RT9150E OPERATOR MANUAL

RCL MAIN MENU

The Main menu shows symbols for further submenus and
symbols for current displays.

RCL Main Menu

1
2
7
XXXX-X
Item Description
Error Submenu,
1
page 3-101, F2
Settings
2 Submenu, page 3-
99, F4
Grove
OPERATING CONTROLS AND PROCEDURES
3
4
5
6
8
FIGURE 3-73
Graphic
1
1
2
Published 2-23-2017, Control # 644-00
Item
1 Error submenu, F2
2 Settings submenu, F4
3 Date/time display
4 Rigging mode submenu, F5
5 Lifting Capacity Tables submenu, F6
6 Monitoring submenu,F8
7 Serial number display
8 Program version display
Refer to the following table for a description of each item
listed above.
The error submenu is where you
access and acknowledge any errors
that are present.
Refer to Error Submenu, page 3-101.
Buttons/displays (1) associated with
buttons F1, F5, F6, F7 and F8 are only
1
shown if a service device is connected,
refer to Settings Submenu, page 3-99
1
for more information.
Button F2 (2) is used to change the
1
time and date.
Press the
1
values are accepted and displayed in
the main menu.
You can cancel the input at any time;
press the
values are changed.
Description
Explanation
button, the entered
button, none of the
