OPERATING CONTROLS AND PROCEDURES
Table 3-1Error Code Table
Error code
5 02 6
5 04 4
5 05 5
6 02 1
6 02 2
6 02 3
6 02 4
6 02 5
8 01 1
8 02 2
8 03 3
8 14 1
8 14 2
8 14 3
8 14 4
1
With working range limiter switched on.
3-104
Cause
Current load is greater than the lift
capacity, lower boom extension
function is disabled
Maximum permissible swing angle
exceeded
Minimum load value not reached
Fuse F1 blown
Fuse F2 blown
Fuse F3 blown
Fuse F11 blown
Fuse F12 blown
Rigging state not yet confirmed
RCL is overridden
Swing gear switched ON with RCL
code for working position 0°, 180° or
Free-on-wheels.
Maximum permissible overall height
1
exceeded .
Maximum permissible overall working
1
radius exceeded .
Maximum permissible overall swing
1
range exceeded .
Shutdown area of a monitored object
1
reached .
Published 2-23-2017, Control # 644-00
RT9150E OPERATOR MANUAL
Remedy
1. Raise the boom extension
2. Press Enter button once
3. If necessary, increase the working radius by lowering
the main boom.
Swing into a permissible working range.
When the main boom is set down, raise main boom and
acknowledge the error. Notify Crane Care if the error
cannot be acknowledged.
Replace blown fuse; refer to the Service Manual.
Confirming the rigging mode, Refer to Entering the
Rigging Mode, page 3-81.
Cancel the override; Refer to RCL Override, page 3-73.
Switch off the swing gear.
Retract or lower.
Raise or retract.
Swing into a permissible working range.
Move into a permissible working range.
