Programming manual
Once the event programming process is complete and the event is sent to the control panel,
the event programming values will be checked for errors.
If you want to generate an alarm (i.e. activate sounder/flashers and calls) when only two PIRs (DET1
and DET2) go into alarm status within a pre-set time.
•
T0000; timer 1 will activate when the "Zone alarm DET1" Start event activates for 30 seconds
•
T0001; timer 2 will activate when the start event of the "Zone alarm DET2" S activates for 30 seconds
•
Both conditions must occur together (AND)
•
Therefore, it is necessary to set the activation of the sounder/flasher and calls on the event configured in
this way.
•
If the programmable event activates an on-BUS sounder/flasher, associate its deactivation with an event.
If you wish to activate an output for 40 seconds when key 17 is used to arm partition 1, and to disarm
and the same output when the partition disarms.
•
T0000; associate timer 1 with the activation of the Start event of key 17 recognition
•
T0000; timer 1 with a 40 second timeout, "timer active with delay" option enabled
•
T0000; associate timer 1 with the restoral of the reset event of partition 1
•
Programmable event 1 must be programmed as:
•
Select the output you want to activate in concurrence with the programmable event
•
If the programmable event activates an on-BUS sounder/flasher, associate its deactivation with an event.
If you wish to receive a telephone call when a zone q, which belongs to partitions 1 and 2, is violated and
one of the two partitions is armed
The automation zone q always generates the zone alarm event (even when the partitions are disarmed).
However, the programmable event will occur only when the zone q is in alarm status and at least one of
the two partitions is armed.
•
Configure zone q as "automation" belonging to partitions 1 and 2
•
Remove all the outputs and phone calls associated with the "Alarm zone q" event
•
The programmable event must be programmed as "Alarm zone q" AND ("Partition 1 armed in away mode"
OR "Partition 2 armed in away mode"):
•
Associate the programmable event with the telephone call you wish to receive
If you wish to activate a telephone call after 3 consecutive wrong code entries (with a maximum of 120
seconds between each entry).
•
C0000; counter 1 will activate on activation of the "False code" Start event, with a count of 3, 120 second
autoreset time
•
The programmable event must be programmed as:
•
Associate the programmable event with the telephone call you wish to receive
If you wish to activate a telephone call and output when at least two detectors out of 5 go into alarm
status.
•
The programmable event must be programmed as ("Alarm zone 1" + "Alarm zone 2" + "Alarm zone 3" +
"Alarm zone 4" + "Alarm zone 5")>=2
( E0000 + E0001 + E0002 + E0003 + E0004 ) >= V0002
•
Associate the programmable event with the telephone call you wish to receive and the output you wish to
activate.
Programming events
T0000 AND T0001
T0000
E0010 AND ( E0790 OR E0791 )
C0000
EXAMPLES
63
