OPERATING CONTROLS AND PROCEDURES
position momentary rocker switch with integral indicator that,
when actuated, will override and prevent the RCL, for a
period of 30 minutes, from locking out the three craning
functions (boom down, telescope extend, and hoist up)
should an overload or two-block condition occur.
Overriding the RCL with this switch should only be done in
the case of an emergency or when servicing the boom.
The indicator in the override switch will illuminate red and the
RCL and A2B override indicators on the RCL display will
flash to indicate the switch has been activated. Upon
activation, all craning function movements are reduced to
15% of their normal maximum speeds.
The RCL override function is automatically cancelled after 30
minutes. The RCL override function can also be cancelled by
the operator by either pressing the RCL emergency override
switch a second time, by turning off the engine, or by turning
the crane function power switch off.
Refer to the RCL operator's manual for more information.
7649-36

ECOS Control Panel

The ECOS Control Panel (3) is located on the right side
console. Various menus are displayed on the ECOS display.
3-8
The individual buttons have a different function in each
menu. The display shows various indicators about the crane,
the engine, outriggers, boom, etc. Many crane functions are
also controlled by the ECOS system.
Refer to ECOS Control Unit, page 3-17 for detailed
descriptions and instructions.

Emergency Stop Switch

The Emergency Stop Switch (4) is located on the right center
console. Pressing this switch will shut down the engine.

Turntable Lock Pin Control Handle

The Turntable Lock Pin Control Handle (5) is located on the
lower right side console. The purpose of the turntable lock
pin is to lock the superstructure in position directly over the
front (0°) or rear (180°). Pull the handle out to disengage the
swing lock. Push it in to engage the lock, preventing the
superstructure from turning.

Accessory Outlet

The Accessory Outlet (6) is located on the right side console.
It provides an outlet for the operator to plug in a 12 vdc
accessory. This outlet should be used only for components
1 requiring 8 amps or less.

Diagnostic Connector

The electrical Diagnostic Connector (7) is located on the
right side console. It can be used for troubleshooting engine
faults and conditions.
The connector is designed to connect a laptop computer,
with appropriate cable and engine or electrical system
software, to the crane for diagnostic work.

Level Indicator

FIGURE 3-4 The Level Indicator (8) is located on the right side of the cab
below the right side console. The indicator provides the
operator with a visual aid in determining the level of the
crane. Refer to the Service Manual to determine the
accuracy and how to adjust the level indicator.
