Programming manual
Key programming consists of setting the parameters of the keys and wireless keyfobs for user
access to the partitions protected by the Prime system.
Each key or wireless keyfob must be enrolled in order to allow it to operate on the system.
Enrolling keys
The enrolling procedure is carried out in this section, as follows:
Type-in Code (Installer) , PROGRAMMING Keys, Enroll
1. The readers present in the control panel configuration will be shown. Select the reader
you want to use for enrolling the keys, then press OK. If you select a reader simulated
by the Air2-BS200, a "W" will be shown at the end of the description.
2. Select the digital key you want to enroll and press OK. If you are using an nBy/S or
nBy/X reader all the LEDs will start to blink to indicate that it is ready to enroll the key.
3. The keypad will indicate the current description of the key concerned.
4. Hold the key in the vicinity of the reader and then move it away. In the case of a wire-
less keyfob, press simultaneously keys 3 and 4.
5. The keypad will emit a beep to confirm that the key has been successfully enrolled. If
you are using an nBy/S or nBy/X reader, the red LED will go On.
6. The key description will go directly to the next key automatically. This method (from
step 4.) allows you to enroll as many digital keys as the system requires.
7. Once you have completed the enrolling process, press
All the enrolled keys will immediately be enabled to operate the system.
Type-in Code (Installer), PROGRAMMING Keys, Delete key
This section allows you to delete enrolled digital keys from the system configuration. The
enrolled digital keys can be found in the list with the
1. Use keys
and
2. Press
to delete the selected key.
3. Press OK to confirm the operation and exit.
Through an appropriate section of the installer menu it is also possible to delete all the
enrolled keys at once. This section can be reached as follows:
Type in Code (Installer), PROGRAMMING Factory par., Only keysDefault
Type-in Code (Installer) , PROGRAMMING Keys, Enable/disable
This section allows you to enable/disable the digital keys. These operations are not
irreversible:
1. Use keys
and
2. Use keys
and
3. Press OK to confirm the operation and exit.
Programming keys
Programming keys
to select the enrolled digital keys you want to delete.
to select the key in question.
to enable/disable the key.
or
.
symbol.
10
Chapter
10-1
Via keypad
Note
DELETE KEYS
KEY
AUTHORIZATIONS
49
