Logic Vue Footnotes
Type and Model Identification
✓
The primary Serial Tag is located on the top, right end near the service panel for the electrical box. The
primary Serial Tag contains the following information:
•
Catalog (Model) Number
•
Serial Number
•
Electrical Information (Voltage, Amperage, Frequency, Phase)
✓
The secondary Serial Tag is located on the front (or bottom) edge of the Display Housing.
✓
The first two digits of the serial number are the year of production; the next two are the month. The next 5
digits are the sequence of production, and the letter following the serial number is the revision level of the
cabinet.
Downflow Test Specifications
✓
All objects must be removed from the work surface before measuring downflow.
Inflow Test Specifications
✓
All tests performed as described in the current NSF/ANSI Standard 49.
HEPA Filter Leak Test Specifications
✓
Based on mineral oil.
✓
For The Supply HEPA Filter:
o
Remove the prefilter, and place the generator on top of the unit, near the air intake.
✓
For The Supply HEPA Filter:
o
Place aerosol generator in the center of the work surface, pointing towards the front grille.
LED Lamp Specifications
✓
THIS PRODUCT USES DIRECT DRIVE T8 LED LAMPS INSTEAD OF FLUORESCENT LAMPS. THERE
IS NO BALLAST; LINE VOLTAGE IS SUPPLIED TO THE LAMP SOCKETS. DO NOT INSTALL
FLUORESCENT LAMPS! FOR REPLACEMENT LED LAMPS, CONTACT LABCONCO PRODUCT
SERVICE DEPARTMENT.
Canopy Data
✓
Canopy vacuum is measured at the exhaust transition sampling point, relative to atmosphere.
✓
DIM = Direct Inflow Meter
✓
Total Exhaust Volume required from remote (building) exhaust system.
✓
Measured as per ASHRAE methodology for measuring air volume in round ducts. These values are
approximations, as the calculated traverse volume value may vary depending on sampling location, exhaust
system, and methodology.
