– From the Home Screen, this button accesses the Main Menu. When in any
[MENU]
menu screen, pressing this button returns you to the previous menu level.
– Moves between selectable options or change numerical fields in
[UP] and [DOWN]
menu screens.

Blower Operation

The Logic Vue enclosure can be configured to automatically turn on the blowers. If this
feature is enabled, opening either sash from closed to operating height will
automatically turn on the blowers (or change back to nominal speed). If this feature is
not enabled, raise the sash to operating height, and press [BLOWER]. Either method
will start the blowers, and the Blower Starting screen will appear for approximately 1
minute.
If the enclosure is configured to operate with an optional canopy connection, and the
building's exhaust system is not pulling the required volume of exhaust air through the
canopy, the internal blower will still start while Blower Starting appears on the display. If
the building exhaust system does not reach the required minimum volume of airflow
within 90 seconds, an alarm will occur.

Light Operation

The Logic Vue enclosure provides dual LED lamps for illuminating the work surface. To
operate the lights, press [LIGHT].

Cable Pass Thru

The Cable Pass Thru allows for passage of a cord, cable, or tube from within the
product. A Cable Pass Thru is located on each end. Each pass thru contains eight (8)
pass thru ports, which are factory populated with solid plugs. Pass Thru Plugs are
available in 1 mm diameter increments from 1 mm to 17 mm.
The pass thru is a cable entry system from Icotek (icotek.com); frame series KEL-QTA.
Two 4-5mm size inserts (Labconco Catalog Number 3889311), which is Icotek Part
Number 42504, are supplied in the Parts Box.
Additional inserts for items 1 through 17 mm in diameter are available from Icotek.
Note: There must be enough clearance to pass the cord between the product's exterior
side panel and any obstruction such as a wall or other device.
Some Pass Thru components and the cord passing through it may become
contaminated during use of the enclosure. Ensure all potentially contaminated
components are surface decontaminated before handling or removal from the cabinet.
