OPERATING CONTROLS AND PROCEDURES
Item Description
ECOS display:
Main menu
1
overview
2 or Sensor for
5 brightness
Error/warning
3
message
4 Buttons F1 to F14
Opening the Error
submenu
6
Error submenu
overview
3-18
Graphic
Published 2-23-2017, Control # 644-00
RT9150E OPERATOR MANUAL
Explanation
The main menu appears after
switching on the ignition.
The symbols, four per side, which
represent submenus are indicated at
the top left by a blue corner.
Submenus are opened by pressing the
button next to the respective symbol.
Refer to Main Menu, page 3-21.
Registers the brightness of the
operating environment. The brightness
of all displays are automatically
adjusted.
Refer to Adjusting the Brightness of the
Display, page 3-57 to manually set the
minimum brightness.
• Flashing: new warning message or
error has occurred
• On: error acknowledged, but still
present
• Off: no warning message or error
present
Refer to Error Messages, page 3-66.
The function of buttons F1 to F14 is
shown on the symbol next to or above
the button. Push the button once, the
function displayed is executed.
The lamp (1) lights up or flashes.
Press the button once to open the
Error Submenu.
ECOS differentiates between error
messages and warning messages.
In the event of an error message, the
lamps (1) and (2) flash.
More information on error messages,
refer to Error Messages, page 3-66.
