Step #1
Remove the Screws around the perimeter of the Exhaust Diffuser, see Figure 1.
Step #2
Place the Canopy Connection over the Exhaust Cover and re-install the Screws
removed in Step #1 through the holes around the perimeter flange of the Canopy
Connection. See Figure 2.
EXHAUST COVER
CANOPY CONNECTION
CABLE CONNECTOR
SCREWS
INLET RELIEF VALVE
141
Figure 1
Figure 2
SCREWS
