Manitowoc Grove RT9150E Operator's Manual page 145

RT9150E OPERATOR MANUAL
Item Description
10 Entering values
11 RCL shutdown
12 Input confirmation
1
Either Item 2 or 5
Grove
OPERATING CONTROLS AND PROCEDURES
Graphic
Published 2-23-2017, Control # 644-00
Explanation
When Input mode is activated:
• To the right: increases the value
• To the left: reduces the value
Slow turning changes the value slowly.
Fast turning changes the value fast.
• On: Machine Shutdown, buzzer
sounds
Degree of utilisation about 100% or
an error exists.
• Off: No shutdown
Refer to RCL Shutdown, page 3-72.
The lamp (1) lights up.
In the Rigging mode submenu:
Press button once, rigging mode
monitoring submenu opens.
In the Rigging mode monitoring
submenu:
Press button once, rigging mode is
accepted, Monitoring submenu
opens, lamp (1) goes out.
3
3-71
