Manitowoc Grove RT9150E Operator's Manual page 152

OPERATING CONTROLS AND PROCEDURES
RIGGING MODE SUBMENU
For a complete rigging mode input, you must enter, confirm
and accept the rigging and reeving conditions as they
currently exist on the machine.
Opening the Submenu
In the main menu and press the F5 button (1) (Figure 3-74)
once.
Rigging Mode Menu
1
2
3
4
9
Item Description
Enter
1
counterweight, F1
3-78
5
6
FIGURE 3-75
Graphic
Published 2-23-2017, Control # 644-00
RT9150E OPERATOR MANUAL
Item
1 Enter counterweight, F1
7
2 Enter outrigger span, F2
3 Enter swing range, F3
4 Enter reeving, F4
5 Maximum load display
8
6 RCL code graphic display
Selection:
7 Up, F5
Down, F6
8 Boom system entry, F7
9 Enter RCL code, F9
Refer to the following table for a description of each item
listed above.
The procedures are given in detail after the table.
FIGURE 3-74
Description
Explanation
• Start Input mode: press the F1
button (1) once, symbol turns green
• Input mode on: press either the F5
button or the F6 button
to bring up the next counterweight
configuration (2).
Refer to Counterweight, page 3-82.
once,
