RT9150E OPERATOR MANUAL

Operating Hours

Press the Settings submenu button in the Main menu and
then press the Operating hours button (1) (Figure 3-55) to
open the Operating Hours submenu.
Operating Hours Submenu
The operating hours are displayed below the symbols, e.g.
1,680 hours and 12 minutes for the telescoping mechanism
(3).
NOTE: The value below the Unlock telescopic section
symbol (6) (Figure 3-56) indicates how often the
cycle has been operated, e.g. 13,750 times.
Grove
OPERATING CONTROLS AND PROCEDURES
Item
1
2
3
4
5
6
7
8
9
10
FIGURE 3-56
Published 2-23-2017, Control # 644-00
Description
ECOS
Auxiliary systems:
Counterweight cylinders
Crane cab cylinder
Telescoping mechanism
Engine operation
Lift cylinder
Telescope locking system
Main hoist
Auxiliary hoist
Swing gear
Boom extension
1
FIGURE 3-55
3
3-59
