RT9150E OPERATOR MANUAL
Lube Point
Item
Description

Drive Train (continued)

Coolant Strainer
23
(Cab Heater)
24a Air Cleaner
Filters
24b Pre-cleaner
25a Water Separator
25b Fuel Filter
26a Driveline - Slip
26b Joints
Retarder
27
(Optional)
NOTE: Grease using hand grease gun until grease comes out of vent tube outlet located near grease nipple.
CAUTION: Do not mix synthetic oil with mineral based oil.
Grove
Figure Approved
No. Lubricant
Figure 5-4 ---
Figure 5-4 ---
Figure 5-4 ---
EP-MPG
Extreme
Pressure
Figure 5-4 Multipurpose
Grease
6829003477
6829104275
Figure 5-4 ---
Published 2-23-2017, Control # 644-00
Lube
Lube Interval
Capacity
Clean strainer screen
after first 100 hours and
---
every 2000 hours or 12
months thereafter.
• Replace primary filter
element when
indicator shows red
(25 in of H
2
Replace secondary
filter every third time
---
primary filter is
replaced.
• In severe dust
conditions the pre-
cleaner may need to
be serviced.
• Drain water trap
every 10 hours or
daily.
---
• Change filter every
500 hours or 6
months.
Until
grease 500 hours or 3 months
extrudes
--- After 2000 hours
LUBRICATION
Application
Close shutoff valves.
Unscrew hex plug to
clean filter.
0).
Right hand side of
engine hood.
Primary fuel/water
separator is located
beside the fuel tank.
Fuel filter is located
on the right side of
the engine
3 grease fittings
Grease using hand
grease gun
5
5-13
