Exhaust Connection

Certain applications such as working with odorous products or volatile toxic materials
will require the connection of the unit to an exhaust system.
Note: The canopy connection, also referred to as a thimble or air gap connection,
allows single or multiple enclosures to be connected to an exhaust system. During
operation, the exhaust system draws all of the enclosure's exhaust air, plus a volume of
room air (through the vent in the canopy) into the exhaust duct. Canopy connections
function as a "shock absorber" allowing the system to function properly during changes
in room air pressure.
For information on installing a canopy connection, go to Section 9: Accessories.
Note: If the research involves the use of toxic compounds or volatile materials, contact
the facility's EH&S team or Labconco to ensure that the enclosure and its exhaust
system are compatible with the materials you will be working with.
