RT9150E OPERATOR MANUAL
5. Remove the clamp (1) (Figure 4-3).
7592-4
4
7592-6
2
Item
1 Clamp
2 Pouch
3 Cable Hole
4 Cable Wedge
6. Push the cable through the hole (3) (Figure 4-3) until the
cable wedge (4) slides out of the pouch (2).
7. Remove the cable wedge and place the cable away from
the crane.

Installing a New Cable

WARNING
Entanglement Hazard!
Keep all body parts and loose clothing clear while hoist is
running.
Death or serious injury may result if entanglement occurs
during hoist operations.
Grove
4
1
FIGURE 4-3
3
Description
Published 2-23-2017, Control # 644-00
If cable is wound from the storage drum, the reel should
be rotated in the same direction as the hoist.
Damage to the wire rope may occur.
1
1. Tension the cable slightly while winding it onto the drum.
2. Place the reel stand (1) (Figure 4-4) with the new cable
in front of the main boom head.
2
3. Guide cable over the head sheave (2) (Figure 4-4) up to
the hoist drum.
7592-7
4. Guide the cable through the hole (3) (Figure 4-5) until it
extends about 5.0 ft (1.5 m) beyond the pouch (2)
(Figure 4-5).
5. Feed the free end of the cable back through the pouch
(2) (Figure 4-5).
4
7592-8
6. Secure the clamp (1) (Figure 4-5) and tighten it. Torque
to 58 lb-ft (79 Nm).
7. Place the cable wedge (4) (Figure 4-5) in the loop.
SET-UP AND INSTALLATION
CAUTION
2
1
FIGURE 4-4
1
3
FIGURE 4-5
2
4
4-3
