RT9150E OPERATOR MANUAL

ECOS CONTROL UNIT

The ECOS control panel is located on the right side console.
Various menus are displayed on the ECOS display. the
menus are operated using buttons F1 to F14. The individual
buttons have a different function in each menu. The
functions of the buttons in the display menu correspond to
Item
1 ECOS display: Main menu overview
2 Sensor for brightness
3 Error/warning message
4 Buttons F1 to F14
5 Sensor for brightness
Opening the Error submenu
6
Submenu overview
7 Entering the keycode
Grove
Description
Published 2-23-2017, Control # 644-00
OPERATING CONTROLS AND PROCEDURES
the symbols next to or above the buttons. After the button is
pressed and released the function displayed is executed.

Common Elements

This section describes the operating elements that are the
same for all menus.
Item
Opening the warning submenu
7.1
Submenu overview (superstructure)
Opening the warning submenu
7.2
Submenu overview (carrier)
8 Exiting the submenu/input mode
9 Swing gear lock/brake engaged/released
10 Entering values
11 Warning for anti two-block switch shutdown
12 Input confirmation
Refer to the following table for a description of each item
listed above.
FIGURE 3-13
Description
3
3-17
