RT9150E OPERATOR MANUAL
Warning Submenu
1
2
5
6
9
10
14
13
Item
Description
1
Fuel level
Low steering
2
pressure
(CE option)
Voltage
3
monitoring
Transmission oil
4
temperature
Grove
3
4
7
8
11
12
16
15
FIGURE 3-63
Graphic
Published 2-23-2017, Control # 644-00
OPERATING CONTROLS AND PROCEDURES
Item
1
Fuel level
2
Low steering pressure (CE option)
3
Voltage monitoring
4
Transmission oil temperature
5
Hoist fifth wrap indicator
6
Low brake pressure
Ambient air temperature, -29°C (Cold Weather
7
Option)
8
Engine warning
9
Pre-tension the counterweight
10
Replace the hydraulic oil filter
11
Anemometer not connected
12
Engine stop
13
Hydraulic oil temperature
14
Exhaust System Cleaning Required (T4i Engine)
15
Inhibit Exhaust System Cleaning
16
High Exhaust System Temperature (HEST)
Refer to the following table for a description of each item
listed above.
The fuel tank is only filled up to a level
of approximately 5%.
Refuel before the fuel is used up.
When the fuel tank is almost empty, air
is sucked in and you must bleed the
fuel system, refer to the Service
Manual.
Inspect the steering system for leaks
and check the accumulator charge.
Refer to the Service Manual.
The voltage in the electrical system is
too high or too low.
Display of the current voltage, refer to
Monitoring submenu, page 3-47.
The temperature of the transmission oil
is outside the operational range.
Description
Explanation
3
3-63
