12: Accessories

This section details the available factory or field-installable accessories and approved
modifications for your Logic Vue enclosure.

Canopy Connection

The Canopy Connection Kit allows for external exhausting of the enclosure's exhaust
airflow. The Kit catalog numbers are listed in Table 12-1 below. To field install the
Canopy Connection Kit, follow the instructions below.
The following tools and supplies are required to install the Canopy Connection Kit:
• #2 Phillips Screwdriver
To install a 12-inch diameter Balancing Damper (recommended, purchased
separately):
• 5/16" and 3/8" Socket and Ratchet
• RTV Silicone Tube (optional)
Cabinet Width (Feet)
4'
6'
Table 12-1
Canopy Kit
3347811
3347813
