OPERATING CONTROLS AND PROCEDURES
Item Description
3 Date/time display
Rigging Mode
4 Submenu, page 3-
78, F5
Lifting Capacity
5 Tables Submenu,
page 3-92, F6
3-76
Graphic
1
2
5
3
6
4
9
1
2
3
6
4
5
10
Published 2-23-2017, Control # 644-00
RT9150E OPERATOR MANUAL
(1) Time
(2) Date
To change the time/date refer to the
Settings Submenu, page 3-99.
(1) Enter counterweight, F1
(2) Enter outrigger span, F2
(3) Enter swing range, F3
(4) Enter reeving, F4
(5) Maximum load display
7
(6) Boom system display
(7) Selection:
8
Up, F5
Down, F6
(8) Boom system entry, F7
(9) Enter RCL code, F9
10
(10) Boom angle display, F14
For a complete rigging mode input, you
must enter, confirm and accept the
rigging mode and reeving, refer to
Rigging Mode Submenu, page 3-78.
Press the F6 button in main menu to
open this submenu.
(1) RCL code display
(2) Reeving display
(3) Maximum load display
8
(4) Current load display
(5) Current working radius display
(6) Load Chart display
7
(7) Current percent of max. load
9
display
(8) Selection
(9) Working range submenu
(10) Telescope status display/input
Refer to Lifting Capacity Tables
Submenu, page 3-92.
Explanation
