Programming manual
If an event is programmed with the "Automatic dialer" option enabled, the "Message type" parameter
will identify messages from 420 to 484, that is, messages containing descriptions of the event types.
If this option is enabled, the system will configure an
optimal sequence of the messages for the activation/
restoral of the event.
Automatic dialer
It is however possible to choose different messages
from those available, but the option activated in this
way imposes a limited choice depending on the type of
event.
Option that adds the message corresponding to the
Send address
recorded address to the message sequence.
Message type
Message A Section for the selection of the messages.
Message B
Button to listen to the combined message.
The digital message associated with the occurrence of the event follows the protocols in
accordance with the following parameters:
This is the CONTACT-ID reporting format Class-Code
Class code
which corresponds to the event.
Event Code on This is the 2-character alphanumeric code, which
activation/ corresponds to the activation/restoral of the event
restoral sent the alarm receiving centre (ARC).
If the event is associated with calls using SIA protocol
or SIA-IP, this parameter allows you to program the
SIA protocol
event code in accordance with SIA standard by
selecting it from the list.
For zone and terminal events (alarm, tamper, bypass), the "CCC" field of the CONTACT-ID
protocol counts the number of hard terminals in accordance with the Hard terminals table (refer
to Appendix E, Screw Terminals).
An explanatory table of all the SIA codes is provided in the support manual for the installer
and programmer.
Shortcut on event
Exclusively via software, it is possible to program for each event the shortcut that will be
activated on the activation of the event itself.
These shortcuts function differently from those which can be activated by the user (refer to
Appendix A, Default programming) and allow the control panel to activate automatically
determined operations when the event occurs.
Click-on the Events button on the menu on the left, then from the "Programming section on
the right select the single event to be programmed.
The "Shortcut functions" section provides check boxes that allow the selection of the shortcut
and definition of the relative parameter:
Programming events
Table 12-3: Voice dialer parameters
Parameter
Table 12-4: Voice dialer parameters
Parameter
Software section Installer menu section
Events list,
Events, "Event type",
selected event, "event", Activation/
Voice dialer
Automatic dialer
Events, "Event type",
"event", Activation/
Restoral
Not available
Software section Installer menu section
Events, "Event type",
"event", Activation/
Events list,
Restoral
selected event,
Digital dialer
Note
Restoral, Options,
Send address
Message type
Message A
Message B
DIGITAL MESSAGE
Class code
Event code
SIA Codes
EVENT CODE
SIA CODES
12-1-2
Via software
