Locate the Pallet Ramp and four (4) Screws removed earlier. Place the Pallet Ramp on
one end of the pallet as shown in Figure 4-5. The long chamfer on the Pallet Ramp
should rest against the floor. Secure the Ramp to the Pallet by re-using the four (4)
Screws that originally secured the Pallet Ramp in place for shipment. Run the four (4)
Screws through the provided holes in the Ramp's top flange.
Using at least two (2) persons, carefully and slowly roll the enclosure off the pallet and
down the ramp until it rests securely on the floor. Discard the shipping pallet, ramp, and
hardware. Keep the Scissor Jack and box with Levelling Feet.
28
Figure 4-5
SCREWS (4)
INTO PROVIDED
RAMP HOLES
PALLET RAMP
