Drive Train - Manitowoc Grove RT9150E Operator's Manual

RT9150E OPERATOR MANUAL
Lube Point
Item
Description

Drive Train

20a a. Engine
Crankcase
20b b. Filter
a. Transmission,
21a
Torque
Converter
21b
b. Filter
NOTE:
• Check fluid level with engine running at 800 rpm idle and the oil at 180° to 200°F (65° to 90°C). Do not attempt an oil level check
with cold oil. To bring the oil temperature to this range, it is necessary to either work the crane or stall the converter. Converter
stall should be accomplished by engaging shift lever in forward high range with the brakes applied and then accelerating the
engine to half or three-quarter throttle. Hold the stall until the required converter temperature is reached and stabilized.
Do not operate the converter at stall condition for longer than 30 seconds at one time. Shift to neutral for 15 seconds and repeat
the procedure until the desired temperature is reached. Excessive temperature, i.e, 250°F (120°C) maximum will cause damage
to transmission clutches, fluid, converter and seals.
• Drain and fill with the oil at 150° to 200°F (65° to 90°C).
• Transmission filters are located on the outside left hand frame in the area of the hydraulic oil cooler.
• Do not operate the machine in two wheel drive while the machine is up on outriggers. Serious transmission damage could result.
• To add fluid:
a. Fill to FULL mark on dipstick
b. Run engine at 800 rpm to prime torque converter and lines
c. Check oil level with engine running at 800 rpm and oil at 180° to 200°F (82° to 93°C). Add oil to bring oil level to
FULL mark on dipstick.
a. Engine
22a Cooling System
22b and SCA Levels
b. Coolant Filter
Grove
Figure Approved
No. Lubricant
EO-15W/40
Engine Oil
SAE 15W-40
T3 Engine:
6829003483
T4 Engine:
Figure 5-3
6829104182
EO-5W/40
Engine Oil
SAE 5W-40
6829101560
HYDO
Hydraulic Oil
6829006444
Figure 5-3
Hydraulic/
Transmission
Oil
6829101559
AFC 50/50
50/50 Blended
Fully
Formulated
Antifreeze
Figure 5-3
Coolant
A6-829-101130
SCA
6829012858
Published 2-23-2017, Control # 644-00
Lube
Lube Interval
Capacity
• Check level every 10
hours or daily
21 quarts
(19 liters)
• Drain, fill and replace
filter every 500 hours
• Check level every 10
hours or daily
• Drain and refill every
1000 hours or 6
34 quarts months
(32 liters)
• Change transmission
filter after first 50 and
100 hours of service,
then every 500 hours
thereafter
• Check coolant level
every 10 hours or
daily
• Change filter and
36 quarts
check SCA levels
(34 liters)
every 500 hours
• Check coolant for
contamination every
1000 hours
LUBRICATION
Application
• Through fill cap to
FULL mark on
dipstick
• Filter located
under radiator
Through fill pipe to
FULL mark on
dipstick
5
See Service Manual
5-11
