RT9150E OPERATOR MANUAL
Lube Point
Item
Description

Boom

Telescope
130 Sections -
Lower Faces
Telescope
131 Sections -
Upper Faces
Boom Lubrication Procedure
Telescope Section 1
• Extend telescope section 1 to 100%.
• Using a brush or roller, apply grease to lower slide faces.
• Apply grease to the upper wear pads at fitting (item 131).
• Lubricate locking pins at fitting (item 132).
• Lock and unlock the section to distribute the grease.
• Extend section 1 to 50%
• Apply grease to the upper wear pads at fitting (item 131).
Fully retract section.
Telescope Section 2 - 5
• Extend telescope section 5 to 100% and telescope section 4 to approximately 25%.
• Using a brush or roller, apply grease to the lower slide faces.
• Apply grease to the upper wear pads at fitting (item 131).
• Lubricate locking pins at fitting (item 132).
• Raise the main boom to 15 degrees.
• Retract telescope section 4 to 0% and telescope section 5 to approximately 50%.
• Lock and unlock telescope section 5 several times to distribute the grease.
• Lower the main boom to 0 degrees. Do not lower less than 0 degrees.
• Extend telescope section 4 to approximately 75%.
• Apply grease to the upper wear pads at fitting (item 131)
• Raise the main boom to 15 degrees.
• Retract telescope sections 4 and 5 to 0%,
• Fully extend and retract telescope section 5 to distribute the grease.
• Lower the main boom to 0 degrees.
• Lubricate telescope sections 2, 3 and 4 in the same method.
Grove
Approved
Figure No.
Lubricant
Lubricant Grease
Figure 5-11
02310394
Lubricant Grease
Figure 5-11
02310394
Published 2-23-2017, Control # 644-00
Lube
Lube Interval
Capacity
Thoroughly
300 hours or 3 months
coat
Thoroughly
300 hours or 3 months
coat
LUBRICATION
Application
5 places by brush.
Refer to Boom
Lubrication Procedure.
10 places by brush.
Refer to Boom
Lubrication Procedure.
5
5-27
