00 Rotor (1.5 ml) Holds (132) 1.5 ml microcentrifuge tubes or (132) 2.0 ml microcentrifuge tubes 74550-00...
Appendix D: CentriVap Accessories PART # DESCRIPTION 74551-00 Rotor (12 mm) Holds (40) 1.5 ml microcentrifuge tubes or (40) 2.0 ml microcentrifuge tubes (16) 12 x 55 mm tubes or (100) 12 x 75 mm tubes or (64) 12 x 95 mm tubes or (100) 13 x 75 mm tubes or (64) 13 x 100 mm tubes 74552-00...
Page 61
Appendix D: CentriVap Accessories PART # DESCRIPTION 74643-00 Strobe Light – For observing samples while the rotor is spinning. 14721-00 Direct Drive Vacuum Pump – 117 liters/minute pumping capacity with gas ballast. Ultimate pressure 1.3 x 10 mBar. 115 VAC, 60 Hz, single phase, 4.6 amp 14677-00 Direct Drive Vacuum Pump –...
