11: Advanced Service Procedures

This section provides instructions to perform advanced service procedures on the
enclosure. Such procedures include changing HEPA filters, adjusting the sash position
sensors, and more.

Tools

Required
• #2 Phillips screwdriver or #2 Phillips bit (4 inches long minimum)
• Ratchet with extension
• Sockets
o 5/16-inch
o 3/8-inch
o 7/16-inch
o 1/2-inch
• 3/8-inch nut driver
• 1/2-inch nut driver
• T20 Torx Driver
Optional
• Cordless screwdriver/drill
• Cordless ratchet (low profile right angle impact driver)
• Pliers (standard and needle nose)
• #10-24 Tap
• 5/16-18 Tap
If a cordless screwdriver or drill is used to drive screws, reduce the torque setting to a
minimum to avoid stripping the screw head.
120
