RT9150E OPERATOR MANUAL
Item Description
Swing gear brake
4
control indicator
Swing gear brake
5 control selector
button, F14
Grove
OPERATING CONTROLS AND PROCEDURES
Graphic
Published 2-23-2017, Control # 644-00
Explanation
(1) Brake pedal control: use swing
gear brake pedal to brake swing
movement
(2) Control lever control: control
lever in zero position brakes swing
movement. Swing gear brake
pedal is without function.
Swing gear must be off to switch
controls.
Swing gear must be switched off.
To select between the brake pedal or
control lever: Press F14 button once.
3
3-31
