Step 4 – Set Work Surface Height
The enclosure must be in its final location before proceeding with this step.
The enclosure can be set with the Work Surface height from 31.5 inches (80 cm) to 37.5
inches (95 cm); in 1 inch (2.5 cm) increments. Identify the desired Work Surface height,
then follow these instructions.
Step 2 – Pallet Removal
Follow the instructions in in this section to utilize the included
Scissor Jack to raise one end of the enclosure (reference Figure 4-4) for jack
placement. Alternatively, a pallet jack can be utilized for this step.
The casters on the enclosure end that is NOT being raised must be chocked with a
board or otherwise secured BEFORE the Scissor Jack is used to raise one end of the
enclosure.
Remove the Lower End Panel (right and left end) by removing the four (4) Screws per
End Panel. Reference Figure 4-3.
Raise the enclosure a maximum of 2 inches (5 cm), then remove the four (4) Height
Adjustment Bolts & Nuts (reference Figure 4-3). Slide the Caster/Levelling Feet Frame
up/down as desired, then reinstall the Adjustment Bolts & Nuts. Lower the completed
end. Repeat this for the opposite end. If raising the enclosure more than 2 inches (5
cm), repeat this step in a maximum of 2 inch (5 cm) increments until the desire height is
achieved.
Securely tighten the four (4) Adjustment Bolts and Nuts on EACH end. Replace the
Lower End Panel and its screws.
