3-5-2
N° This identifies the number of the command in the table displayed.
Name This is the identification string of the command.
This is the telephone number which, during a call to the Nexus, will activate the
Telephone number
command.
This field associates the user code with the telephone number. The code determines
Access Codes
which partitions the telephone-number user can operate on.
This is the number that identifies the command option selected from the 30
Actions
commands programmed in the SMS Commands section.
If enabled, when the telephone number calls, the Nexus, after rejecting the call, will
carry out the command associated with the telephone number concerned.
Reject call
If disabled - when the telephone number calls, the Nexus will not reject the call but
will allow it to proceed in such a way that the control panel can activate (if duly
programmed) the dialer after the programmed number of rings.
This option, when activated, enables the selected number to receive SMS messages
diverted from the Nexus communicator which do not comply with the command-
Receive diverted SMS
activation format.
SMS "command" messages cannot be diverted.
3-5-3
22
• "STATUS" - for status inquiries relating to the Nexus, the user will receive an SMS text
indicating the:
•• device name and firmware revision
•• GSM network provider
•• GSM signal reception level
•• device tamper status
•• BUS status
•• Balance (remaining credit)
•• scenario active (if present)
• "EXC" (or "ESC"), to inhibit the control panel zones
• "INC", to activate the control panel zones
For the last two commands, the message text must be:
where:
- <xxxxxx> is the PIN of a control-panel user coded, followed by a blank space
- "EXC" (or "ESC" or "INC") is the command to be implemented on the zone, followed
by a space
- <zone description> is the name zone to be inhibited or activated
Caller ID commands
The "Programming - Caller ID commands" section allows you to program up to 200 telephone
numbers and the commands which will be implemented when each telephone number is
recognized by the control panel. If a voice call is received from a telephone number, the
command you select from those programmed in the "SMS Commands" section will be carried
out.
Table 3-12: Call command parameters
Parameter
SMS message texts
The "Programming - Text for SMS messages" section allows you to edit up to 50 SMS text
messages containing 80 alphanumeric characters each message. These messages can be
associated with the events by means of the "SMS number" option described in paragraph 12-
1 Programming single events.
In the section concerned, where SMS messages are listed in the column, you have the
following parameters for each message:
• N°, which Identifies the number of the SMS message.
• Text, editable field for the SMS text message. Also indicated is the number of characters
available.
<xxxxxx> EXC <zone description>
