Manitowoc Grove RT9150E Operator's Manual page 254

SET-UP AND INSTALLATION
Item
1 Clamp
2 Quick Release Pin
3 Pin Cylinder
4-20
3
Description
Published 2-23-2017, Control # 644-00
RT9150E OPERATOR MANUAL
4
2
1
Item
4 Lifting Lug
5 Outrigger Beam Assembly
6 Outrigger Box
6
5
FIGURE 4-21
Description
