1. Before entering the
shown (below). The enclosure's internal blower(s) will automatically shut off. If
the enclosure is connected to a remote exhaust system, stop all exhaust airflow
before proceeding. Once all airflow is removed, press [OK/MUTE].
AFS ZERO POINT
INTERNAL BLOWER WILL
SHUT OFF NOW. IF
CONNECTED TO EXHAUST
SYSTEM, STOP ALL
EXHAUST AIR FOR PROPER
ZERO POINT CALIBRATION
'OK' ONCE EXHAUST AIR REMOVED
2. The enclosure will display
the airflow sensor readings. When complete, the screen below is shown. At this
time, if the enclosure is connected to a remote exhaust system, restart the
remote exhaust now. Press [OK/MUTE].
3. Zero point calibration is now complete. The following screens will proceed
through setting the blower speed(s) as would normally be done if the standard
password had been entered (recalibration without resetting the zero point).
4. On the Exhaust
press [OK/MUTE].
See screen images on the following page.
Blower Speed
screen(s), the
[OK/MUTE]
Wait
for approximately 15 seconds while it samples
AFS ZERO POINT
IF CABINET CONNECTED TO
EXHAUST SYSTEM,
RESTART EXHAUST
SYSTEM NOW
'OK' WHEN EXHAUST AIR ON
Filter Life Selection
Zero Point Warning
AFS ZERO POINT
screen, make the appropriate selection, then
152
screen is
WAIT
