OPERATING CONTROLS AND PROCEDURES
Item Description
Anemometer
14
display
Description of Telescope Section Views
Refer to Figure 3-21.
The Telescope submenu of the ECOS display shows two
sectional views of the main boom:
• (A), the sectional view from the rear
• (B), the sectional view from above.
3-36
Graphic
A
Item
1
2
3
4
5
6
7
8
9
10
Published 2-23-2017, Control # 644-00
RT9150E OPERATOR MANUAL
Explanation
(1) Scale in meters per second (m/sec)
(2) Beaufort scale (B)
(3) Display of wind speed
Refer to Section 2 for safety
information and Wind Forces, page 3-
105 for more information on this
display.
B
Description
Telescopic section 1
Telescopic section 2
Telescopic section 3
Section cutouts
Cylinder locking pins
Cylinder locking pin cutouts
Telescopic section locking pins
Telescope cylinder (rod)
Boom base section
Butterfly mechanism
A
B
FIGURE 3-21
