Page 1 INVERTER FR-F800 INSTRUCTION MANUAL (DETAILED) Inverter for fans and pumps FR-F820-00046(0.75K) to 04750(110K) FR-F840-00023(0.75K) to 06830(315K) FR-F842-07700(355K) to 12120(560K) FR-F846-00023(0.75K) to 03610(160K)
Page 2 Safety instructions..............8 Chapter 1 INTRODUCTION .
Page 3 2.8.2 Connection of the brake unit (FR-BU)..............82 2.8.3 Connection of the brake unit (BU type) .
Page 4 4.5.5 Setting the frequency using an analog signal (current input) ..........127 Basic operation procedure (External operation) .
Page 5 5.5.5 Minimum motor speed frequency at the motor start up........... 239 (D) Operation command and frequency command .
Page 6 5.11.2 Self power management ................410 5.11.3 Start count monitor .
Page 7 Reset method for the protective functions ........589 Check and clear of the fault history .
Page 8 Common specifications ........... . . 646 Outline dimension drawings.
Page 9 • A person who possesses a certification in regard with electric appliance handling, or person took a proper engineering training. Such training may be available at your local Mitsubishi Electric office. Contact your local sales office for schedules and locations.
Page 10 Electric shock prevention WARNING  Do not remove the front cover or the wiring cover while the power of this product is ON, and do not run this product with the front cover or the wiring cover removed as the exposed high voltage terminals or the charging part of the circuitry can be touched.
Page 11 Additional instructions The following instructions must be also followed. If this product is handled incorrectly, it may cause unexpected fault, an injury, or an electric shock. CAUTION Transportation and installation  Any person who is opening a package using a sharp object, such as a knife or cutter, must wear gloves to prevent injuries caused by the edge of the sharp object.
Page 12 WARNING Usage  Stay away from the equipment after using the retry function in this product as the equipment will restart suddenly after the output shutoff of this product.  Depending on the function settings of this product, the product does not stop its output even when the STOP/RESET key on the operation panel is pressed.
Page 13 CAUTION Usage  The electronic thermal O/L relay function may not be enough for protection of a motor from overheating. It is recommended to install an external thermal relay or a PTC thermistor for overheat protection.  Do not repeatedly start or stop this product with a magnetic contactor on its input side. Doing so may shorten the life of this product.
Page 14 DoS: A denial-of-service (DoS) attack disrupts services by overloading systems or exploiting vulnerabilities, resulting in a denial-of-service (DoS) state. General instruction  For clarity, illustrations in this Instruction Manual may be drawn with covers or safety guards removed. Ensure all covers and safety guards are properly installed prior to starting operation.
Page 15 MEMO Downloaded from ManualsNet.com search engine...
Page 16 CHAPTER 1 INTRODUCTION Product checking and accessories .........................17 Component names ..............................19 Operation steps ..............................21 Related manuals..............................22 Downloaded from ManualsNet.com search engine...
Page 17 Operation panel (FR-DU08) and LCD operation panel (FR-LU08) Parameter unit Parameter unit (FR-PU07) Operation panel and parameter unit Inverter Mitsubishi Electric inverter FR-F800 series Parameter number (Number assigned to function) PU operation Operation using the PU (operation panel/parameter unit) External operation...
Page 18: Product Checking And Accessories
Product checking and accessories Unpack the product and check the rating plate and the capacity plate of the inverter to ensure that the model agrees with the order and the product is intact.  Inverter model Symbol Voltage class Symbol Structure, functionality Symbol Description Symbol Type...
Page 19  Accessory • Fan cover fixing screws These screws are necessary for compliance with the EU Directives. (Refer to the Instruction Manual (Startup).) Capacity Screw size (mm) Quantity FR-F820-00105(2.2K) to FR-F820-00250(5.5K) M3 × 35 FR-F840-00083(3.7K), FR-F840-00126(5.5K) FR-F820-00340(7.5K), FR-F820-00490(11K) M3 × 35 FR-F840-00170(7.5K), FR-F840-00250(11K) FR-F820-00630(15K) to FR-F820-00930(22K) M4 ×...
Page 20: Component Names
Component names Component names are as follows. 1. INTRODUCTION 1.2 Component names Downloaded from ManualsNet.com search engine...
Page 21 Refer to Symbol Name Description page Connector for the operation panel or the parameter unit. Also used for RS-485 PU connector communication. USB A connector Connector for a USB memory device. Connector for a personal computer. Enables communication with FR USB mini B connector Configurator2.
Page 22: Operation Steps
Operation steps : Initial setting Step of operation Frequency command Installation/mounting Inverter output Wiring of the power frequency supply and motor Time (Hz) Start command Control mode selection Start command via the PU connector to give a start to give a start to give a start and RS-485 terminal of the inverter command?
Page 23: Related Manuals
Related manuals Manuals related to the FR-F800 inverter are shown in the following table. Name Manual number FR-F800 Instruction Manual (Startup) IB-0600545 FR-F802 (Separated Converter Type) Instruction Manual (Hardware) IB-0600550ENG FR-CC2 (Converter unit) Instruction Manual IB-0600543ENG FR-F806 (IP55/UL Type 12 specification) Instruction Manual (Hardware) IB-0600676ENG FR Configurator2 Instruction Manual IB-0600516ENG...
Page 24: Table Of Contents
CHAPTER 2 INSTALLATION AND WIRING Peripheral devices ..............................25 Removal and reinstallation of the operation panel or the front covers..............32 Installation of the inverter and enclosure design ....................36 Terminal connection diagrams..........................45 Main circuit terminals ..............................49 Control circuit................................60 Communication connectors and terminals......................77 Connection of stand-alone option units ........................80 Downloaded from ManualsNet.com...
Page 25 INSTALLATION AND WIRING This chapter explains the installation and the wiring of this product. Always read the instructions before use. For the separated converter type, refer to the "INSTALLATION AND WIRING" in the FR-F802 (Separated Converter Type) Instruction Manual (Hardware). For the IP55 compatible model, refer to the "INSTALLATION AND WIRING"...
Page 26: Peripheral Devices
Peripheral devices 2.1.1 Inverter and peripheral devices (b) Three-phase AC power supply (n) USB connector (a) Inverter USB host (A connector) Communication status indicator (LED)(USB host) (c) Molded case circuit breaker (MCCB) or earth leakage current USB device breaker (ELB), fuse (Mini B connector) Personal computer (FR Configurator 2)
Page 27 Refer to Symbol Name Overview page The life of the inverter is influenced by the surrounding air temperature. The surrounding air temperature should be as low as possible within the permissible range. This must be noted especially when the inverter is installed in an enclosure.
Page 28 NOTE • To prevent an electric shock, always earth (ground) the motor and inverter. • Do not install a power factor correction capacitor, surge suppressor, or capacitor type filter on the inverter's output side. Doing so will cause the inverter shut off or damage the capacitor or surge suppressor. If any of the above devices is connected, immediately remove it.
Page 29 500 A — S-N400 Assumes the use of a Mitsubishi Electric standard 4-pole motor with the power supply voltage of 200 VAC 50 Hz. NOTE • Select an MCCB according to the power supply capacity. • Install one MCCB per inverter. For the use in the United States or Canada, refer to "Instructions for UL and cUL" in the Instruction Manual (Startup) or Instruction Manual (Hardware) to select an appropriate fuse or MCCB.
Page 30 700 A — S-N600 Assumes the use of a Mitsubishi Electric standard 4-pole motor with the power supply voltage of 400 VAC 50 Hz. NOTE • Select an MCCB according to the power supply capacity. • Install one MCCB per inverter. For the use in the United States or Canada, refer to "Instructions for UL and cUL" in the Instruction Manual (Startup) or Instruction Manual (Hardware) to select an appropriate fuse or MCCB.
Page 31  SLD rating (Pr.570 Multiple rating setting = "0") • 200 V class Molded case circuit breaker (MCCB) or earth Magnetic contactor (MC) on inverter input Motor leakage circuit breaker (ELB) (NF or NV type) side Applicable inverter output model Power factor improving AC/DC reactor Power factor improving AC/DC reactor (kW)
Page 32 • 400 V class Molded case circuit breaker (MCCB) or earth Magnetic contactor (MC) on inverter input Motor leakage circuit breaker (ELB) (NF or NV type) side Applicable inverter output model Power factor improving AC/DC reactor Power factor improving AC/DC reactor (kW) Not installed Installed...
Page 33: Removal And Reinstallation Of The Operation Panel Or The Front Covers
Removal and reinstallation of the operation panel or the front covers  Removal and reinstallation of the operation panel • Loosen the two screws on the operation panel. • Press the upper edge of the operation panel while pulling (These screws cannot be removed.) out the operation panel.
Page 34  Removal of the upper front cover (FR-F820-01540(37K) or lower, FR-F840- 00770(37K) or lower) Loosen Loosen Loosen (a) With the lower front cover removed, loosen the screws on the upper front cover. (These screws cannot be removed.) (FR-F820-00340(7.5K) to FR-F820-01540(37K) and FR-F840-00170(7.5K) to FR-F840-00770(37K) have two mounting screws.) (b) While holding the areas around the installation hooks on the sides of the upper front cover, pull out the cover using its upper side as a support.
Page 35  Removal of the lower front cover (FR-F820-01870(45K) or higher, FR- F840-00930(45K) or higher) (a) Remove the mounting screws to remove the lower front cover. (b) With the lower front cover removed, the main circuit can be wired.  Removal of the upper front cover (FR-F820-01870(45K) or higher, FR- F840-00930(45K) or higher) Loosen Loosen...
Page 36  Reinstallation of the front covers (FR-F820-01870(45K) or higher, FR- F840-00930(45K) or higher) Tighten Tighten Tighten Tighten Tighten Tighten (a) Clip on the upper front cover as illustrated. Securely install the cover to the inverter by fixing the hooks on the sides of the cover into place. (b) Tighten the screws on the lower part of the cover.
Page 37: Installation Of The Inverter And Enclosure Design
Installation of the inverter and enclosure design When designing or manufacturing an inverter enclosure, determine the structure, size, and device layout of the enclosure by fully considering the conditions such as heat generation of the contained devices and the operating environment. An inverter unit uses many semiconductor devices.
Page 38 NOTE • For the amount of heat generated by the inverter unit, refer to page  Humidity Operate the inverter within the ambient air humidity of usually 45% to 90% (up to 95% with circuit board coating). Too high humidity will pose problems of reduced insulation and metal corrosion. On the other hand, too low humidity may cause a spatial electrical breakdown.
Page 39  Vibration, impact The vibration resistance of the inverter is up to 5.9 m/s (2.9 m/s or less for the FR-F840-04320(185K) or higher) at 10 to 55 Hz frequency and 1 mm amplitude in X, Y, and Z directions. Subjecting the product to vibration and impacts over a long period of time may loosen the structures and cause poor contacts of connectors, even if those vibration and impacts are within the specified values.
Page 40 2.3.2 Amount of heat generated by the inverter  Installing the heat sink inside the enclosure When the heat sink is installed inside the enclosure, the amount of heat generated by the inverter unit is shown in the following tables. Amount of heat generated (W) Voltage Inverter model...
Page 41  Installing the heat sink outside the enclosure When the heat sink is installed outside the enclosure, the amount of heat generated by the inverter unit is shown in the following tables. (For the details on protruding the heat sink through a panel, refer to page 43.) Amount of heat generated (W)
Page 42 • Cooling by ventilation (forced ventilation type, pipe ventilation type) • Cooling by heat exchanger or cooler (heat pipe, cooler, etc.) Cooling system Enclosure structure Comment This system is low in cost and generally used, but the Natural ventilation (enclosed enclosure size increases as the inverter capacity type / open type) increases.
Page 43 Clearances (front) Clearances (side) FR-F820-03160(75K) or lower, FR-F820-03800(90K) or higher, FR-F840-01800(75K) or lower FR-F840-02160(90K) or higher 20 cm 10 cm or more or more 5 cm or more 5 cm 5 cm 10 cm 10 cm *1,*2 *1,*2 *1,*3 or more or more or more or more...
Page 44  Arrangement of the ventilation fan and inverter Heat generated in the inverter is blown up from the bottom of the unit as warm air by the cooling fan. When installing a ventilation fan for that heat, determine the place of ventilation fan installation after fully considering an air flow. (Air passes through areas of low resistance.
Page 45  Mount point change of installation frame from the rear to the front The upper and lower installation frames are attached on the inverter (one for each position). Change the mount point of the upper and lower installation frames from the rear to the front as shown in the figure. When reattaching the installation frames, make sure that the installation orientation is correct.
Page 46: Terminal Connection Diagrams
Terminal connection diagrams  Type FM FR-F820-00770(18.5K) to 01250(30K), FR-F840-00470(22K) to 01800(75K) DC reactor (FR-HEL) DC reactor Brake unit (Option) (FR-HEL) Sink logic Brake unit (Option) Jumper Main circuit terminal Earth (Ground) Control circuit terminal Jumper Jumper Earth PR N/- (Ground) Inrush PX PR N/-...
Page 47 For the FR-F820-03160(75K) or higher and the FR-F840-01800(75K) or higher, always connect the DC reactor option FR-HEL. Refer to page to select the right DC reactor according to the applicable motor capacity. To connect a DC reactor to the FR-F820-02330(55K) or lower or the FR-F840-01160(55K) or lower, remove a jumper installed across terminals P1 and P/+, before installing the DC reactor.
Page 48  Type CA FR-F820-00770(18.5K) to 01250(30K), FR-F840-00470(22K) to 01800(75K) DC reactor (FR-HEL) DC reactor Brake unit (Option) (FR-HEL) Source logic Brake unit Jumper (Option) Main circuit terminal Earth (Ground) Control circuit terminal Jumper Jumper Earth PR N/- (Ground) Inrush PX PR N/- current limit circuit...
Page 49 For the FR-F820-03160(75K) or higher and the FR-F840-01800(75K) or higher, always connect the DC reactor option FR-HEL. Refer to page to select the right DC reactor according to the applicable motor capacity. To connect a DC reactor to the FR-F820-02330(55K) or lower or the FR-F840-01160(55K) or lower, remove a jumper installed across terminals P1 and P/+, before installing the DC reactor.
Page 50: Main Circuit Terminals
Main circuit terminals 2.5.1 Details on the main circuit terminals Terminal Refer to Terminal name Terminal function description symbol page Connect these terminals to the commercial power supply. Do not connect anything to these terminals when using the high power factor R/L1, S/L2, T/ AC power input —...
Page 51 2.5.2 Main circuit terminal layout and wiring to power supply and motor FR-F820-00046(0.75K), FR-F820-00077(1.5K) FR-F820-00105(2.2K) to FR-F820-00250(5.5K) FR-F840-00023(0.75K) to FR-F840-00126(5.5K) Jumper Jumper R/L1 S/L2 T/L3 Jumper R/L1 S/L2 T/L3 P/+ PR Jumper R1/L11 S1/L21 R1/L11 S1/L21 Charge lamp Power supply Motor Charge lamp Power supply...
Page 52 FR-F820-01870(45K), FR-F820-02330(55K) FR-F820-03160(75K) R1/L11 S1/L21 R1/L11 S1/L21 Charge lamp Charge lamp Jumper Jumper R/L1 S/L2 T/L3 R/L1 S/L2 T/L3 N/- Jumper Power supply Motor Power supply DC reactor Motor (option) FR-F820-03800(90K), FR-F820-04750(110K) FR-F840-00930(45K) to FR-F840-01800(75K) FR-F840-03250(132K) to FR-F840-04810(220K) R1/L11 S1/L21 R1/L11 S1/L21 Charge lamp Charge lamp...
Page 53 NOTE • Make sure the power cables are connected to the R/L1, S/L2, and T/L3. (Phase need not be matched.) Never connect the power cable to the U, V, and W of the inverter. Doing so will damage the inverter. •...
Page 54 2.5.3 Recommended cables and wiring length Select a recommended size cable to ensure that the voltage drop ratio is within 2%. If the wiring distance is long between the inverter and motor, the voltage drop in the main circuit will cause the motor torque to decrease especially at a low speed.
Page 55 • 400 V class (440 V input power supply, without a power factor improving AC or DC reactor) Cable gauge Crimp terminal Applicable Terminal Tightening HIV cables, etc. (mm AWG/MCM PVC cables, etc. (mm inverter model screw torque R/L1, S/ R/L1, Earthing R/L1,...
Page 56 For all the 200 V class capacities and FR-F840-00930(45K) or lower, it is the gauge of a cable with the continuous maximum permissible temperature of 75°C (THHW cable). It is assumed that the cables will be used in a surrounding air temperatures of 40? or less and the wiring distance of 20 m or shorter.
Page 57 • 400 V class (440 V input power supply, without a power factor improving AC or DC reactor) Cable gauge Crimp terminal Applicable Terminal Tightening HIV cables, etc. (mm AWG/MCM PVC cables, etc. (mm inverter model screw torque R/L1, S/ R/L1, Earthing R/L1,...
Page 58 For all the 200 V class capacities and FR-F840-00930(45K) or lower, it is the gauge of a cable with the continuous maximum permissible temperature of 75°C (THHW cable). It is assumed that the cables will be used in a surrounding air temperatures of 40°C or less and the wiring distance of 20 m or shorter.
Page 59  With PM motor Use the following length of wiring or shorter when connecting a PM motor. FR-F820-00077(1.5K) or lower, FR-F820-00105(2.2K) or higher, Voltage class Pr.72 setting (carrier frequency) FR-F840-00038(1.5K) or lower FR-F840-00052(2.2K) or higher 200 V 0 (2 kHz) to 15 (14 kHz) 100 m 100 m 5 or lower (2 kHz)
Page 60 2.5.4 Earthing (grounding) precautions Always earth (ground) the motor and inverter.  Purpose of earthing (grounding) Generally, an electrical apparatus has an earth (ground) terminal, which must be connected to the ground before use. An electrical circuit is usually insulated by an insulating material and encased. However, it is impossible to manufacture an insulating material that can shut off a leakage current completely, and actually, a slight current flows into the case.
Page 61: Control Circuit
Control circuit 2.6.1 Details on the control circuit terminals  Input signal Refer Terminal Type Common Terminal name Terminal function description Rated specification symbol page Turn ON the STF signal to start When the STF Forward rotation forward rotation and turn it OFF to and STR signals start stop.
Page 62 Refer Terminal Type Common Terminal name Terminal function description Rated specification symbol page 10 ±0.4 VDC, permissible load When connecting the frequency setting potentiometer current: 10 mA Frequency setting at an initial status, connect it to terminal 10. power supply Change the input specifications of terminal 2 using 5 ±0.5 VDC, Pr.73 when connecting it to terminal 10E.
Page 63  Output signal Refer Terminal Type Common Terminal name Terminal function description Rated specification symbol page 1 changeover contact output that indicates that an inverter's protective function has been activated and A1, B1, Relay output 1 (fault the outputs are stopped. Contact capacity: 230 —...
Page 64  Safety stop signal Refer Terminal Terminal name Common Terminal function description Rated specification symbol page Use terminals S1 and S2 to receive the safety stop signal input from the safety relay module. Terminals S1 and S2 can Safety stop input be used at a time (dual channel).
Page 65  Communication Terminal Refer Type Terminal name Terminal function description symbol to page RS-485 communication can be made through the PU connector (for connection on a 1:1 basis only). Conforming standard: EIA-485 (RS-485) — PU connector Transmission format: Multidrop link Transmission speed: 4800 to 115200 bps Wiring length: 500 m TXD+...
Page 66  Sink logic and source logic • In the sink logic, a signal turns ON when a current exits from the corresponding signal input terminal. Terminal SD is common to the contact input signals. Terminal SE is common to the open collector output signals. •...
Page 67 2.6.3 Wiring of control circuit  Control circuit terminal layout • Recommended cable gauge: 0.3 to 0.75 mm ∗1 1 F/C +24 SD So SOC S1 S2 PC 5 10E 10 SE SE IPF OL FU PC RL RM RH RT AU STP MRS RES SD SD STF STR JOG...
Page 68 • NICHIFU Co., Ltd. Blade terminal Insulation cap product Crimping tool product Cable gauge (mm product number number number 0.3 to 0.75 BT 0.75-11 VC 0.75 NH 69 Insert the wire into the terminal block. When using single wire or stranded wire without crimp terminal, push an open/close button all the way down with a flathead screwdriver, and insert the wire.
Page 69  Common terminals of the control circuit (SD, PC, 5, SE) • Terminals SD (sink logic), PC (source logic), 5, and SE are common terminals (0 V) for I/O signals. (All common terminals are isolated from each other.) Do not earth (ground) these terminals. Avoid connecting terminal SD (sink logic) with terminal 5, terminal PC (source logic) with terminal 5, and terminal SE with terminal 5.
Page 70 • When a relay coil is connected to the output terminals, use one with a surge absorbing function (reflux diode). When the voltage application direction is incorrect, the inverter will be damaged. Pay attention to the diode direction or other precautions to avoid incorrect wiring.
Page 71 • FR-F820-00250(5.5K) or lower, FR-F840-00126(5.5K) or lower S/L2 R/L1 T/L3 R1/L11 S1/L21 Main circuit terminal block (a) Remove the upper screws. (b) Remove the lower screws. (c) Remove the jumper. (d) Connect the separate power cable for the control circuit to the lower terminals (R1/L11, S1/L21). •...
Page 72 • FR-F820-00770(18.5K) or higher, FR-F840-00470(22K) or higher R1/L11 S1/L21 Power supply terminal block for the control circuit Power supply terminal block for the control circuit R/L1 S/L2 T/L3 R1/L11 S1/L21 Main power supply FR-F820-00770(18.5K) to 01250(30K) FR-F840-00470(22K), FR-F820-01540(37K) FR-F820-01870(45K) or higher 00620(30K) FR-F840-00770(37K) FR-F840-00930(45K) or higher...
Page 73 NOTE • When using separate power supplies, always remove the jumpers across terminals R/L1 and R1/L11 and across S/L2 and S1/ L21. The inverter may be damaged if the jumpers are not removed. • When the control circuit power is supplied from other than the input line of the MC, the voltage of the separate power supply must be the same as that of the main control circuit .
Page 74 2.6.6 When supplying 24 V external power to the control circuit Connect the 24 V external power supply across terminals +24 and SD to turn the I/O terminal ON/OFF operation, keep the operation panel ON, and carry out communication during communication operation even at power-OFF state of inverter's main circuit power supply.
Page 75 • During the 24 V external power supply operation, the monitor items and signals related to inputs to main circuit power supply, such as the output current, converter output voltage, and IPF signal, are invalid. • The alarms, which have occurred when the main circuit power supply is ON, continue to be output after the power supply is changed to the 24 V external power supply.
Page 76  Connection diagram To prevent restart at failure occurrence, connect terminals So (SO) and SOC to the reset button, which are the feedback input terminals of the safety relay module. Inverter R/L1 S/L2 T/L3 So (SO) Logic IGBTs +24V Gate Gate ASIC Driver...
Page 77 For more details, refer to the Safety Stop Function Instruction Manual. Find a PDF file of the manual in the CD-ROM enclosed with the product. The manual can also be downloaded in PDF form from the Mitsubishi Electric FA Global Website. www.MitsubishiElectric.co.jp/fa 2.
Page 78: Communication Connectors And Terminals
Communication connectors and terminals 2.7.1 PU connector  Mounting the operation panel or the parameter unit on the enclosure surface • Having an operation panel or a parameter unit on the enclosure surface is convenient. With a connection cable, the operation panel or the parameter unit can be mounted to the enclosure surface and connected to the inverter.
Page 79 2.7.2 USB connector USB host (A connector) USB memory device Communication status Place a flathead screwdriver, indicator (LED) etc. in a slot and push up the USB device cover to open. (Mini B connector) Personal computer (FR Configurator2)  USB host communication Interface Conforms to USB 1.1 Transmission speed...
Page 80 NOTE • Do not connect devices other than a USB memory device to the inverter. • If a USB device is connected to the inverter via a USB hub, the inverter cannot recognize the USB memory device properly.  USB device communication The inverter can be connected to a personal computer with a USB (ver.
Page 81: Connection Of Stand-Alone Option Units
Connection of stand-alone option units The inverter accepts a variety of stand-alone option units as required. Incorrect connection will cause inverter damage or accident. Connect and operate the option unit carefully in accordance with the Instruction Manual of the corresponding option unit. 2.8.1 Connection of the brake unit (FR-BU2) Connect the brake unit (FR-BU2(-H)) as follows to improve the braking capability during deceleration.
Page 82  Connection example with the FR-BR(-H) resistor unit FR-BR MCCB Motor R/L1 Three phase AC S/L2 power supply T/L3 FR-BU2 Inverter 10 m or less When wiring, make sure to match the terminal symbols (P/+, N/-) on the inverter and on the brake unit (FR-BU2). (Incorrect connection will damage the inverter and brake unit.) When the power supply is 400 V class, install a stepdown transformer.
Page 83 2.8.2 Connection of the brake unit (FR-BU) Connect the brake unit (FR-BU(-H)) as follows to improve the braking capability during deceleration. The FR-BU is compatible with the FR-F820-02330(55K) or lower and the FR-F840-01160(55K) and lower. FR-BR MCCB Motor R/L1 Three-phase AC S/L2 power supply T/L3...
Page 84 2.8.4 Connection of the high power factor converter (FR- HC2) When connecting the high power factor converter (FR-HC2) to suppress power harmonics, perform wiring securely as follows. Incorrect connection will damage the high power factor converter and the inverter. After making sure that the wiring is correct and secure, set the rated motor voltage in Pr.19 Base frequency voltage (under V/F control) or Pr.83 Rated motor voltage (under other than V/F control) and "2 or 102"...
Page 85 2.8.5 Connection of the multifunction regeneration converter (FR-XC)  Common bus regeneration mode with harmonic suppression disabled (Pr.416 = "0") When connecting the multifunction regeneration converter (FR-XC) to improve the braking capability, perform wiring securely as follows. Incorrect connection will damage the converter and the inverter. Turn ON switch 1 (connection mode setting switch) in the function selection switch assembly (SW2).
Page 86 Connect between the inverter terminal P/+ and the converter terminal P/+ and between the inverter terminal N/- and the converter terminal N/- for polarity consistency. Connecting opposite polarity of terminals P/+ and N/- will damage the converter and the inverter. Confirm the correct phase sequence of three-phase current to connect between the reactor and the converter, and between the power supply and terminals R/L1, S/L2, and T/L3.
Page 87 2.8.6 Connection of the power regeneration common converter (FR-CV) When wiring for connecting the power regeneration common converter (FR-CV) to the inverter, make sure to match the terminal symbols (P/+, N/-) on the inverter and on the power regeneration common converter. The FR-CV is compatible with the FR-F820-02330(55K) or lower and the FR-F840-01160(55K) or lower.
Page 88 2.8.7 Connection of the power regeneration converter (MT-RC) When connecting the power regeneration converter (MT-RC), perform wiring securely as follows. Incorrect connection will damage the power regeneration converter and the inverter. The MT-RC is compatible with FR-F840-01800(75K) or higher. After making sure that the wiring is correct and secure, set "1 or 101" in Pr.30 Regenerative function selection. Inverter MCCB R/L1...
Page 89 2.8.8 Connection of the DC reactor (FR-HEL) • Keep the surrounding air temperature within the permissible range (-10°C to +50°C). Keep enough clearance around the reactor because it heats up. (Take 10 cm or more clearance on top and bottom and 5 cm or more on left and right regardless of the installation direction.) 10 cm or more 5 cm or...
Page 90 CHAPTER 3 PRECAUTIONS FOR USE OF THE INVERTER Electro-magnetic interference (EMI) and leakage currents ..................90 Power supply harmonics............................97 Installation of a reactor ............................101 Power shutdown and magnetic contactor (MC)....................102 Countermeasures against deterioration of the 400 V class motor insulation............104 Checklist before starting operation ........................105 Failsafe system which uses the inverter .......................108 Downloaded from ManualsNet.com...
Page 91: Electro-Magnetic Interference (Emi) And Leakage Currents
PRECAUTIONS FOR USE OF THE INVERTER This chapter explains the precautions for use of this product. Always read the instructions before use. For the separated converter type, refer to the "PRECAUTIONS FOR USE OF THE INVERTER" in the FR-F802 (Separated Converter Type) Instruction Manual (Hardware).
Page 92  Line-to-line leakage current example (200 V class) Leakage current (mA) Motor capacity Rated motor Condition (kW) current (A) Wiring length 50 m Wiring length 100 m 0.75 • Motor: SF-JR 4P • Carrier frequency: 14.5 kHz • Cable: 2 mm , 4 cores 12.8 •...
Page 93 Breaker designed Item for harmonic and Standard breaker Example surge suppression 5.5 mm 5.5 mm 50 m Leakage current Ig1 (mA) 33 × = 0.17 1000m Noise Leakage current Ign (mA) 0 (without noise filter) filter 3φ Inverter 200 V 1 (without EMC filter).
Page 94 3.1.2 Techniques and measures for electromagnetic compatibility (EMC) Some electromagnetic noises enter the inverter to cause the inverter malfunction, and others are radiated by the inverter to cause the peripheral devices to malfunction. (The former is called EMS problem, the latter is called EMI problem, and both is called EMC problem.) Though the inverter is designed to be immune to noises, it requires the following basic measures and EMS measures as it handles low-level signals.
Page 95 Noise propagation Countermeasure path When devices that handle low-level signals and are liable to malfunction due to electromagnetic noises, e.g. instruments, receivers and sensors, are contained in the enclosure that contains the inverter or when their signal cables are run near the inverter, the devices may malfunction due to by air-propagated electromagnetic noises. The following countermeasures must be taken: •...
Page 96  EMI measure example Enclosure Decrease carrier frequency. Install filter (FR-BLF or FR-BSF01) on inverter output side. Inverter power Inverter Motor filter supply Use 4-core cable for motor Separate inverter and power cable and use one cable power line by more than as earth (ground) cable.
Page 97 • When disconnecting the connector, push the fixing tab and pull the connector straight without pulling the cable or forcibly pulling the connector with the tab fixed. When installing the connector, also engage the fixing tab securely. (If it is difficult to disconnect the connector, use a pair of needle-nose pliers, etc.) EMC filter Disengage connector fixing tab.
Page 98: Power Supply Harmonics
Power supply harmonics 3.2.1 Power supply harmonics The inverter may generate power supply harmonics from its converter circuit to affect the power generator, power factor correction capacitor etc. Power supply harmonics are different from noise and leakage currents in source, frequency band and transmission path.
Page 99 3.2.2 Harmonic suppression guidelines in Japan Inverters have a converter section (rectifier circuit) and generate a harmonic current. Harmonic currents flow from the inverter to a power receiving point via a power transformer. The Harmonic Suppression Guidelines was established to protect other consumers from these outgoing harmonic currents. The three-phase 200 V input specifications 3.7 kW or lower were previously covered by "the Harmonic Suppression Guidelines for Household Appliances and General-purpose Products"...
Page 100  Equivalent capacity limit Received power voltage Reference capacity 6.6 kV 50 kVA 22/33 kV 300 kVA 66 kV or more 2000 kVA  Harmonic content (when the fundamental current is considered as 100%) Reactor 11th 13th 17th 19th 23rd 25th Not used Used (AC side)
Page 101 Fundamental Fundamental Outgoing harmonic current converted from 6.6 kV (mA) (with a DC reactor, Rated Applicable wave current wave current (A) 100% operation ratio) capacity motor (kW) converted from (kVA) 200 V 400 V 11th 13th 17th 19th 23rd 25th 6.6 kV (mA) 7455 87.2...
Page 102: Installation Of A Reactor
Installation of a reactor When the inverter is connected near a large-capacity power transformer (1000 kVA or more) or when a power factor correction capacitor is to be switched over, an excessive peak current may flow in the power input circuit, damaging the converter circuit. To prevent this, always install an AC reactor (FR-HAL), which is available as an option.
Page 103: Power Shutdown And Magnetic Contactor (Mc)
Power shutdown and magnetic contactor (MC)  Inverter input side magnetic contactor (MC) On the inverter input side, it is recommended to provide an MC for the following purposes. (Refer to page 28 for selection.) • To disconnect the inverter from the power supply at activation of a protective function or at malfunctioning of the driving system (emergency stop, etc.).
Page 104 NOTE • Before wiring or inspection for a PM motor, confirm that the PM motor is stopped. In an application, such as fan and blower, where the motor is driven by the load, a low-voltage manual contactor must be connected at the inverter's output side, and wiring and inspection must be performed while the contactor is open.
Page 105: Countermeasures Against Deterioration Of The 400 V Class Motor Insulation
Countermeasures against deterioration of the 400 V class motor insulation In the PWM type inverter, a surge voltage attributable to wiring constants is generated at the motor terminals. Especially in a 400 V class motor, the surge voltage may deteriorate the insulation. When the 400 V class motor is driven by the inverter, consider the following countermeasures: ...
Page 106: Checklist Before Starting Operation
Checklist before starting operation The FR-F800 series inverter is a highly reliable product, but incorrect peripheral circuit making or operation/handling method may shorten the product life or damage the product. Before starting operation, always recheck the following points. Refer to...
Page 107 Refer to Check by Checkpoint Countermeasure page user When using a switching circuit as shown below, chattering due to misconfigured sequence or arc generated at switching may allow undesirable current to flow in and damage the inverter. Miswiring may also damage the inverter. (Note that a PM motor cannot be driven by the commercial power supply.) Interlock When using the electronic bypass...
Page 108 Refer to Check by Checkpoint Countermeasure page user When a motor is driven by the inverter, axial voltage is generated on the motor shaft, which may cause electrical corrosion of the bearing in rare cases depending on the wiring, load, operating conditions of the motor or specific inverter settings (high carrier frequency and EMC filter ON).
Page 109: Failsafe System Which Uses The Inverter
Failsafe system which uses the inverter When a fault is detected by the protective function, the protective function activates and outputs the Fault signal. However, the Fault signal may not be output at an inverter's fault occurrence when the detection circuit or output circuit fails, etc. Although Mitsubishi assures the best quality products, provide an interlock which uses inverter status output signals to prevent accidents such as damage to the machine when the inverter fails for some reason.
Page 110  Checking the inverter operating status by using the start signal input to the inverter and the Inverter running signal output from the inverter ... (c) The Inverter running (RUN) signal is output when the inverter is running. (The RUN signal is assigned to terminal RUN in the initial setting.) Check if the RUN signal is output while a start signal (the STF/STR signal for forward/reverse rotation command) is input to the inverter.
Page 111  Command speed and actual operation check Check for a gap between the actual speed and commanded speed by comparing the inverter's speed command and the speed detected by the speed detector. Controller System failure Sensor Inverter (speed, temperature, air volume, etc.) To the alarm detection sensor 3.
Page 112 CHAPTER 4 BASIC OPERATION Operation panel (FR-DU08)..........................112 Monitoring the inverter ............................117 Easy setting of the inverter operation mode ......................118 Frequently-used parameters (simple mode parameters)..................120 Basic operation procedure (PU operation) ......................122 Basic operation procedure (External operation) ....................129 Basic operation procedure (JOG operation) ......................136 Downloaded from ManualsNet.com search engine...
Page 113: Operation Panel (Fr-Du08)
BASIC OPERATION This chapter explains the basic operation of this product. Always read the instructions before use. Operation panel (FR-DU08) 4.1.1 Components of the operation panel (FR-DU08) To mount the operation panel (FR-DU08) on the enclosure surface, refer to page 4.
Page 114 STOP/RESET key Used to reset the inverter when the protective function is activated. The setting dial of the Mitsubishi Electric inverters. Turn the setting dial to change the setting of frequency or parameter, etc. Press the setting dial to perform the following operations: Setting dial •...
Page 115 4.1.2 Basic operation of the operation panel  Basic operation Operation mode switchover/Frequency setting ∗1( ∗1 External operation mode displayed at power-ON) PU Jog operation mode PU operation mode ∗1 Alternating (Example) Change the setting. Frequency setting written and complete Second screen Third screen (Output current...
Page 116 Changes parameter settings as a batch. The target parameters include Automatic parameter communication parameters for the Mitsubishi Electric human machine setting interface (GOT) connection and the parameters for the rated frequency settings of 50 Hz/60 Hz.
Page 117 4.1.4 Changing the parameter setting value The following shows the procedure to change the setting of Pr.1 Maximum frequency. Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode. Changing the operation mode Press to choose the PU operation mode.
Page 118: Monitoring The Inverter
Monitoring the inverter 4.2.1 Monitoring of output current and output voltage • Press on the operation panel in the monitor mode to switch the monitor item between output frequency, output current, and output voltage. Operating procedure Press during inverter operation to monitor the output frequency. [Hz] indicator turns ON. Press to monitor the output current.
Page 119: Easy Setting Of The Inverter Operation Mode
Easy setting of the inverter operation mode The operation mode suitable for start and speed command combinations can be set easily using Pr.79 Operation mode selection. The following shows the procedure to operate with the external start command (STF/STR) and the frequency command by using Operating procedure Press...
Page 120 NOTE • " " appears if the Pr.79 setting is tried to be changed while the inverter is set that only the parameters registered in the user group are read (Pr.160 = "1") but Pr.79 is not included in the user group. •...
Page 121: Frequently-Used Parameters (Simple Mode Parameters)
Frequently-used parameters (simple mode parameters) Parameters that are frequently used for the FR-F800 series are grouped as simple mode parameters. When Pr.160 User group read selection = "9999", only the simple mode parameters are displayed on the operation panel. This section explains the simple mode parameters.
Page 122 9009, 9109 motor. Changes parameter settings as a batch. The target parameters include communication Automatic 1, 2, 10 to 13, parameters for the Mitsubishi Electric human E431 parameter 9999 20, 21, 9999 machine interface (GOT) connection and the setting parameters for the rated frequency settings of 50/60 Hz.
Page 123: Basic Operation Procedure (Pu Operation)
Basic operation procedure (PU operation) Select a method to give the frequency command from the list below, and refer to the specified page for its procedure. Method to give the frequency command Refer to page Setting the frequency on the operation panel in the frequency setting mode Give commands by turning the setting dial like a potentiometer Give commands by turning ON/OFF switches wired to inverter's terminals (multi-speed setting) Setting the frequency by inputting voltage signals...
Page 124 4.5.1 Setting the frequency on the operation panel (example: operating at 30 Hz) • Use the operation panel (FR-DU08) to give a start command and a frequency command. (PU operation) Operation panel (FR-DU08) The following shows the procedure to operate at 30 Hz. Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode.
Page 125 Parameters referred to Pr.7 Acceleration time, Pr.8 Deceleration timepage 228 Pr.79 Operation mode selectionpage 240 4.5.2 Perform PU operation using the setting dial like a potentiometer • Set Pr.161 Frequency setting/key lock operation selection = "1" (setting dial potentiometer). The following shows the procedure to change the frequency from 0 Hz to 60 Hz during operation. Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode.
Page 126 4.5.3 Setting the frequency with switches (multi-speed setting) • Use on the operation panel (FR-DU08) to give a start command. • Turn ON the RH, RM, or RL signal to give a frequency command (multi-speed setting). • Set Pr.79 Operation mode selection = "4" (External/PU combination operation mode 2). [Connection diagram] Speed 1 Inverter...
Page 127 4.5.4 Setting the frequency using an analog signal (voltage input) • Use on the operation panel (FR-DU08) to give a start command. • Use the frequency setting potentiometer to give a frequency command (by connecting it to terminals 2 and 5 (voltage input)). •...
Page 128 Pr.125 Terminal 2 frequency setting gain frequencypage 357 C2 (Pr.902) Terminal 2 frequency setting bias frequencypage 357 4.5.5 Setting the frequency using an analog signal (current input) • Use on the operation panel (FR-DU08) to give a start command. • Use the current regulator which outputs 4 to 20 mA to give a frequency command (by connecting it across terminals 4 and 5 (current input)).
Page 129 Parameters referred to Pr.7 Acceleration time, Pr.8 Deceleration timepage 228 Pr.79 Operation mode selectionpage 240 Pr.126 Terminal 4 frequency setting gain frequencypage 357 Pr.184 AU terminal function selectionpage 373 C5(Pr.904) Terminal 4 frequency setting bias frequencypage 357 4. BASIC OPERATION 4.5 Basic operation procedure (PU operation) Downloaded from ManualsNet.com search engine...
Page 130: Basic Operation Procedure (External Operation)
Basic operation procedure (External operation) Select a method to give the frequency command from the list below, and refer to the specified page for its procedure. Method to give the frequency command Refer to page Setting the frequency on the operation panel in the frequency setting mode Turning ON/OFF switches wired to inverter's terminals (multi-speed setting) Setting the frequency by inputting voltage signals Setting the frequency by inputting current signals...
Page 131 NOTE • When both the forward rotation start switch (STF signal) and the reverse rotation start switch (STR signal) are turned ON, the motor cannot be started. If both are turned ON while the inverter is running, the inverter decelerates to a stop. •...
Page 132 NOTE • When both the forward rotation start switch (STF signal) and the reverse rotation start switch (STR signal) are turned ON, the motor cannot be started. If both are turned ON while the inverter is running, the inverter decelerates to a stop. •...
Page 133 NOTE • When both the forward rotation start switch (STF signal) and the reverse rotation start switch (STR signal) are turned ON, the motor cannot be started. If both are turned ON while the inverter is running, the inverter decelerates to a stop. •...
Page 134 4.6.4 Changing the frequency (60 Hz, initial value) at the maximum voltage input (5 V, initial value) • Change the maximum frequency. The following shows the procedure to change the frequency at 5 V from 60 Hz (initial value) to 50 Hz using a frequency setting potentiometer for 0 to 5 VDC input.
Page 135 4.6.5 Setting the frequency using an analog signal (current input) • Turn ON the STF/STR signal to give a start command. • Turn ON the AU signal. • Set Pr.79 Operation mode selection = "2" (External operation mode). [Connection diagram] Inverter Forward rotation start Reverse rotation start...
Page 136 4.6.6 Changing the frequency (60 Hz, initial value) at the maximum current input (at 20 mA, initial value) • Change the maximum frequency. The following shows the procedure to change the frequency at 20 mA from 60 Hz (initial value) to 50 Hz using a frequency setting potentiometer for 4 to 20 mA input.
Page 137: Basic Operation Procedure (Jog Operation)
Basic operation procedure (JOG operation) 4.7.1 Giving a start command by using external signals for JOG operation • JOG operation is performed while the JOG signal is ON. • Use Pr.15 Jog frequency to set a frequency, and set Pr.16 Jog acceleration/deceleration time to set the acceleration/ deceleration time for JOG operation.
Page 138 4.7.2 Giving a start command from the operation panel for JOG operation • JOG operation is performed while on the operation panel is pressed. Operation panel (FR-DU08) The following shows the procedure to operate at 5 Hz. Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode.
Page 139 MEMO 4. BASIC OPERATION 4.7 Basic operation procedure (JOG operation) Downloaded from ManualsNet.com search engine...
Page 140 CHAPTER 5 PARAMETERS Parameter list................................140 Control method ..............................175 Speed control under PM motor control .........................188 (E) Environment setting parameters ........................194 (F) Setting of acceleration/deceleration time and acceleration/deceleration pattern ..........228 (D) Operation command and frequency command....................240 (H) Protective function parameter.........................266 (M) Item and output signal for monitoring ......................303 (T) Multi-function input terminal parameters ......................348 5.10 (C) Motor constant parameters..........................379...
Page 141: Parameter List
PARAMETERS This chapter explains the function setting for use of this product. Always read the instructions before use. The following marks are used to indicate the controls. (Parameters without any mark are valid for all the controls.) Mark Control method Applied motor V/F control Three-phase induction motor...
Page 142 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments G000 Simple Simple Simple 0% to 30% 0.1% Torque boost 1.5% 120 Hz H400 Simple Simple Simple 0 to 120 Hz 0.01 Hz Maximum frequency 60 Hz H401 Simple...
Page 143 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Stall prevention operation H500 0% to 400% 0.1% 120% 110% level Stall prevention operation H610 level compensation factor at 0% to 200%, 9999 0.1% 9999 double speed 24 to D304 to...
Page 144 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments 0, 5 to 14, 17, 18, 20, 23 to 25, 34, 38, 40 to Operation panel main 305, M100 45, 50 to 57, 61, 62, 64, monitor selection 67 to 69, 81 to 96, 98, 1 to 3, 5 to 14, 17, 18,...
Page 145 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Reverse rotation prevention — D020 0 to 2 selection Operation mode 240, — D000 0 to 4, 6, 7 Simple Simple Simple selection 177, 0.4 to 55 kW, 9999 0.01 kW C101 Motor capacity...
Page 146 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments PU communication station N020 0 to 31 number 48, 96, 192, 384, 576, N021 PU communication speed 768, 1152 PU communication stop bit — 0, 1, 10, 11 length / data length PU communication data N022...
Page 147 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Stall prevention level at 0 V H620 0% to 400% 0.1% 120% 110% input Stall prevention level at 10 V H621 0% to 400% 0.1% 150% 120% input Output current detection...
Page 148 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments 0 to 8, 10 to 14, 16, 18, 24, 25, 28, 37 to 40, 46 STF terminal function to 48, 50, 51, 57, 58, T700 selection 60, 62, 64 to 67, 70 to 73, 77 to 81, 84, 94 to...
Page 149 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments 0 to 5, 7, 8, 10 to 19, RUN terminal function M400 25, 26, 35, 39 to 42, 45 selection to 54, 57, 64 to 68, 70 to 80, 82, 85, 90 to 96, SU terminal function 98 to 105, 107, 108,...
Page 150 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Self power management — A006 0 to 2 selection Earth (ground) fault detection — H101 0, 1 at start 0 to 100 s, 1000 to —...
Page 151 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments M410 DO0 output selection 9999 0 to 5, 7, 8, 10 to 19, 25, 26, 35, 39 to 42, 45 to 54, 57, 64 to 66, 68, M411 DO1 output selection 9999...
Page 152 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments % setting reference — N054 1 to 590 Hz 0.01 Hz 60 Hz 50 Hz frequency PLC function operation A800 0 to 2, 11, 12 selection Inverter operation lock mode A801...
Page 153 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Display/reset ABC2 relay — E707 0% to 100% 100% contact life Emergency drive dedicated — H324 0.1 to 600 s, 9999 0.1 s 9999 retry waiting time Emergency drive dedicated —...
Page 154 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Second motor speed control G942 0% to 200%, 9999 0.1% 9999 gain E301 Multiple rating setting 0, 1 — F103 Holding time at a start 0 to 10 s, 9999 0.1 s 9999...
Page 155 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments 175 to 215 VDC /350 — H102 Undervoltage level 0.1 V 9999 to 430 VDC , 9999 *10*12 — T721 X10 terminal input selection 0, 1 First free thermal reduction H001 0 to 590 Hz, 9999...
Page 156 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Power failure stop frequency — A786 0% to 200% 0.1% 100% gain SF-PR slip amount — G060 adjustment operation 2, 4, 6, 9999 9999 selection SF-PR slip amount —...
Page 157 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Second motor induced 0 to 5000 mV (rad/s), 0.1 mV C230 9999 voltage constant (phi f) 9999 (rad/s) C231 Second motor Ld decay ratio 0% to 100%, 9999 0.1% 9999 C232...
Page 158 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Deceleration time in low- — F071 0 to 3600 s, 9999 0.1 s 9999 speed range Pulse increment setting for 0.1, 1, 10, 100, 1000 —...
Page 159 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments E420 Free parameter 1 0 to 9999 9999 E421 Free parameter 2 0 to 9999 9999 Internal storage device status — H325 (0 to 9999) indication Cumulative power monitor 305,...
Page 160 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments T111 Terminal 1 bias (torque) 0% to 300% 0.1% (919) Terminal 1 gain command T112 0% to 400% 0.1% 150% (torque) (920) T113 Terminal 1 gain (torque) 0% to 300% 0.1% 100%...
Page 161 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Integral stop selection at — 1015 A607 0 to 2, 10 to 12 limited frequency PTC thermistor protection — 1016 H021 0 to 60 s detection time —...
Page 162 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Pre-charge change increment 1132 A626 0% to 100%, 9999 0.01% 9999 amount Second pre-charge change 1133 A666 0% to 100%, 9999 0.01% 9999 increment amount Second PID display bias 1136 A670...
Page 163 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Detection time for PID output 1361 A440 0 to 900 s 0.1 s hold 1362 A441 PID output hold range 0% to 50%, 9999 0.1% 9999 1363 A447...
Page 164 Minimum Initial value Refer Customer Function Name Setting range setting group to page setting increments Number of cleaning times 1469 A420 0 to 255 monitor Number of cleaning times 1470 A421 0 to 255 setting 1471 A422 Cleaning trigger selection 0 to 15 Cleaning reverse rotation 1472...
Page 165 Differs according to the capacity. 6%: FR-F820-00046(0.75K) or lower and FR-F840-00023(0.75K) or lower 4%: FR-F820-00077(1.5K) to FR-F820-00167(3.7K), FR-F840-00038(1.5K) to FR-F840-00083(3.7K) 3%: FR-F820-00250(5.5K), FR-F820-00340(7.5K), FR-F840-00126(5.5K), FR-F840-00170(7.5K) 2%: FR-F820-00490(11K) to FR-F820-01540(37K), FR-F840-00250(11K) to FR-F840-00770(37K) 1.5%: FR-F820-01870(45K), FR-F820-02330(55K), FR-F840-00930(45K), FR-F840-01160(55K) 1%: FR-F820-03160(75K) or higher and FR-F840-01800(75K) or higher The setting range or initial value for the FR-F820-02330(55K) or lower and FR-F840-01160(55K) or lower.
Page 166  Selecting a parameter by function group number to change its setting The following shows the procedure to change the setting of P.H400 (Pr.1) Maximum frequency. Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode. Changing the operation mode Press to choose the PU operation mode.
Page 167 5.1.3 Parameter list (by function group number)  E: Environment setting Refer Name group to page parameters Display estimated main circuit E705 capacitor residual life Parameters for the inverter operating environment. Display/reset ABC1 relay contact E706 Refer life Name group to page Display/reset ABC2 relay contact E707...
Page 168 Refer Refer Name Name group to page group to page Backlash deceleration stopping First free thermal reduction F202 H005 frequency frequency 3 Backlash deceleration stopping H006 Motor permissible load level F203 time 266, Second electronic thermal O/L H010 383,  D: Parameters for the setting of relay operation command and Second free thermal reduction...
Page 169 Refer Refer Name Name group to page group to page Load characteristics measurement M042 Torque monitoring reference H520 1480 mode Analog input display unit M043 Load characteristics load switchover H521 1481 reference 1 305, M044 Monitor negative output selection Load characteristics load H522 1482 reference 2...
Page 170 Refer Refer Name Name group to page group to page 290, M412 DO2 output selection T040 Terminal 4 function assignment M413 DO3 output selection Terminal 1 added compensation T041 M414 DO4 output selection amount (terminal 4) M415 DO5 output selection Terminal 4 frequency setting gain T042 Simple...
Page 171 Refer Refer Name Name group to page group to page T707 JOG terminal function selection Lq tuning target current C150 1002 adjustment coefficient T708 CS terminal function selection Starting resistance tuning T709 MRS terminal function selection C182 compensation T710 STOP terminal function selection Starting magnetic pole position T711 RES terminal function selection...
Page 172 Refer Refer Name Name group to page group to page Automatic switchover frequency 419, Detection time for PID limiting A005 range from bypass to inverter A442 1370 450, operation operation A006 Self power management selection PID upper/lower limit pre-warning A443 1371 level range Main circuit power OFF waiting...
Page 173 Refer Refer Name Name group to page group to page A694 1215 Limit cycle output upper limit A631 PID display bias analog value (934) A695 1216 Limit cycle output lower limit A696 1217 Limit cycle hysteresis A632 PID display gain coefficient A697 1218 PID gain tuning setting...
Page 174 Refer Refer Name Name group to page group to page A932 1040 Digital source selection (3ch) N051 Max Info Frames A933 1041 Digital source selection (4ch) Device instance number (Upper 3 N052 digits) A934 1042 Digital source selection (5ch) Device instance number (Lower 4 A935 1043 Digital source selection (6ch)
Page 175 Refer Refer Name Name group to page group to page Increased magnetic excitation Second motor excitation current G130 G302 deceleration operation selection low-speed scaling factor G131 Magnetic excitation increase rate G311 Speed control P gain 2 Increased magnetic excitation G312 Speed control integral time 2 G132 current level...
Page 176: Control Method
Mitsubishi Electric high-efficiency motor (SF-HR) The offline auto tuning is not required. Mitsubishi Electric constant-torque motor (SF-JRCA 4P / SF-HRCA) Mitsubishi Electric high-performance energy-saving motor (SF-PR) Other motor (Mitsubishi motor SF-TH, etc. or other manufacturer's motor) The offline auto tuning is required.
Page 177 • The motor described in the following table is used. Motor Condition Mitsubishi Electric IPM motor (MM-EFS or MM-THE4) The offline auto tuning is not required. IPM motor (other than MM-EFS or MM-THE4), SPM motor The offline auto tuning is required.
Page 178 5.2.1 Changing the control method and mode Set the control method. V/F control, Advanced magnetic flux vector control, and PM motor control are the control methods available for selection. When using an IPM motor MM-EFS or MM-THE4, simply performing the motor parameter initialization (PM parameter initialization or IPM initialization) enables PM motor control.
Page 179  PM motor test operation (Pr.800 = "9") • A test operation for speed control is available without connecting a motor to the inverter. The speed calculation changes to track the speed command, and such speed changes can be checked on the operation panel or by outputting it as analog signals to terminal FM/CA or AM.
Page 180 When the inverter operation is switched to the test operation, the accumulated thermal value is reduced because the output current is considered as 0. Parameters referred to Pr.52 Operation panel main monitor selectionpage 305 Pr.158 AM terminal function selectionpage 314  Changing the control method with external terminals (RT signal, X18 signal) •...
Page 181 Make the motor setting (Pr.71). Motor Pr.71 setting Remarks SF-JR 0 (initial value) (3, 4) SF-JR 4P 1.5 kW or lower Mitsubishi Electric standard motor Mitsubishi Electric high-efficiency motor SF-HR Others 0 (3) Offline auto tuning is required. SF-JRCA 4P...
Page 182  Keeping the motor speed constant when the load fluctuates (speed control gain) Initial Setting Name Description value range Makes adjustments to keep the motor speed constant during variable load Speed control gain 0% to 200% operation under Advanced magnetic flux vector control. The reference (Advanced magnetic flux 9999 value is 100%.
Page 183 5.2.3 Selecting the PM motor control  Setting for the PM motor control by selecting IPM initialization on the operation panel (" ") • The parameters required to drive an IPM motor MM-EFS or MM-THE4 are automatically set by batch. (Refer to page 185.) •...
Page 184  Motor parameter initialization for PM motor control (Pr.998) • Use PM parameter initialization to set the parameters required for driving an IPM motor MM-EFS or MM-THE4. • The offline auto tuning enables the operation with an IPM motor other than the MM-EFS or MM-THE4 and with SPM motors.
Page 185 NOTE • Make sure to set Pr.998 before setting other parameters. If the Pr.998 setting is changed after setting other parameters, some of those parameters are initialized too. (Refer to page 185 for the parameters that are initialized.) • To change back to the parameter settings required to drive an induction motor, perform Parameter clear or All parameter clear. •...
Page 186  List of the target parameters for the motor parameter initialization • The setting of the parameters in the following table is changed to the setting for PM motor control by performing the motor parameter initialization using IPM initialization or Pr.998 PM parameter initialization. The changed settings differ according to the specification (capacity) of the PM motor used.
Page 187 Setting Setting Induction PM motor (setting in PM motor (setting in increments motor rotations per minute) frequencies) Name 0 (initial value) 12, 14, 0, 112, 8009 8109 8009, 114, 8109, 9009 9109 9009 9109, Rated motor Subtraction starting Rated motor 60 Hz 50 Hz rotations per...
Page 188  IPM motor specification list MM-EFS 1500 r/min spec. MM-EFS 1500 r/min spec. Item MM-THE4 (75 to 160 kW) (15 kW or lower) (18.5 to 55 kW)) Rated motor frequency (rotations per minute) 75 Hz (1500 r/min) 100 Hz (1500 r/min) 75 Hz (1500 r/min) Maximum motor frequency (rotations per minute) 112.5 Hz (2250 r/min)
Page 189: Speed Control Under Pm Motor Control
Speed control under PM motor control Refer Purpose Parameter to set to page Pr.820, Pr.821, Pr.824, To adjust the gain for PM motor Speed control gain P.G211 to P.G214, P.G311 to Pr.825, Pr.830, Pr.831, control adjustment P.G314 Pr.834, Pr.835 Torque detection To stabilize torque feedback signal P.G216, P.G316 Pr.827, Pr.837...
Page 190  Driving a PM motor other than the MM-EFS or MM-THE4 Operating procedure Motor settings (Pr.9, Pr.71, Pr.80, Pr.81, Pr.83, and Pr.84) (Refer to page 379, page 392.) Set "8093 (IPM motor other than MM-EFS or MM-THE4) or 9093 (SPM motor)" in Pr.71 Applied motor. Set Pr.9 Rated motor current, Pr.80 Motor capacity, Pr.81 Number of motor poles, Pr.83 Rated motor voltage, and Pr.84 Rated motor frequency according to the motor specifications.
Page 191 5.3.2 Performing high-accuracy, fast-response control (gain adjustment for PM motor control) Manual gain adjustment is useful for achieving optimum machine performance or improving unfavorable conditions, such as vibration and acoustic noise during operation with high load inertia or gear backlash. Initial Setting Name...
Page 192  Adjustment procedure Change the Pr.820 setting while checking the conditions. If it cannot be adjusted well, change Pr.821 setting, and perform step again. Movement / condition Adjustment method Set Pr.820 and Pr.821 higher. If acceleration is slow, raise the setting by 10% and then set the value to 80% to 90% of the Pr.820 Load inertia is too high.
Page 193 5.3.3 Troubleshooting in the speed control Condition Possible cause Countermeasure Speed command from the controller is different from the • Check that the speed command sent from the controller is correct. actual speed. (Take EMC measures.) Motor does not run at the The speed command is •...
Page 194 5.3.4 Torque detection filter Set the time constant of primary delay filter torque feedback signal. Speed loop response is reduced. Under ordinary circumstances, therefore, use the initial value as it is. Initial Setting Name Description value range Without filter Torque detection filter 1 G216 0.001 to 0.1 s Set the time constant of primary delay filter torque feedback signal.
Page 195: (E) Environment Setting Parameters
(E) Environment setting parameters Refer to Purpose Parameter to set page Pr.1006 to To set the time Real time clock function P.E020 to P.E022 Pr.1008 To set a limit for the reset function. Reset selection/ To shut off output if the operation panel disconnected PU P.E100 to P.E102, disconnects.
Page 196 5.4.1 Real time clock function The time can be set. The time can only be updated while the inverter power is ON. The real time clock function is enabled using an optional LCD operation panel (FR-LU08). Name Initial value Setting range Description 1006 Clock (year)
Page 197 5.4.2 Reset selection / disconnected PU detection / PU stop selection The acceptance of reset command, the inverter operation in the event of detection of the PU (operation panel / parameter unit) disconnected, and the acceptance of stop command from the PU (PU stop function) can be selected using Pr.E100 (Reset selection), Pr.E101 (Disconnected PU detection), and Pr.E102 (PU stop selection), respectively, or using Pr.75 alone.
Page 198 Operation after PU Pr.75 setting Reset input disconnection is PU stop function Reset limit function detected Always enabled. Operation continues. Disabled Disabled When the protective function is activated. Operation continues. Disabled Disabled Always enabled. Inverter output shutoff. Disabled Disabled When the protective function is activated. Inverter output shutoff. Disabled Disabled 14 (initial...
Page 199 NOTE • When the RES signal is input during operation, the motor coasts since the inverter being reset shuts off the output. Also, the cumulative value of the electronic thermal relay is cleared. • When "reset input always enabled" is selected, the reset key on the PU is enabled only when the protective function is activated.
Page 200  How to restart the inverter which has been stopped in the External operation mode by using on the PU ("PS" (PU stop) warning reset method) • For the operation panel (FR-DU08) After completion of deceleration stop, turn OFF the STF and STR signals. Press three times ("...
Page 201 5.4.3 PU display language selection You can switch the display language of the parameter unit (FR-PU07) to another. Name Initial value Setting range Description Japanese English German French PU display language — E103 selection Spanish Italian Swedish Finnish 5.4.4 Buzzer control The PU (operation panel or parameter unit) key sound and buzzer can be turned ON/OFF.
Page 202 5.4.7 Direct setting The PID set point setting screen (direct setting screen) can be displayed first on the LCD operation panel (FR-LU08) according to the parameter setting. Name Initial value Setting range Description Displays the Frequency setting screen. 1000 Displays the direct setting screen (for set point setting). Direct setting selection E108 Displays the direct setting screen (for set point setting)
Page 203 5.4.9 Easy frequency setting (Volume-knob-like setting) and key lock function selection The frequency can be easily set with the setting dial on the operation panel (FR-DU08) like a volume knob. The key operation of the operation panel can be disabled. Name Initial value Setting range...
Page 204 5.4.10 Frequency change increment amount setting When setting the set frequency with the setting dial of the operation panel (FR-DU08), the frequency changes in 0.01 Hz increments in the initial status. Setting this parameter to increase the frequency increment amount that changes when the setting dial is rotated can improve usability.
Page 205 5.4.11 Multiple rating setting Two rating types of different rated current and permissible load can be selected. The optimal inverter rating can be chosen in accordance with the application, enabling equipment size to be reduced. (The setting is available for the standard structure model or the separated converter type.) Initial value Name...
Page 206 5.4.12 Using a power supply exceeding 480 VAC To input a voltage between 480 VAC and 500 VAC to the 400 V class inverter, change the voltage protection level. Setting Name Initial value Description range 400 V class voltage protection level Input voltage mode 500 V class voltage protection level E302...
Page 207 5.4.13 Parameter write selection Whether to enable the writing to various parameters or not can be selected. Use this function to prevent parameter values from being rewritten by misoperation. Name Initial value Setting range Description Parameter write is enabled only during stop. Parameter writing is disabled.
Page 208  Parameter write disabled (Pr.77 = "1") • Parameter write, Parameter clear, and All parameter clear are disabled. (Parameter read is enabled.) • The following parameters can be written even if Pr.77 = "1". Name Stall prevention operation level Password lock/unlock Reset selection/Disconnected PU detection/PU 345, 346 (DeviceNet communication)
Page 209 5.4.14 Password Registering a 4-digit password can restrict access to parameters (reading/writing). Name Initial value Setting range Description Password protection enabled. Setting the access 0 to 6, 99, 100, (reading/writing) restriction level to parameters locked 106, 199 Password lock level 9999 with a password enables writing to Pr.297.
Page 210  Locking parameters with a password (Pr.296, Pr.297) • The procedure of locking parameters with a password is as follows. Set the parameter reading/writing restriction level to enable the password protection. (Set a value other than "9999" in Pr.296.) Allowable number of failed password Pr.296 setting Pr.297 readout attempts...
Page 211  Access to parameters according to the password status Password protection disabled / Parameters Parameters locked Password locked up unlocked Parameter Pr.296 = "9999", Pr.296 ≠ "9999", Pr.296 ≠ "9999", Pr.296 = "100 to 106, 199" Pr.297 = "9999" Pr.297 = "9999" Pr.297 = "0 to 4"...
Page 212 5.4.16 Setting multiple parameters by batch The setting of particular parameters is changed by batch, such as communication parameters for connection with the Mitsubishi Electric human machine interface (GOT), the parameters for the rated frequency (50/60 Hz) setting, or the parameters for acceleration/deceleration time increment.
Page 213  PID monitor indicator setting (Pr.999 = "1 or 2") Name Initial value Pr.999 = "1" Pr.999 = "2" Refer to page PID unit selection 9999 9999 1142 Second PID unit selection 9999 9999 Operation panel monitor selection 1 9999 9999 Operation panel monitor selection 2 9999...
Page 214  Initial setting with the GOT2000 series • When "FREQROL 500/700/800, SENSORLESS SERVO" is selected for "Controller Type" in the GOT setting, set Pr.999 = "10" to configure the GOT initial setting. • When "FREQROL 800 (Automatic Negotiation)" is selected for "Controller Type" in the GOT setting, the GOT automatic connection can be used.
Page 215  Rated frequency (Pr.999 = "20" (50 Hz) or "21" (60 Hz)) Initial value Name Pr.999 = "21" Pr.999 = "20" Refer to page FM type CA type Base frequency 60 Hz 50 Hz 60 Hz 50 Hz Multi-speed setting (high speed) 60 Hz 50 Hz 60 Hz...
Page 216 5.4.17 Extended parameter display and user group function This function restricts the parameters that are read by the operation panel and parameter unit. Initial value Name Setting range Description 9999 Only simple mode parameters are displayed. User group read 9999 Displays simple mode and extended parameters.
Page 217  Registering a parameter in a user group (Pr.173) • To register Pr.3 in a user group Operating procedure Power ON Make sure the motor is stopped. Changing the operation mode Press to choose the PU operation mode. [PU] indicator turns ON. Selecting the parameter setting mode Press to choose the parameter setting mode.
Page 218  Clearing a parameter from a user group (Pr.174) • To delete Pr.3 from a user group. Operating procedure Power ON Make sure the motor is stopped. Changing the operation mode Press to choose the PU operation mode. [PU] indicator turns ON. Selecting the parameter setting mode Press to choose the parameter setting mode.
Page 219 5.4.18 PWM carrier frequency and Soft-PWM control The motor sound can be changed. Initial Setting Name Description value range The PWM carrier frequency can be changed. The setting value 0 to 15 represents the frequency in kHz. However, "0" indicates 0.7 kHz, "15" PWM frequency selection 2 E600 indicates 14.5 kHz, and "25"...
Page 220  Soft-PWM control (Pr.240) • Soft-PWM control is a function that changes the motor noise from a metallic sound into an inoffensive, complex tone. • Setting Pr.240 = "1" will enable the Soft-PWM control. • To enable the Soft-PWM control, set Pr.72 to 5 kHz or less for the FR-F820-02330(55K) or lower or the FR-F840- 01160(55K) or lower.
Page 221 5.4.19 Inverter parts life display The degree of deterioration of the control circuit capacitor, main circuit capacitor, cooling fan, inrush current limit circuit, and relay contacts of terminals A, B, and C can be diagnosed on the monitor. When a part approaches the end of its life, an alarm can be output by self diagnosis to prevent a fault.
Page 222 • When the parts have reached the life alarm output level, the corresponding bits of Pr.255 turns ON. The ON/OFF state of the bits can be checked with Pr.255. The following table shows examples. Pr.255 bit 7 bit 6 bit 5 bit 4 bit 3 bit 2...
Page 223  Life display of the main circuit capacitor (Pr.258, Pr.259) (Standard models and IP55 compatible models) • For accurate life measurement of the main circuit capacitor, wait three hours or longer after turning OFF. The temperature left in the main circuit capacitor affects measurement. •...
Page 224 WARNING • When measuring the main circuit capacitor capacity (Pr.259 = "1 or 11"), the DC voltage is applied to the motor for about 1 second at power OFF. Never touch the motor terminal, etc. right after powering OFF to prevent an electric shock. ...
Page 225 5.4.20 Maintenance timer alarm The Maintenance timer (Y95) signal is output when the inverter's cumulative energization time reaches the time period set with the parameter. MT1, MT2 or MT3 is displayed on the operation panel. This can be used as a guideline for the maintenance time of peripheral devices.
Page 226 5.4.21 Current average value monitor signal The output current average value during constant-speed operation and the maintenance timer value are output to the Current average monitor (Y93) signal as a pulse. The output pulse width can be used in a device such as the I/O unit of a programmable controller as a guideline for the maintenance time for mechanical wear, belt stretching, or deterioration of devices with age.
Page 227  Pr.555 Current average time setting • The output current average is calculated during start pulse (1 second) HIGH output. Set the time for calculating the average current during start pulse output in Pr.555.  Pr.557 Current average value monitor signal output reference current setting Set the reference (100%) for outputting the output current average value signal.
Page 228 NOTE • Masking of the data output and sampling of the output current are not performed during acceleration/deceleration. • If constant speed changes to acceleration or deceleration during start pulse output, it is judged as invalid data, and the signal maintains HIGH start pulse output for 3.5 seconds and LOW end pulse output for 16.5 seconds.
Page 229: (F) Setting Of Acceleration/Deceleration Time And Acceleration/Deceleration Pattern
(F) Setting of acceleration/deceleration time and acceleration/deceleration pattern Purpose Parameter to set Refer to page Pr.7, Pr.8, P.F000 to P.F003, Pr.16, Pr.20, To set the motor acceleration/ P.F010, P.F011, Pr.21, Pr.44, Acceleration/deceleration time deceleration time P.F020 to P.F022, Pr.45, Pr.147, P.F070, P.F071 Pr.611, Pr.791, Pr.792...
Page 230 Initial value Name Setting range Description Set the deceleration time in a low-speed range (less than 1/10 of the 0 to 3600 s Deceleration time rated motor frequency). in low-speed 9999 F071 The deceleration time set in Pr.8 is applied. (While the RT signal is range 9999 ON, the second function is enabled.)
Page 231 NOTE • If the acceleration/deceleration time is set, the actual motor acceleration/deceleration time cannot be made shorter than the shortest acceleration/deceleration time determined by the mechanical system J (moment of inertia) and motor torque. • If the Pr.20 setting is changed, the Pr.125 and Pr.126 (frequency setting signal gain frequency) settings do not change. Set Pr.125 and Pr.126 to adjust the gains.
Page 232 NOTE • The reference frequency during acceleration/deceleration depends on the setting of Pr.29 Acceleration/deceleration pattern selection. (Refer to page 231.) • The RT signal can be assigned to an input terminal by setting Pr.178 to Pr.189 (Input terminal function selection). Changing the terminal assignment may affect other functions.
Page 233  Linear acceleration/deceleration (Pr.29 = "0 (initial value)") • When the frequency is changed for acceleration, deceleration, etc. during inverter operation, the output frequency is changed linearly (linear acceleration/deceleration) to reach the set frequency without straining the motor and inverter. Linear acceleration/deceleration has a uniform frequency/time slope.
Page 234 NOTE • When the RT signal turns ON during acceleration or deceleration with the S-pattern acceleration/deceleration B enabled, a pattern of acceleration or deceleration changes to linear at the moment.  Backlash measures (Pr.29 = "3", Pr.140 to Pr.143) • Reduction gears have an engagement gap and have a dead zone between forward rotation and reverse rotation. This dead zone is called backlash, and this gap disables a mechanical system from following motor rotation.
Page 235 5.5.3 Remote setting function Even if the operation panel is located away from the enclosure, contact signals can be used to perform continuous variable- speed operation, without using analog signals. Description Initial Setting Name RH, RM, RL signal Frequency setting Deceleration to the value range...
Page 236  Acceleration/deceleration operation • The running frequency changes as follows when the set frequency is changed by the remote setting function. Frequency Time setting Description Set frequency Pr.44/Pr.45 The set frequency increases/decreases by remote setting according to the Pr.44/Pr.45 setting. Running frequency Pr.7/Pr.8 The running frequency increases/decreases by the set frequency according to the Pr.7/Pr.8 setting.
Page 237 NOTE • When switching the start signal from ON to OFF, or changing frequency by the RH or RM signal frequently, set the frequency setting value storage function (write to EEPROM) invalid (Pr.59 = "2, 3, 12, 13"). If the frequency setting value storage function is valid (Pr.59 = "1, 11"), the frequency is written to EEPROM frequently, and this will shorten the life of the EEPROM.
Page 238 • When the remotely-set frequency is cleared by turning ON the RL (clear) signal after turning OFF (ON) both the RH and RM signals, the inverter operates at the frequency in the remotely-set frequency cleared state if power is reapplied before one minute has elapsed since turning OFF (ON) both the RH and RM signals.
Page 239 5.5.4 Starting frequency and start-time hold function Magnetic flux Magnetic flux Magnetic flux It is possible to set the starting frequency and hold the set starting frequency for a certain period of time. Set these functions when a starting torque is needed or the motor drive at start needs smoothing. Name Initial value Setting range...
Page 240 5.5.5 Minimum motor speed frequency at the motor start Set the frequency where the PM motor starts running. Set the deadband in the low-speed range to eliminate noise and offset deviation when setting a frequency with analog input. Name Initial value Setting range Description Minimum...
Page 241: 5.6 (D) Operation Command And Frequency Command
(D) Operation command and frequency command Purpose Parameter to set Refer to page To select the operation mode Operation mode selection P.D000 Pr.79 To start up the inverter in Network operation Communication startup P.D000, P.D001 Pr.79, Pr.340 mode at power-ON mode selection Operation and speed command sources during...
Page 242 LED indicator Pr.79 Refer to Description : OFF setting page : ON PU operation mode External operation External/PU switchover mode. mode 0 (initial The inverter operation mode can be switched between PU and External by pressing value) At power ON, the inverter is in the External operation mode. NET operation mode Operation mode...
Page 243  Operation mode basics • The operation mode specifies the source of the start command and the frequency command for the inverter. • Basic operation modes are as follows. External operation mode: For giving a start command and a frequency command with an external potentiometer or switches which are connected to the control circuit terminal.
Page 244  Operation mode switching method External operation When "0, 1, or 2" is set in Pr. 340 Switching with the PU Switching through the network Press Switch to External operation mode through the PU to light Press Switch to the Network operation the network.
Page 245  Operation mode selection flow Referring to the following table, select the basic parameter settings or terminal wiring related to the operation mode. Method to give Method to give frequency setting Input interface Parameter setting Operation method start command command Terminal STF (forward Using external signals •...
Page 246  External operation mode (Pr.79 = "0 (initial value) or 2") • Select the External operation mode when the start command and the frequency command are applied from a frequency setting potentiometer, start switch, etc. which are provided externally and connected to the control circuit terminals of the inverter.
Page 247 Inverter Operation panel (FR-DU08) Forward rotation start Reverse rotation start Switch  PU/External combined operation mode 2 (Pr.79 = "4") • Select the PU/External combined operation mode 2 when giving a frequency command from the external potentiometer, or using the multi-speed setting signals or the JOG signal, and giving a start command by key operation of the operation panel or the parameter unit.
Page 248  PU operation interlock (Pr.79 = "7") • The operation mode can be forcibly switched to the External operation mode by turning OFF the PU operation external interlock (X12) signal. This function will be usable in a case where the inverter does not reply to external command signals during operation due to the operation mode accidentally unswitched from the PU operation mode to the External operation mode.
Page 249  Switching operation mode by external signal (X16 signal) • When External operation and the operation from the operation panel are used together, the PU operation mode and External operation mode can be switched during a stop (during motor stop, start command OFF) by using the PU/External operation switchover (X16) signal.
Page 250 When the X16 signal is OFF, the PU operation mode is selected. Also, when "0" is set for Pr.550 NET mode operation command source selection and the communication option is not connected (communication option is the command source), the PU operation mode is selected. When the X16 signal is ON, the External operation mode is selected.
Page 251 5.6.2 Startup of the inverter in Network operation mode at power-ON When power is switched ON or when power comes back ON after an instantaneous power failure, the inverter can be started up in the Network operation mode. After the inverter starts up in the Network operation mode, parameter writing and operation can be commanded from programs. Set this mode when performing communication operation using the RS-485 terminals or a communication option.
Page 252 Parameters referred to Pr.57 Restart coasting timepage 466, page 472 Pr.79 Operation mode selectionpage 240 5.6.3 Start command source and frequency command source during communication operation The start and frequency commands given from an external device can be made valid when using the RS-485 terminals or the communication option.
Page 253 NOTE • When Pr.550 = "1" (NET mode RS-485 terminals) and Pr.551 ="1" (PU mode RS-485 terminals), the PU operation mode has a precedence. For this reason, if the communication option is not mounted, switching to the Network operation mode is no longer possible.
Page 254  Controllability through communication Controllability in each operation mode Conditions Combined Combined Command NET operation (Pr.551 Item External operation operation NET operation interface (via RS-485 setting) operation operation mode 1 mode 2 (via option) terminals) (Pr.79 = "3") (Pr.79 = "4") Operation (start) ○...
Page 255 Controllability in each operation mode Conditions Combined Combined Command NET operation (Pr.551 Item External operation operation NET operation interface (via RS-485 setting) operation operation mode 1 mode 2 (via option) terminals) (Pr.79 = "3") (Pr.79 = "4") Inverter reset ○ ○...
Page 256  Selecting the command interface in the Network operation mode (Pr.338, Pr.339) • Selecting a command interface is required for the following two types of commands: the operation command using the start signals and the signals related to the inverter function selection, and the speed command using signals related to the frequency setting.
Page 257 Pr.338 Communication operation command 0: NET 1: EXT source Remarks Pr.339 Communication speed command source *When Pr.414 = "1", the interface used for signal input is enabled. Sequence start EXT or NET When Pr.414 = "2", External is enabled. Fault clear Combined JOG forward rotation command —...
Page 258  Changing the command interface using a signal input via external terminal (X67 signal) • In the Network operation mode, the command interface for the operation command and the speed command can be changed using the Command source switchover (X67) signal. This method may be useful to use both external terminal and communication interface by using a different interface according to the command type.
Page 259 5.6.5 Frequency setting using pulse train input A pulse train input via terminal JOG can be used to set the inverter's speed command. Moreover, speed synchronized operation of an inverter can be performed by using the pulse train input and output together. Initial value Description Name...
Page 260 • Connection with a complementary output system pulse generator Sink logic Source logic Inverter Inverter 2 kΩ 24 V power 24 V power 2 kΩ NOTE • When pulse train input is selected, the function assigned to terminal JOG using Pr.185 JOG terminal function selection is disabled.
Page 261 NOTE • The priority of the frequency command given by the external signals is as follows: JOG operation > multi-speed operation > terminal 4 analog input > pulse train input. When pulse train input is enabled (Pr.291 = "1, 11, 21, or 100" and Pr.384 ≠ "0"), terminal 2 analog input becomes disabled.
Page 262 5.6.6 JOG operation The frequency and acceleration/deceleration time for JOG operation can be set. JOG operation is possible in both External operation and PU. JOG operation can be used for conveyor positioning, test operation, etc. Initial Name Setting range Description value Jog frequency 5 Hz...
Page 263 NOTE • The reference frequency during acceleration/deceleration depends on the Pr.29 Acceleration/deceleration pattern selection setting. (Refer to page 231.) • The Pr.15 setting should be equal to or higher than the Pr.13 Starting frequency setting. • Changing the terminal assignment using Pr.178 to Pr.189 (Input terminal function selection) may affect the other functions. Set parameters after confirming the function of each terminal.
Page 264 5.6.7 Operation by multi-speed setting Use these parameters to change among pre-set operation speeds with the terminals. The speeds are pre-set with parameters. Any speed can be selected by simply turning ON/OFF the contact signals (RH, RM, RL, and REX signals). Initial value Name Setting range...
Page 265  Multi-speed setting for 4th speed or more (Pr.24 to Pr.27, Pr.232 to Pr.239) • The frequency from 4th speed to 15th speed can be set according to the combination of the RH, RM, RL, and REX signals. Set the frequencies in Pr.24 to Pr.27, Pr.232 to Pr.239. (In the initial status, 4th to 15th speeds are invalid.) •...
Page 266 NOTE • The priority of the frequency commands given by the external signals is as follows: JOG operation > multi-speed operation > terminal 4 analog input > pulse train input > terminal 2 analog input. (For details on frequency commands given by analog input, refer to page 357.)
Page 267: (H) Protective Function Parameter
(H) Protective function parameter Purpose Parameter to set Refer to page P.H000, P.H006, Pr.9, Pr.51, Pr.561, To protect the motor from overheating Electronic thermal O/L relay P.H010, P.H016, Pr.607, Pr.608, P.H020, P.H021 Pr.1016 To set the overheat protection P.H001 to P.H005, Pr.600 to Pr.604, Free thermal O/L relay characteristics for the motor...
Page 268 (Note that the output transistor protection of the inverter is activated. (E.THT)) • When using the Mitsubishi Electric constant-torque motor, set Pr.71 Applied motor = "1, 13 to 16, 50, 53, or 54". (This setting enables the 100% constant-torque characteristic in the low-speed range.) Pr.9 = 50% setting...
Page 269 The % value denotes the percentage to the rated inverter current. It is not the percentage to the rated motor current. When the electronic thermal O/L relay of the Mitsubishi Electric constant-torque motor is set, the characteristic curve is as shown in this diagram at 6 Hz or higher.
Page 270 NOTE • The internal accumulated heat value of the electronic thermal relay function is reset to the initial value by the inverter's power reset or reset signal input. Avoid unnecessary reset and power-OFF. • When using a PM motor other than MM-CF, set the free thermal parameters (Pr.600 to Pr.604) in accordance with the motor characteristic.
Page 271  Acceleration time setting (Pr.607, Pr.608) The electronic thermal O/L relay operation characteristic can be changed by setting the permissible load level according to the motor characteristics. Motor permissible load 150% (Initial value) Motor permissible load 110% Range for the transistor protection Inverter output power (%) (% to the inverter rated current)
Page 272 NOTE • Changing the terminal assignment using Pr.178 to Pr.189 (Input terminal function selection) may affect the other functions. Set parameters after confirming the function of each terminal.  PTC thermistor input (Pr.561, Pr.1016, E.PTC) This function is used to protect the motor from overheating by inputting outputs from the motor's built-in PTC thermistor to the inverter.
Page 273 NOTE • When using terminal 2 for PTC thermistor input (Pr.561 ≠ "9999"), the terminal 2 does not operate as an analog frequency command terminal. The PID and dancer control functions assigned to the terminal 2 is also disabled. Use Pr.133 PID action set point to set the set point for the PID function.
Page 274 5.7.2 Cooling fan operation selection A cooling fan is built into the inverter and its operation can be controlled. Name Initial value Setting range Description Cooling fan ON/OFF control disabled. (The cooling fan is always ON at power ON.) A cooling fan operates at power ON. Cooling fan ON/OFF control enabled.
Page 275  Cooling fan operation command (Y206) signal • The Cooling fan operation command (Y206) signal can be output when the inverter cooling fan meets the conditions for running. The function can be used when the fan installed on the enclosure is synchronized with the inverter cooling fan. •...
Page 276 5.7.4 Varying the activation level of the undervoltage protective function If the undervoltage protection (E.UVT) activates due to unstable voltage in the power supply, the undervoltage level (DC bus voltage value) can be changed. Name Initial value Setting range Description 175 to 215 VDC Set the DC voltage value at which E.UVT occurs.
Page 277 5.7.6 I/O phase loss protection selection The output phase loss protection function, which stops the inverter output if one of the three phases (U, V, W) on the inverter's output side (load side) is lost, can be disabled. The input phase loss protective function on the inverter input side (R/L1, S/L2, T/L3) can be enabled. Name Initial value Setting range...
Page 278 • The retry function is enabled when the Pr.67 setting is other than "0". Set the number of retries at activation of the protective function in Pr.67. Fault output during retry Pr.67 setting Retry count operation — No retry function 1 to 10 Not available 1 to 10 times...
Page 279 NOTE • Use the retry function only when the operation can be resumed after resetting a protective function activation. Making a retry against the protective function, which is activated by an unknown condition, will lead the inverter and motor to be faulty. Identify and remove the cause of the protective function activation before restarting the operation.
Page 280 5.7.8 Emergency drive (Fire mode) This function is used in case of emergency such as a fire to forcibly continue inverter operation to drive a motor without activating protective functions even if the inverter detects a fault. Using this function may cause damage of the motor or the inverter because driving the motor is given the highest priority.
Page 281  Connection diagram • The following diagram shows a connection example for emergency drive operation (in the commercial mode). MCCB R/L1 S/L2 T/L3 Emergency drive in operation Emergency drive execution Fault output during emergency drive ALM3 Inverter/bypass Reset 24VDC Be careful of the capacity of the sequence output terminals. The applied terminals differ by the settings of Pr.190 to Pr.196 (Output terminal function selection).
Page 282 • To return to the normal operation during emergency drive operation, do the following. (The operation will not be returned to normal only by turning OFF the X84 signal.) Reset the inverter, or turn OFF the power supply. Clear a fault by turning ON the X51 signal while the sequence function is enabled (when the protective function is activated).
Page 283 • The following diagram shows the operation of switching over to the commercial power supply operation during emergency drive operation by using the CS signal (when the electronic bypass during emergency drive operation is enabled) (in the commercial mode or in the fixed frequency mode (Pr.523 = "411")). Emergency drive continued Power supply Command...
Page 284  Emergency drive operation selection (Pr.523, Pr.524) • Use Pr.523 Emergency drive mode selection to select the emergency drive operation. Set a value in the hundreds place to select the operation when a valid protective function is activated (critical fault) during emergency drive. Set values in the ones and tens places to select the operation method.
Page 285  Electronic bypass during emergency drive (Pr.136, Pr.139, Pr.57) • For selecting the commercial mode (Pr.523 = "3[][], 4[][]"), setting is required as follows. Set Pr.136 MC switchover interlock time and Pr.139 Automatic switchover frequency from inverter to bypass operation and assign MC2 and MC3 signals to output terminals. When the CS signal is assigned to an input terminal, set Pr.57 Restart coasting time ≠...
Page 286  PID control during emergency drive operation • The Pr.524 setting is used as a set point for operation during emergency drive operation in the PID control mode. Input the measured values in the method set in Pr.128 or Pr.753. •...
Page 287 • The fault output during emergency drive operation is as follows. Pr.190 to Pr.196 setting Signal Description Positive Negative logic logic Turns ON at the occurrence of a fault that causes the above-mentioned "retry" or "output shutoff" during emergency drive operation. Output when a fault occurs during emergency drive operation.
Page 288 5.7.9 Checking faulty area in the internal storage device When E.PE6 (Internal storage device fault) occurs, faulty area in the internal storage device can be checked by reading Pr.890. When the read value of Pr.890 is "7" or smaller, an inverter reset after All parameter clear can return the operation to normal. (The parameters that had been changed before All parameter clear must be set again.) Name Initial value...
Page 289  Setting the minimum frequency (Pr.2) • Set Pr.2 Minimum frequency to the lower limit of the output frequency. • If the set frequency is Pr.2 or less, the output frequency is clamped at Pr.2 (does not fall below Pr.2). NOTE •...
Page 290 5.7.11 Avoiding machine resonance points (frequency jump) When it is desired to avoid resonance attributable to the natural frequency of a mechanical system, these parameters allow resonant frequencies to be jumped. Name Initial value Setting range Description Frequency jump 1A H420 Frequency jump 1B H421...
Page 291  6-point frequency jump (Pr.552) • A total of six jump areas can be set by setting the common jump range for the frequencies set in Pr.31 to Pr.36. • When frequency jump ranges overlap, the lower limit of the lower jump range and the upper limit of the upper jump range are used.
Page 292 Initial value Name Setting range Description Stall prevention operation disabled. Stall prevention 120% 110% Set the current limit at which the stall prevention operation H500 operation level 0.1% to 400% starts. Stall prevention Enable/disable the stall prevention operation and the fast- 0 to 31, 100, 101 H501 operation selection...
Page 293  Setting of stall prevention operation level (Pr.22) • For Pr.22 Stall prevention operation level, set the ratio Output current of the output current to the inverter's rated current at which Pr.22 the stall prevention operation is activated. Normally, use this parameter in the initial setting.
Page 294  Disabling the stall prevention operation and fast-response current limit according to operating conditions (Pr.156) • Referring to the following table, enable/disable the stall prevention operation and the fast-response current limit operation, and also set the operation at OL signal output. Stall prevention operation selection Fast-response OL signal output...
Page 295  Adjusting the stall prevention operation signal and output timing (OL signal, Pr.157) • If the output current exceeds the stall prevention operation level and stall prevention is activated, Overload warning (OL) signal turns ON for 100 ms or more. The output signal turns OFF when the output current falls to the stall prevention operation level or less.
Page 296  Setting multiple stall prevention operation levels (Pr.48, Pr.49) Magnetic flux Magnetic flux Magnetic flux • Setting Pr.49 Second stall prevention operation frequency = "9999" and turning ON the RT signal enables Pr.48 Second stall prevention operation level. • For Pr.48, set the stall prevention operation level that is effective in the output frequency range between 0 Hz and Pr.49. However, the operation level is Pr.22 during acceleration.
Page 297  Stall prevention operation level setting (analog variable) from terminal 1 (terminal 4) (Pr.148, Pr.149, Pr.858, Pr.868) Magnetic flux Magnetic flux Magnetic flux • To use the terminal 1 (analog voltage input) to set the stall prevention operation level, set Pr.868 Terminal 1 function assignment = "4".
Page 298  Trip during stall prevention operation (Pr.874) • The inverter can be set to trip at activation of stall prevention and stalling of the motor. • When a high load is applied and the stall prevention is activated, the motor stalls. At this time, if a state where the motor rotation speed is lower than 1.5 Hz and the output torque exceeds the level set in Pr.874 OLT level setting continues for 3 seconds, the stall prevention stop (E.OLT) is activated and the inverter output is shut off.
Page 299 5.7.13 Load characteristics fault detection This function is used to monitor whether the load is operating in normal condition by storing the speed/torque relationship in the inverter to detect mechanical faults or for maintenance. When the load operating condition deviates from the normal range, the protective function is activated or the warning is output to protect the inverter or the motor.
Page 300  Load characteristics reference setting (Pr.1481 to Pr.1487) • Use Pr.1481 to Pr.1485 to set the reference value of load characteristics. • Use Pr.1486 Load characteristics maximum frequency and Pr.1487 Load characteristics minimum frequency to set the output frequency range for load fault detection. Upper limit warning detection width Load status (Pr.1488)
Page 301 • Setting "8888" in Pr.1481 to Pr.1485 enables fine adjustment of load characteristics. When "8888" is set to Pr.1481 to Pr.1485 during operation, the load status at that point is set in the parameter. (Only when the set frequency is within ±2 Hz of the frequency of the measurement point, and SU signal is in the ON state.) Example of starting measurement from the stop state Frequency(Hz)
Page 302  Load fault detection setting (Pr.1488 to Pr.1491) • When the load is deviated from the detection width set in Pr.1488 Upper limit warning detection width, the Upper limit warning detection (LUP) signal is output. When the load is deviated from the detection width set in Pr.1489 Lower limit warning detection width, the Lower limit warning detection (LDN) signal is output.
Page 303 Load(%) Frequency(Hz) NOTE • When the load reference is not set for five points, the load characteristics value is determined by linear interpolation of the set load reference values only. If there is only one load reference setting, the set load reference is used as the load reference all through the range.
Page 304: (M) Item And Output Signal For Monitoring
(M) Item and output signal for monitoring Refer to Purpose Parameter to set page To display the motor speed (the number of rotations per minute) Speed indication and its To switch the unit of measure to set the setting change to P.M000 to P.M002 Pr.37, Pr.144, Pr.505 operation speed from frequency to motor...
Page 305 The maximum value of the setting range differs according to the Pr.1 Maximum frequency, Pr.505 Speed setting reference, and it can be calculated from the following formula. The maximum value of Pr.37 < 65535 × Pr.505 / Pr.1 setting value (Hz). The maximum setting value of Pr.37 is 9998 if the result of the above formula exceeds 9998.
Page 306 Parameters referred to Pr.1 Maximum frequencypage 287 Pr.52 Operation panel main monitor selectionpage 305 Pr.81 Number of motor polespage 177 Pr.800 Control method selectionpage 177 5.8.2 Monitor item selection on operation panel or via communication The monitor item to be displayed on the operation panel or the parameter unit can be selected. Name Initial value Setting range...
Page 307  Monitor item list (Pr.52, Pr.774 to Pr.776, Pr.992) • Use Pr.52, Pr.774 to Pr.776, or Pr.992 to select the item to monitor on the operation panel or the parameter unit. • Refer to the following table to find the setting value for each monitoring. The value in the Pr. setting column is set in each of the parameters for monitoring (Pr.52, Pr.774 to Pr.776, and Pr.992) to determine the monitored item.
Page 308 Negative Increment MODBUS Monitor item RS-485 indication Description and unit setting PLC function user The user-designated monitor item is displayed using the 40240 monitor 1 PLC function. Increment set Each value of the following special registers is displayed. PLC function user 40241 in the register SD1216: displayed with the setting value "40"...
Page 309 Negative Increment MODBUS Monitor item RS-485 indication Description and unit setting PID input pressure Displays the input pressure value of the PID input 0.1% 40269 value pressure control function. 32-bit cumulative 1 kWh — 40277 energy (lower 16 bits) The upper or lower 16 bits of the 32-bit cumulative energy is displayed on each indication.
Page 310 *11 The details of bits for the input terminal status are as follows. (1: ON state, 0: OFF state of a terminal on the inverter. "—" denotes an indefinite (null) value.) (STOP) *12 The details of bits for the output terminal status are as follows. (1: ON state, 0: OFF state of a terminal on the inverter. "—" denotes an indefinite (null) value.) So (SO) ABC2...
Page 311 NOTE • On the operation panel (FR-DU08), the "Hz" unit indicator is lit while displaying the output frequency, the "Hz" blinks when displaying the set frequency.  Displaying the set frequency during stop (Pr.52) • When Pr.52 = "100", the set frequency is displayed during stop, and output frequency is displayed during running. (LED of Hz blinks during stop and is lit during operation.) Pr.52 setting Status...
Page 312 • On the I/O terminal monitor, the upper LEDs indicate the input terminal status, and the lower LEDs indicate the output terminal status. STP (STOP) Segments corresponding to input terminals - Display example - When signals STF, RH and RUN are on The center LED segments are always ON.
Page 313 NOTE • When Pr.170 is read just after "0" has been written in Pr.170, the setting "9999" or "10" is displayed.  Monitoring cumulative energization time (Pr.563) • When the cumulative energization time is selected as a monitor item (Pr.52 = "20"), the counter of cumulative energization time since the inverter shipment accumulated every hour is displayed.
Page 314  Enabling display of negative numbers during monitoring (Pr.290) • Negative signal outputs can be selected for the items monitored via terminal AM (analog voltage output), via a communication option, and on the operation panel. To check which items can be monitored with indication of negative numbers, refer to the monitor items list (on page 306).
Page 315 Parameters referred to Pr.30 Regenerative function selectionpage 566 Pr.37 Speed display, Pr.144 Speed setting switchoverpage 303 Pr.55 Frequency monitoring reference, Pr.56 Current monitoring reference, Pr.866 Torque monitoring referencepage 314 5.8.3 Monitor display selection for terminals FM/CA and Monitored values are output in either of the following: analog voltage (terminal AM), pulse train (terminal FM) for the FM type inverter, or analog current (terminal CA) for the CA type inverter.
Page 316 Increment Pr.54 (FM/CA) Terminal FM/CA/AM Negative Monitor item Remarks and unit Pr.158 (AM) setting full-scale value output Output frequency 0.01 Hz Pr.55 ○ Pr.56 Output current 0.01/0.1 A 200 V class: 400 V Output voltage 0.1 V 400 V class: 800 V Frequency setting value 0.01 Hz Pr.55...
Page 317 Increment Pr.54 (FM/CA) Terminal FM/CA/AM Negative Monitor item Remarks and unit Pr.158 (AM) setting full-scale value output Remote output value 1 0.1% 1000% Remote output value 2 0.1% 1000% Refer to page 343 for the analog remote output. Remote output value 3 0.1% 1000% Remote output value 4...
Page 318 Output voltage 10VDC 60Hz 60Hz 590Hz (initial value) Setting range of Pr.55 -10VDC FM type: 60 Hz, CA type: 50 Hz Output of negative signals enabled when Pr.290 Monitor negative output selection = "1 or 3"  Current monitor reference (Pr.56) •...
Page 319 FM output circuit Inverter 2.2K 3.3K Indicator 1mA full-scale (Digital indicator) analog meter 1440 pulses/s(+) Calibration 8VDC resistor Pulse width T1: Adjust using calibration parameter C0 Pulse cycle T2: Set with Pr.55 (frequency monitor) Set with Pr.56 (current monitor) Not needed when the operation panel or the parameter unit is used for calibration. Use a calibration resistor when the indicator (frequency meter) needs to be calibrated by a neighboring device because the indicator is located far from the inverter.
Page 320 "HIGH" indicates when the open collector output transistor is OFF. High-speed pulse train output Item specifications Output method NPN open collector output Voltage between collector-emitter 30 V (max.) Maximum permissible load current 80 mA Output pulse rate 0 to 55k pulses/s Output resolution 3 pulses/s (excluding jitter) 50k pulses/s when the monitor output value is 100%.
Page 321  Terminal FM calibration (C0 (Pr.900)) • The output via terminal FM is set to the pulse output. By setting C0 (Pr.900), the meter connected to the inverter can be calibrated by parameter setting without use of a calibration resistor. •...
Page 322  Calibration procedure for terminal FM when using the operation panel (FR-DU08) Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode. Changing the operation mode Press to choose the PU operation mode. [PU] indicator turns ON. Calibration is also possible in the External operation mode.
Page 323  Terminal CA calibration (C0 (Pr.900), C8 (Pr.930) to C11 (Pr.931)) • Terminal CA is initially set to provide a 20 mADC output in the full-scale state of the corresponding monitor item. The calibration parameter C0 (Pr.900) allows the output current ratio (gains) to be adjusted according to the meter scale. Note that the maximum output current is 20 mADC.
Page 324  Calibration of terminal AM (C1 (Pr.901)) • Terminal AM is initially set to provide a 10 VDC output in the full-scale state of the corresponding monitor item. The calibration parameter C1 (Pr.901) AM terminal calibration allows the output voltage ratio (gains) to be adjusted according to the meter scale.
Page 325 5.8.5 Energy saving monitoring From the power consumption estimated value during commercial power supply operation, the energy saving effect by use of the inverter can be monitored and output. Name Initial value Setting range Description Operation panel main 0 (output M100 monitor selection frequency)
Page 326  Energy saving monitoring list • The items in the energy saving effect monitoring (items which can be monitored when "50" is set in Pr.52, Pr.54, Pr.158, Pr.774 to Pr.776, and Pr.992) are listed below. (The items which can be monitored via terminal FM or CA (Pr.54 setting) and via terminal AM (Pr.158 setting) are limited to [1 Power saving] and [3 Average power saving].) Parameter setting Energy saving...
Page 327 • The items in the cumulative energy saving monitoring (items which can be monitored when "51" is set in Pr.52, Pr.774 to Pr.776, and Pr.992) are listed below. (The digit of the cumulative energy saving monitored value can be moved to the right according to the setting of Pr.891 Cumulative power monitor digit shifted times.) Parameter setting Energy saving...
Page 328 • When the setting of Pr.897 is changed, when the inverter is powered ON, or when the inverter is reset, the averaging is restarted. The Energy saving average value updated timing (Y92) signal is inverted every time the averaging is restarted. When Pr.897=4 [Hr] Power is off...
Page 329  Estimated input power for the commercial power supply operation (Pr.892, Pr.893, Pr.894) • Select the pattern of the commercial power supply operation from among four patterns (discharge damper control (fan), suction damper control (fan), valve control (pump) and commercial power drive), and set it in Pr.894 Control selection during commercial power-supply operation.
Page 330 NOTE • Setting example for operation time rate: In the case where the average operation time per day is about 21 hours and the average operation days per month is 16 days. Annual operation time = 21 (h/day) × 16 (days/month) × 12 (months) = 4032 (h/year) 4032 (h/year) ×...
Page 331 5.8.6 Output terminal function selection Use the following parameters to change the functions of the open collector output terminals and relay output terminals. Initial Name Signal name Setting range value RUN terminal RUN (Inverter running) M400 function selection SU terminal 0 to 5, 7, 8, 10 to 19, 25, 26, 35, 39 to 42, 45 to SU (Up to frequency) M401...
Page 332  Output signal list • A function listed below can be set to each output terminal. • Refer to the following table and set the parameters. (0 to 99, 200 to 299: Positive logic, 100 to 199, 300 to 399: Negative logic) Setting Refer...
Page 333 Setting Refer Signal Related Function Operation Positive Negative name parameter page logic logic Inverter running and start The signal is ON while the inverter is running RUN3 — command ON or while the start command signal is ON. Output when the power-failure deceleration During deceleration at function is activated.
Page 334 Setting Refer Signal Related Function Operation Positive Negative name parameter page logic logic Control circuit capacitor life Output when the control circuit capacitor approaches the end of its life. (for Pr.313 to Pr.322) Main circuit capacitor life Output when the main circuit capacitor *2*5 approaches the end of its life.
Page 335 Setting Refer Signal Related Function Operation Positive Negative name parameter page logic logic Output when the load fault upper limit Upper limit warning detection warning is detected. Output when the load fault lower limit warning Pr.1480 to Lower limit warning detection is detected.
Page 336  Adjusting the output terminal response level (Pr.289) • The responsivity of the output terminals can be delayed in a range between 5 to 50 ms. (The following is the operation example of the RUN signal.) Time Pr.289 = 9999 Pr.289 ≠...
Page 337 The signal is OFF during power failure or undervoltage. This means the state during a fault occurrence or while the MRS signal is ON, etc. The signal is OFF while power is not supplied to the main circuit. • To use the RY, RUN, or RUN3 signal, set the corresponding number selected from the following table in any parameter from Pr.190 to Pr.196 (Output terminal function selection) to assign the function to an output terminal.
Page 338  Changing the special relay function for the PLC function • For the PLC function, the function of special relays (SM1225 to SM1234) can be changed by setting Pr.313 to Pr.322. (For details on the PLC function, refer to the PLC Function Programming Manual.) Parameters referred to Pr.13 Starting frequencypage...
Page 339 • When a different detection point of the frequency is required, Pr.50 is available. The FU2 (or FB2) signal can be set to be output when the output frequency reaches the Pr.50 setting or higher. Forward rotation Pr.50 Pr.42 Pr.43 Time Pr.50 Reverse...
Page 340 • Setting a higher value in Pr.870 causes a lower responsivity of the signals for frequency detection (SU, FB, and FB2 signals). • Changing the terminal assignment using Pr.190 to Pr.196 (Output terminal function selection) may affect the other functions. Set parameters after confirming the function of each terminal. Parameters referred to Pr.190 to Pr.196 (Output terminal function selection)page 330...
Page 341 Pr.166 "9999", Pr.167 = "0" Pr.150 Output current Pr.151 Time Pr.166 Output current detection signal (Y12)  Zero current detection (Y13 signal, Pr.152, Pr.153) • If the inverter output during inverter running remains higher than the Pr.152 setting for the time set in Pr.153 or longer, the Zero current detection (Y13) signal is output from the inverter's open collector or the relay output terminal.
Page 342 5.8.9 Output torque detection function Magnetic flux Magnetic flux Magnetic flux If the motor torque which reaches a specific value is detected, the relative signal is output. The signal is useful for applying or releasing electromagnetic brake, etc. Name Initial value Setting range Description Set a value of the torque at which the TU...
Page 343 • Refer to the following figures to check correspondences between the bit and the actual terminal. When "1" is set in the bit corresponding to the terminal to which the REM signal assigned by setting a number in Pr.496 and Pr.497 each, the signal turns ON (or OFF in negative logic setting).
Page 344 5.8.11 Analog remote output function An analog value can be output via the analog output terminal on the inverter. Initial Setting Name Description value range Remote output data is cleared when the inverter power is turned OFF. Remote output data is cleared during an inverter reset.
Page 345 • Terminal CA output [mA] = 20 [mA] × (Analog remote output value - 1000)/100 Where the output range is 0 to 20 mA. Output current [mA] 1000 1100 1200 Analog remote output value [%] Terminal CA • When Pr.158 AM terminal function selection = "87, 88, 89, or 90", an analog voltage can be output via terminal AM. •...
Page 346 NOTE • When Pr.655 = "1 or 11" (remote output data retained at power OFF), take measures to keep the control circuit power ON, such as connecting terminal R1/L11 with terminal P/+ and connecting terminal S1/L21 with terminal N/- (while power is supplied via input terminals R/L1, S/L2 and T/L3).
Page 347 5.8.13 Pulse train output to announce cumulative output energy Every time when the output energy cumulated from the time at power ON or at an inverter reset or when the setting of Pr.799 Pulse increment setting for output power has been changed increments by the set value, the Pulse train output of output power (Y79) signal is output in pulses.
Page 348 5.8.14 Detection of control circuit temperature The temperature of the control circuit board can be monitored, and a signal can be output according to a predetermined temperature setting. Name Initial value Setting range Description Control circuit temperature Set the temperature where the Y207 signal turns 0°C 0°C to 100°C M060...
Page 349: T) Multi-Function Input Terminal Parameters
(T) Multi-function input terminal parameters Refer to Purpose Parameter to set page To inverse the rotation direction with the voltage/current analog input selection Analog input selection P.T000, P.T001 Pr.73, Pr.267 (terminals 1, 2, and 4) To assign functions to analog input Terminal 1 and terminal 4 P.T010, P.T040 Pr.858, Pr.868...
Page 350 5.9.1 Analog input selection The functions to switch the analog input terminal specifications, override function, forward/reverse rotation by the input signal polarity are selectable. Setting Name Initial value Description range 0 to 5, 10 Switch 1 - OFF The terminal 2 input specification (0 to 5 V, 0 to 10 to 15 (initial status) V, 0 to 20 mA) and terminal 1 input specification (0...
Page 351 Set Pr.73 and the voltage/current input selection switch according to the following table. Compensation input Terminal 2 Terminal 1 Pr.73 setting Switch 1 terminal compensation Reversible polarity input input method 0 to ±10 V 0 to 10 V 1 (initial value) 0 to ±10 V 0 to 5 V Terminal 1 addition...
Page 352  Running with analog input voltage • For the frequency setting signal, input 0 to 5 VDC (or 0 to 10 VDC) between terminals 2 and 5. The 5 V (10 V) input is the maximum output frequency. • The power supply 5 V (10 V) can be input by either using the internal power supply or preparing an external power supply. The internal power supply is 5 VDC output between terminals 10 and 5, and 10 VDC output between terminals 10E and 5.
Page 353  Performing forward/reverse rotation with the analog input (polarity reversible operation) • Setting "10 to 17" in Pr.73 enables the polarity reversible operation. • Set a positive or negative input (0 to ±5 V or 0 to ±10 V) to terminal 1 to allow the operation of forward/reverse rotation according to the polarity of the input value.
Page 354 5.9.3 Analog input compensation The analog input for multi-speed operation or speed setting (main speed) through terminal 2 or 4 can be compensated by adding an input, or terminal 2 can be used for an auxiliary input to compensate the analog input at a fixed ratio using the override function.
Page 355 Output frequency Output frequency When voltage across When voltage across terminals 2 and 5 is 2.5 V terminals 2 and 5 is 2.5 V (5 V) (5 V) When voltage When voltage across terminals across terminals 2 and 5 is 0 V 2 and 5 is 0 V -5 V -2.5 V...
Page 356 • Example) When Pr.73 = "5" By the terminal 1 (main speed) and terminal 2 (auxiliary) input, the setting frequency is set as shown in the figure below. Terminal 2 5VDC input(150%) Pr.252 Initial value Terminal 2 2.5VDC (50% to 150%) Pr.253 input(100%) Terminal 2 0V...
Page 357  Analog input time constant (Pr.74) • Use this parameter to eliminate noise on the frequency setting circuit. • Increase the filter time constant if the operation is unstable due to noise or other factors. If the setting is too large, response becomes slow. (The time constant can be between 0 and 8, which are about 2 ms to 1 ...
Page 358 5.9.5 Frequency setting voltage (current) bias and gain The magnitude (slope) of the output frequency can be set as desired in relation to the frequency setting signal (0 to 5 VDC, 0 to 10 VDC, or 4 to 20 mA). Use Pr.73 Analog input selection (Pr.267 Terminal 4 input selection) and the voltage/current input selection switch to switch among input of 0 to 5 VDC, 0 to 10 V, and 4 to 20 mA.
Page 359 • Calibration parameter according to the terminal 4 function Calibration parameter Pr.858 Terminal function setting Bias setting Gain setting C5 (Pr.904) Terminal 4 frequency setting Pr.126 Terminal 4 frequency setting gain 0 (initial bias frequency Frequency command frequency value) C6 (Pr.904) Terminal 4 frequency setting C7 (Pr.905) Terminal 4 frequency setting gain bias C38 (Pr.932) Terminal 4 bias command...
Page 360 NOTE • When the slope of the frequency is changed after calibration of terminal 2, the slope of the frequency is also changed for terminal 1. • When voltage is applied to terminal 1 while calibration of terminal 2 or terminal 4 is in progress, the terminal 1 input value is added to the terminal 2 (4) input value.
Page 361  Frequency setting voltage (current) bias/gain adjustment method  Adjustment by applying voltage (current) between terminals 2 and 5 (4 and 5) to set the voltage (current) at the bias/gain frequency (Example of adjustment at the gain frequency) Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode.
Page 362  Adjustment by selecting the voltage (current) at the bias/gain frequency without applying voltage (current) between terminals 2 and 5 (4 and 5) (Example of adjustment at the gain frequency) Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode. Changing the operation mode Press to choose the PU operation mode.
Page 363  Adjustment by changing the frequency without adjusting the voltage (current) (Example of changing the gain frequency from 60 Hz to 50 Hz) Operating procedure Selecting the parameter Turn until " " (Pr.125) appears for terminal 2, or " " (Pr.126) for terminal 4. Press to read the present set value.
Page 364 5.9.6 Bias and gain for voltage (current) setting of stall prevention operation level The magnitude (slope) of the stall prevention operation level can be set as desired in relation to the analog signal (0 to 5 VDC, 0 to 10 VDC, or 4 to 20 mA). Use Pr.73 Analog input selection or Pr.267 Terminal 4 input selection to switch among input 0 to 5 VDC, 0 to 10 VDC, and 4 to 20 mA.
Page 365 • Calibration parameter according to the terminal 4 function Calibration parameter Pr.858 Terminal function setting Bias setting Gain setting C5 (Pr.904) Terminal 4 frequency setting Pr.126 Terminal 4 frequency setting gain 0 (initial bias frequency Frequency (speed) command frequency value) C6 (Pr.904) Terminal 4 frequency setting C7 (Pr.905) Terminal 4 frequency setting gain bias...
Page 366  Display unit changing for analog input (Pr.241) • The analog input display unit (%/V/mA) can be changed for analog input bias/gain calibration. • Depending on the terminal input specification setting of Pr.73 (Pr.267), the unit of the displayed value of C17 (Pr.919), C19 (Pr.920), C39 (Pr.932), and C41 (Pr.933) changes as follows: Analog command (via terminal 1 or 4) (depending on the setting of Pr.73...
Page 367  Adjustment method for the stall prevention operation level setting voltage (current) bias and gain (a) Adjustment by applying voltage (current) between terminals 1 and 5 (4 and 5) to set the voltage (current) at the bias/gain level Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode.
Page 368 (b) Adjustment by selecting the voltage (current) at the bias/gain level without applying voltage (current) between terminals 1 and 5 (4 and 5) Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode. Changing the operation mode Press to choose the PU operation mode.
Page 369 (c) Adjustment by changing the stall prevention operation level only without adjusting the gain voltage (current). (Example of changing the gain value from 150% to 130%) Operating procedure Selecting the parameter Turn until " " (Pr.920) appears for terminal 2, or " "...
Page 370 5.9.7 Checking of current input on analog input terminal When current is input to the analog input terminal 2 or terminal 4, the input current can be checked and the operation when the input falls below the specified level (the analog current input is lost) can be selected. The operation can be continued even when the analog current input is lost.
Page 371 NOTE • Changing the terminal assignment using Pr.190 to Pr.196 (Output terminal function selection) may affect the other functions. Set parameters after confirming the function of each terminal.  Continuing operation when the analog current input is lost (Pr.573 = "1, 4, 11, 14, 21, or 24", Pr.777) •...
Page 372 • The following is the operation example during PID control (reverse action) operation. E.LCI occurs Output frequency Input current 20mA decrease Set point (fixed) Return Measured value Time LF signal PID signal ALM signal  Fault output after deceleration to stop (Pr.573 = "3, 13, or 23") •...
Page 373  Functions related to current input check Refer to Function Operation page When the operation continues, the minimum frequency setting is valid even during current Minimum frequency input loss. The multi-speed setting signal is prioritized even during current input loss (the motor operates according to the multi-speed setting even during continuous operation at the predetermined frequency or during deceleration to a stop).
Page 374 5.9.8 Input terminal function selection Use the following parameters to select or change the input terminal functions. Initial Name Initial signal Setting range value 0 to 8, 10 to 14, 16, 18, 24, 25, 28, 37 to 40, 46 STF terminal STF (Forward rotation command) to 48, 50, 51, 57, 58, 60, 62, 64 to 67, 70 to 73, T700...
Page 375 Signal Refer to Setting Function Related parameter name page 15-speed selection (Combination with multi-speeds of RL, RM, and Pr.4 to Pr.6, Pr.24 to Pr.27, Pr.232 to Pr.239 Inverter run enable (FR-HC2/FR-XC/FR-CV/FR-CC2 connection) Pr.30, Pr.599 FR-HC2/FR-CC2 connection, instantaneous power failure Pr.30 detection PU operation external interlock Pr.79...
Page 376 When Pr.59 Remote function selection ≠ "0", functions of the RL, RM, and RH signals are changed as shown in the table. The OH signal is activated when the relay contact is open. The setting is available for the standard structure model and the IP55 compatible model. NOTE •...
Page 377  Output shutoff signal (MRS signal) (Initial Setting value "0" Setting value "2" Motor coasts value) Output frequency to stop Inverter Inverter Time MRS signal STF (STR) signal • When the Output stop (MRS) signal is turned ON while operating the inverter, the inverter output is instantaneously shut off.
Page 378 5.9.10 Selecting the condition to activate the Second function selection (RT) signal The second function can be selected using the RT signal. The condition to activate the second function can be also set. Name Initial value Setting range Description The second function is immediately enabled when the RT signal is turned ON.
Page 379 • When the RT signal is ON, second functions are selected. The following table shows the functions which can be changed to the second function. First function Second function Function Refer to page Parameter number Parameter number Torque boost Pr.0 Pr.46 Base frequency Pr.3...
Page 380: (C) Motor Constant Parameters
5.10 (C) Motor constant parameters Purpose Parameter to set Refer to page To select the motor to be used Applied motor P.C100, P.C200 Pr.71, Pr.450 P.C000, P.C100 to Pr.9, Pr.51, Pr.71, P.C105, P.C107, Pr.80 to Pr.84, Pr.90 to P.C108, P.C110, Pr.94, Pr.96, Pr.450, To maximize the performance of the P.C120 to P.C126,...
Page 381 Adjustable 5 points V/F (Refer to page ○ 558.) • 0 to 50 Ω, 9999 (0.001 Ω) Mitsubishi Electric standard motor (SF- • 0 to 400 mΩ, 9999 (0.01 mΩ) ○ JR 4P 1.5kW or lower) Pr.92 (Pr.460), Pr.93 (Pr.461) (Induction...
Page 382 The same operation is performed for the both settings. NOTE • Regardless of the Pr.71 (Pr.450) setting, offline auto tuning can be performed according to Pr.96 (Pr.463) Auto tuning setting/status. (Refer to page 383 for offline auto tuning.)  Using two types of motors (RT signal, Pr.450) •...
Page 383  Automatic change of Pr.0 Torque boost and Pr.12 DC injection brake operation voltage • When initial values are set in Pr.0 and Pr.12, the Pr.0 and Pr.12 settings are automatically changed to the values in the following table by changing the Pr.71 setting. Pr.12 value (%) after automatic Inverter Pr.0 value (%) after automatic change...
Page 384 Motor inertia 9999 10 to 999, 9999 Set the motor inertia. C107 (integer) 9999: The constant value of Mitsubishi Electric motor (SF-JR, Motor inertia SF-HR, SF-JRCA, or SF-HRCA and so on) is used. 9999 0 to 7, 9999 C108 (exponent) No offline auto tuning Offline auto tuning is performed without the motor rotating.
Page 385 9999 10 to 999, 9999 Set the inertia of the second motor. C207 inertia (integer) 9999: The constant value of Mitsubishi Electric motor (SF-PR, Second motor SF-JR, SF-HR, SF-JRCA, SF-HRCA and so on) is used. 9999 0 to 7, 9999...
Page 386 • By using the offline auto tuning function, the optimum operation characteristics are obtained for a motor other than Mitsubishi Electric standard motors (SF-JR 0.4 kW or higher), high-efficiency motors (SF-HR 0.4 kW or higher), Mitsubishi Electric constant-torque motors (SF-JRCA 4P, SF-HRCA 0.4 kW to 55 kW), or Mitsubishi Electric high-performance energy-serving motor (SF-PR), such as an induction motor of other manufacturers, SF-JRC, or SF-TH, or with a long wiring length (30 m or longer).
Page 387 Ω, mΩ, and unit setting data setting A unit setting SF-JR, SF-TH 0 (initial value) 3 (4) — Mitsubishi Electric SF-JR 4P 1.5 kW or lower 23 (24) — standard motor Mitsubishi Electric SF-HR 43 (44) —...
Page 388 NOTE • Satisfy the required inverter start conditions to start offline auto tuning. For example, stop the input of the MRS signal. • To force tuning to end, use the MRS or RES signal or on the operation panel. (Turning OFF the start signal (STF signal or STR signal) also ends tuning.) •...
Page 389  Changing the motor constants (when setting the Pr.92 and Pr.93 motor constants in units of mH) • Set Pr.71 as follows. Motor Pr.71 setting SF-JR 0 (initial value) Mitsubishi Electric standard motor SF-JR 4P 1.5 kW or lower Mitsubishi Electric high-efficiency motor SF-HR SF-JRCA 4P Mitsubishi Electric constant-torque motor SF-HRCA...
Page 390 For the FR-F820-03160(75K) or higher, and FR-F840-01800(75K) or higher. NOTE • If "9999" is set, tuning data will be invalid and the constant values for Mitsubishi Electric motors (SF-PR, SF-JR, SF-HR, SF- JRCA, SF-HRCA and so on) are used.  Changing the motor constants (when setting motor constants in the internal data of the inverter) •...
Page 391 (The value displayed has been converted into a value for internal use. Therefore, simple addition of a value to the displayed value does not bring the desired effect.) • If "9999" is set, tuning data will be invalid and the constant values for Mitsubishi Electric motors (SF-PR, SF-JR, SF-HR, SF- JRCA, SF-HRCA and so on) are used.
Page 392 • If "wye connection" or "delta connection" is incorrectly selected in Pr.71, Advanced magnetic flux vector control is not performed properly. • If "9999" is set, tuning data will be invalid and the constant values for Mitsubishi Electric motors (SF-PR, SF-JR, SF-HR, SF- JRCA, SF-HRCA and so on) are used.
Page 393 Parameters referred to Pr.1 Maximum frequencypage 287 Pr.9 Electronic thermal O/L relaypage 266 Pr.31 to Pr.36 Frequency jumppage 289 Pr.71 Applied motorpage 379 Pr.156 Stall prevention operation selectionpage 290 Pr.178 to Pr.189 (Input terminal function selection)page 373 Pr.190 to Pr.196 (Output terminal function selection)page 330 5.10.3 Offline auto tuning for a PM motor (motor constant tuning)
Page 394 Initial Name Setting range Description value *1*4 0 to 50 Ω, 9999 Motor constant (R1) 9999 C120 *2*4 0 to 400 mΩ, 9999 Tuning data *1*4 0 to 500 mH, 9999 (The value measured by offline auto tuning is automatically Motor constant (L1)/d- 9999 set.)
Page 395 Initial Name Setting range Description value Second motor inertia 9999 10 to 999, 9999 Set the inertia of the second motor. C207 (integer) 9999: The MM-EFS/MM-THE4 inertia is used for the IPM motor Second motor inertia MM-EFS/MM-THE4. 9999 0 to 7, 9999 C208 (exponent) 0, 101...
Page 396  Before performing offline auto tuning Check the following points before performing offline auto tuning: • The PM motor control is selected. • A motor is connected. (Check that the motor is not rotated by an external force during tuning.) •...
Page 397  Performing tuning • Before performing tuning, check the monitor display of the operation panel or parameter unit if the inverter is in the state ready for tuning. The motor starts by turning ON the start command while tuning is unavailable. •...
Page 398 • If offline auto tuning has ended in error (see the following table), motor constants are not set. Perform an inverter reset and perform tuning again. Error display Error cause Countermeasures Forced end Set Pr.96 (Pr.463)="1 or 11" and try again. Inverter protective function operation Make the setting again.
Page 399  Changing the motor constants • The motor constants can be set directly when the motor constants are known in advance, or by using the data measured during offline auto tuning. • According to the Pr.71 (Pr.450) setting, the range of the motor constant parameter setting values and units can be changed.
Page 400  Changing the motor constants (when setting a motor constants in the internal data of the inverter) • Set Pr.71 as follows. Motor Pr.71 setting MM-EFS (1500 r/min specification) / MM-THE4 213 (214) IPM motor MM-EFS (3000 r/min specification) 243 (244) Other than MM-EFS/MM-THE4 8093 (8094) SPM motor...
Page 401 5.10.4 Online auto tuning Magnetic flux Magnetic flux Magnetic flux If online auto tuning is selected under Advanced magnetic flux vector control, favorable torque accuracy is retained by adjusting temperature even when the resistance value varies due to increase in the motor temperature. Name Initial value Setting range...
Page 402  Online auto tuning at startup using the external terminal (Pr.95/Pr.574 = "1", X28 signal, Y39 signal) • Before turning ON the start signal (STF or STR), online auto tuning can be performed by turning ON the Start-time tuning start external input (X28) signal in a stopped status in order to minimize the startup delay by tuning at start. •...
Page 403 NOTE • The Y39 signal remains ON after the motor is stopped as long as the second flux remains. • The X28 signal is disabled while the Y39 signal is ON. • The STF and STR signals are enabled after completing tuning at start. •...
Page 404: A) Application Parameters
5.11 (A) Application parameters Refer to Purpose Parameter to set page To operate by switching between the inverter and the commercial power Electronic bypass function P.A000 to P.A005 Pr.135 to Pr.139, Pr.159 supply operation P.A002, P.A006, Pr.30, Pr.137, Pr.248, To reduce the standby power Self power management P.A007, P.E300 Pr.254...
Page 405 5.11.1 Electronic bypass function Magnetic flux Magnetic flux Magnetic flux The inverter contains complicated sequence circuits for switching between the commercial power supply operation and inverter operation. Therefore, interlock operation of the magnetic contactor for switching can be easily performed by simply inputting start, stop, and automatic switching selection signals.
Page 406 • When switching between inverter operation and commercial power supply operation, commercial power supply may be accidentally applied to the output side of the inverter. To avoid such situation, provide an interlock where the magnetic contactor at the commercial power supply side turns ON at turn OFF of the magnetic contactor at the inverter output side. The inverter's electronic bypass sequence that outputs timing signals for the magnetic contactors can act as a complicated interlock between the commercial power supply operation and the inverter operation.
Page 407 To use the signal, assign the function to the output terminal Pr.190 to Pr.195 (Output terminal function selection) of the converter unit. Always set the negative logic for the ALM signal. NOTE • To use the electronic bypass function, the wiring terminals R1/L11 and S1/L21 must be connected to a separate power source that does not go through MC1.
Page 408 MC operation is as shown below. Notation MC operation ○ × During inverter operation: MC2-OFF, MC3-ON — During commercial power supply operation: MC2-ON, MC3-OFF No change The operation status before changing the signal state to ON or OFF is held. •...
Page 409 • Example of operation sequence with automatic bypass sequence (Pr.139 ≠ "9999", Pr.159 ≠ "9999") Output frequency Pr.139 Pr.159 Frequency command Time Actual motor speed Time operation Commercial power supply operation A : Pr.136 MC switchover interlock time B : Pr.137 Start waiting time C : Pr.57 Restart coasting time D : Pr.58 Restart cushion time Operating procedure...
Page 410 NOTE • Connect the control power (R1/L11, S1/L21) in front of the input-side MC1. If the control power is connected behind the input- side MC1, the electronic bypass sequence function will not operate. • The electronic bypass sequence function is enabled only when Pr.135 = "1" and the inverter is in either External operation mode, PU/External combined operation mode 1 (Pr.79 = "3"), or Network operation mode.
Page 411  Operation in combination with the self power management function for the separated converter type • When the self power management function is used with the separated converter type, the input signal operations are as follows. MC operation (Converter unit (Control signal for (Converter unit Converter status...
Page 412  Connection diagram • Terminal R1, S1 inputs Inverter Converter unit Inverter MCCB MCCB R/L1 R/L1 S/L2 S/L2 T/L3 T/L3 R1/L11 R1/L11 S1/L21 S1/L21 24VDC R1/L11 24VDC S1/L21 Standard models Separated converter type • 24 V external power supply input Inverter Converter unit Inverter...
Page 413 • When the protective function of the inverter is activated, the MC1 signal is immediately turned OFF according to the Pr.248 setting. (The MC1 signal is turned OFF before the time set in Pr.254 has passed.) When Pr.248 = "1", the MC1 signal is turned OFF when the protective function is activated due to any cause. When Pr.248 = "2", the MC1 signal is turned OFF only when the protective function is activated due to an error resulted from a failure in the inverter circuit or a wiring error (refer to the following table).
Page 414 NOTE • When the start signal is turned OFF before the time set in Pr.137 has passed after the start signal is turned ON, the inverter does not start and the MC1 signal is turned OFF after the time set in Pr.254 has passed. If the start signal is turned ON again before the time set in Pr.254 has passed, the inverter immediately starts outputting.
Page 415 • The maximum count is "99999999". When "99999999" is exceeded on the monitor, the monitor value is reset to 0. Display data Monitor display Pr.1410 (Lower digits monitor) 10000 Pr.1411 (Upper digits monitor) Pr.1410 (Lower digits monitor) Pr.1411 (Upper digits monitor) NOTE •...
Page 416 • When the output frequency reaches f0 and the X37 signal turns ON, the inverter begins traverse operation and accelerates to f0 + f1. The acceleration time at this time is according to the Pr.596 setting. (If the X37 signal turns ON before the output frequency reaches f0, traverse operation begins after the output frequency reaches f0.) •...
Page 417  Outline of the cleaning operation • Setting a number in Pr.1470 Number of cleaning times setting enables the cleaning function. • The cleaning operation is started when the trigger set in Pr.1471 or Pr.1479 occurs, or when the X98 signal turns ON. When the cleaning is started initially, the operation in the opposite direction to the start command is performed.
Page 418  Cleaning trigger selection (Pr.1471, Pr.1479, X98 signal) • Use Pr.1471 Cleaning trigger selection to select the trigger to start cleaning operation. As set in Pr.1471, cleaning operation is started when any of the applicable trigger conditions is satisfied. Value in each bit Pr.1471 Trigger factor Remarks...
Page 419 • Starting conditions of the timer for a time trigger When the start command turns ON When the cleaning ends Start command ON trigger Time trigger Time trigger Y215 Output Pr.1479 Pr.1479 frequency 0 Hz Time Cleaning Cleaning Cleaning Normal Normal Normal operation operation...
Page 420 5.11.6 PID control Process control such as flow rate, air volume or pressure are possible on the inverter. A feedback system can be configured and PID control can be performed using the terminal 2 input signal or parameter setting value as the set point and the terminal 4 input signal as the feedback value. Name Initial value Setting range...
Page 421 Name Initial value Setting range Description Terminal 1 input Terminal 2 input Terminal 4 input Direct input of the measured value Communication input PLC function input PID measured value A625 input selection Terminal 1 input Terminal 2 input Input of the square root of the Terminal 4 input measured value Communication input...
Page 422 Name Initial value Setting range Description 0, 10, 11, 20, 21, 50, 51, 60, 61, 70, 71, 80, 81, 90, 91, Second PID action 100, 101, 1000, Refer to Pr.128. A650 selection 1001, 1010, 1011, 2000, 2001, 2010, 2011 Second PID control automatic switchover 9999 0 to 590 Hz, 9999 Refer to Pr.127.
Page 423  PID action outline  PI action PI action is a combination of proportional action (P) and integral action (I), and applies a manipulated amount according to the size of the deviation and transition or changes over time. [Example of action when the measured value changes in a stepped manner] Deviation Set point Measured value P action...
Page 424  Reverse action When deviation X = (set point - measured value) is a plus value, the manipulated amount (output frequency) is increased, and when the deviation is a minus value, the manipulated amount is decreased. Deviation Set point [Heating] X>0 Cold Increase...
Page 425  Selection of deviation value, measured value and set point input method, and PID action method (Pr.128, Pr.609, Pr.610) • Using Pr.128, select the input method for the PID set point, measured value detected by the meter, and externally calculated deviation. Also, select forward or reverse action. •...
Page 426 • The set point/deviation input method can also be flexibly selected by Pr.609 PID set point/deviation input selection and the measured value input method can be selected by Pr.610 PID measured value input selection. Selection by Pr.609 and Pr.610 is enabled when Pr.128 = "1000 to 2011". Setting value Command source Input method...
Page 427 • The following shows the relationship between the input values of the analog input terminals and set point, measured value and deviation. (Calibration parameter initial values) Relationship with analog input Input Input terminal Calibration parameter specification Set point Result Deviation 0 V = 0% 0 V = 0% 0 V = 0%...
Page 428  Input/output signals • Assigning the PID control valid (X14) signal to the input terminal by Pr.178 to Pr.189 (Input terminal function selection) enables PID control to be performed only when the X14 signal is turned ON. When the X14 signal is OFF, regular inverter running is performed without PID action .
Page 429  PID automatic switchover control (Pr.127) • The system can be started up more quickly by starting up without PID control activated. • When Pr.127 PID control automatic switchover frequency is set, the startup is made without PID control until the output frequency reaches the Pr.127 setting.
Page 430 • The following is the operation example of the FUP and FDN signals. Measured value Upper limit level Pr.131(Pr.1143) Measured Detection time Detection time Detection time value Detection time Detection time Detection time Pr.1370 Pr.1370 Pr.1370 Pr.1370 Pr.1370 Pr.1370 Detection Detection Detection Pr.1346...
Page 431  PID output suspension function (sleep function) (SLEEP signal, Pr.575 to Pr.577) • When a status where the output frequency after PID calculation is less than Pr.576 Output interruption detection level has continued for the time set in Pr.575 Output interruption detection time or longer, inverter running is suspended. This allows the amount of energy consumed in the inefficient low-speed range to be reduced.
Page 432 NOTE • The stirring function during the PID sleep prevents clogging of the pump while the sleep function is activated. (Refer to page 459.) • The PID sleep boost function maintains the sleep state for a long period of time. (Refer to page 459.) ...
Page 433  PID monitor function • This function displays the PID control set point, measured value and deviation on the operation panel, and can output these from the terminals FM/CA and AM. • An integral value indicating a negative % can be displayed on the deviation monitor. 0% is displayed as 1000. (These values cannot be output on the deviation monitor from terminals FM and CA.) •...
Page 434  Calibration example (Adjust room temperature to 25°C by PID control using a detector that outputs 4 mA at 0°C and 20 mA at 50°C.) Start Set the room temperature to 25°C. Determination of set point Determine the set point of what is desired to be adjusted.
Page 435 • Calibrating set point input (Example: To enter the set point on terminal 2) 1. Apply the input (for example, 0 V) of set point setting 0% across terminals 2 and 5. Using C2 (Pr.902), enter the frequency (for example, 0 Hz) to be output by the inverter when the deviation is 0%. Using C3 (Pr.902), set the voltage value at 0%.
Page 436  Setting multiple PID functions • When the second PID function is set, two sets of PID functions can be switched for use. The PID setting is selected as shown in the following table. Pr.128 setting Pr.753 setting Pr.155 PID setting applied to the output RT signal (First PID setting) (Second PID setting)
Page 437 NOTE • Even if the X14 signal is ON, PID control is stopped and multi-speed or JOG operation is performed when the multi-speed operation (RH, RM, RL, or REX) signal or JOG signal (JOG operation) is input. • PID control is invalid under the following settings. Pr.79 Operation mode selection = "6"...
Page 438 5.11.7 PID gain tuning Changing the PID control manipulated amount and measuring the PID control response enable automatic setting of the constant optimal for PID control. For tuning, use the step response method or the limit cycle method. Initial Name Setting range Description value...
Page 439 • The measured value is taken for every sampling cycle (Pr.1213). From the variation between the measured values (Y) and the time (t), the maximum slope (R) is calculated. • The measurement ends when the timeout time (Pr.1214) elapsed after the maximum slope is obtained. •...
Page 440 • After the integral term is cleared, PID control is performed with the constant to which the change has been applied (the constant used before PID gain tuning when a fault occurs). NOTE • Confirm that the measured values are stable when performing PID gain tuning with the step response method. When the measured values are unstable, the tuning result may not be accurate.
Page 441  Execution of PID gain tuning (Pr.1219, PGT signal) • While the PID gain tuning function is enabled (Pr.1218 ≠ "0"), PID gain tuning is started when any of the following operations is performed during PID control. Turn ON the PID gain tuning start/forced end (PGT) signal. Set Pr.1219 PID gain tuning start/status = "1".
Page 442  PID gain tuning error • When the read value of Pr.1219 or the PID gain tuning status monitor display is "9, 90 to 96", tuning has not been properly completed due to a tuning error. Remove the cause of the tuning error, and perform tuning again. Monitor value Error description Cause of tuning error...
Page 443 5.11.8 Changing the display increment of numerical values used in PID control When the LCD operation panel (FR-LU08) or the parameter unit (FR-PU07) is used, the display unit of parameters and monitor items related to PID control can be changed to various units. Setting Name Initial value...
Page 444 • There are three methods to adjust the PID display bias/gain. Method to adjust any point by application of a current (voltage) to the measured value input terminal Method to adjust any point without application of a current (voltage) to the measured value input terminal Method to adjust only the display coefficient without adjustment of current (voltage) (Refer to page 357...
Page 445  Changing the PID display coefficient of the LCD operation panel (FR- LU08) or the parameter unit (FR-PU07) (Pr.759) • Use Pr.759 PID unit selection to change the unit of the displayed value on the FR-LU08 or the FR-PU07. For the coefficient set in C42 (Pr.934) to C44 (Pr.935), the units can be changed as follows.
Page 446 5.11.9 PID Pre-charge function This function drives the motor at a certain speed before starting PID control. This function is useful for a pump with a long hose, since PID control would start before the pump is filled with water, and proper control would not be performed without this function, Initial Setting...
Page 447 • The pre-charge function valid/invalid settings and pre-charge ending conditions are as follows: Pre-charge ending condition setting Pre-charge Pr.127 setting Valid pre-charge ending condition function Pr.761 setting Pr.762 setting X77 signal 9999 — — — Disabled — Not assigned 9999 Assigned —...
Page 448  Example of the pre-charge operation • When the measured amount reaches the pre-charge ending level (Pr.761 Pre-charge ending level ≠ "9999") The pre-charge operation ends when the measured value reaches the Pr.761 setting or higher, then the PID control is performed.
Page 449 • When the signal is input to end the pre-charge operation When the X77 signal turns ON, the pre-charge operation ends, and the PID control starts. (If a start command is given while the X77 signal is ON, the pre-charge operation is not performed, and PID control starts.) Output frequency[Hz] Pr.127 PID control...
Page 450 • Example of protective function by time limit (Pr.760 = "0") Measured value[PSI] Ending level Pr.761 Time Output frequency[Hz] Pr.127 When Pr.760 = "0", output is immediately shut off. Pr.764 Time E.PCH • Example of protective function measured value limit (Pr.760 = "1") Measured value[PSI] Pr.763 Time...
Page 451 NOTE • The second PID pre-charge function is valid also when the first pre-charge function is set to invalid and the second pre-charge function is set. • When "10" (second function enabled only during constant-speed operation) is set to Pr.155, the second PID function is not selected even if the RT signal turns ON.
Page 452  Multi-pump function control method • Use Pr.579 Motor connection function selection to select the control method for the multi-pump function. Use Pr.578 Auxiliary motor operation selection to set the number of auxiliary motors. Pr.579 setting Control method Description The motor driven by the inverter is always fixed. Commercial power supply operation of auxiliary Basic system motors is available by turning ON and OFF the MC between the power supply and the motor depending on the output frequency of the inverter.
Page 453 NOTE • The motor 1 (M1) starts first when power is turned ON for the first time or after inverter reset. • When the Pr.578 or Pr.579 setting has been changed, The motor 1 (M1) starts first.  Connection diagram •...
Page 454 • Alternative system (Pr.579 = "1"), direct system (Pr.579 = "2"), alternative direct system (Pr.579 = "3") Sink logic Pr.183 = 14, Pr.185 = 64, Pr.194 = 75, Pr.193 = 71, Pr.192 = 76, Pr.191 = 72, Pr.190 = 77 Pr.320 = 73, Pr.321 = 78, Pr.322 = 74 Inverter Distributed water...
Page 455  Motor switchover timing • Switchover timing at a start (stop) of an auxiliary motor 1 in the basic system (Pr.579 = "0") and alternative system (Pr.579 = "1") Pr. 590 Auxiliary motor start detection time Output frequency Maximum frequency Pr.
Page 456  Waiting time setting at MC switchover (Pr.580, Pr.581) • Set a waiting time for switchover of MC for the direct system (Pr.579 = "2") or alternative direct system (Pr.579 = "3"). • Set the MC switching time (for example, the time after RIO1 turns OFF until RO1 turns ON) in Pr.580 MC switchover interlock time (multi-pump).
Page 457  Timing diagram • When using four motors in the basic system (Pr.579 = "0") STF (STR) Pr.590 Pr.590 Pr.590 Pr.126 Pr.126 Pr.126 Pr.126 Pr.126 Pr.126 Pr.126 Pr.575 Pr.591 Pr.591 Pr.591 Pr.586 Pr.584 Pr.585 Pr.589 Pr.589 Pr.589 Pr.588 Pr.588 Pr.588 Pr.587 Pr.587 Pr.587 Inverter...
Page 458 • When using two motors in the direct system (Pr.579 = "2") RIO1 RIO2 Pr. 580 Pr. 580 Pr. 580 Pr. 580 Pr. 580 Pr. 580 Pr. 590 Pr. 590 Pr. 590 Pr. 125 Pr. 125 Pr. 125 Pr. 584 Pr.
Page 459 NOTE • When the start signal is turned OFF during operation, the inverter-driven motor is decelerated to stop. The motors under commercial power supply operation are switched over to inverter-driven operation one at a time and decelerated to stop after frequency search in order from the longest operation time.
Page 460 5.11.11 PID control enhanced functions PID control enhanced functions can be used to perform PID control according to applications. Initial Name Setting range Description value 1361 Detection time for PID output Set the time from when the deviation falls within the PID output hold 0 to 900 s A440 hold...
Page 461 • When the deviation falls within the Pr.1362 PID output hold range and the elapsed time exceeds the Pr.1361 Detection time for PID output hold, the manipulated amount (PID output) is fixed at the output frequency at that time. • Even if the deviation falls out of the PID output hold range, the manipulated amount (PID output) is maintained for the detection time for PID output hold.
Page 462 • When Pr.579 Motor connection function selection = "1 or 3" (multi-pump function), the starting order of the motors is changed when the sleep function is activated. The stirring operation during the sleep is applied to the motor to be started first next time.
Page 463 • When the deviation exceeds the auxiliary pressure pump operation starting level (Pr.1374 Auxiliary pressure pump operation starting level - 1000%) after the PID output suspension function (sleep function) is activated, the auxiliary pressure pump starts and the Auxiliary pressure pump operation (Y226) signal turns ON. •...
Page 464  PID sleep boost (Pr.1366 to Pr.1368) • The pump pressure can be increased before the PID output suspension function (sleep function) is activated. This function is useful to prevent frequent repetition of starting and stopping of the pump, and to maintain the sleep state for a long period of time.
Page 465  PID upper/lower limit pre-warning (Pr.1346, Pr.1370 to Pr.1373) • The set point can be changed to suppress increases of the measured value before PID upper limit (FUP) or PID lower limit (FDN) is detected. • When the measured value reaches and remains at the pre-warning level set in Pr.1371 PID upper/lower limit pre- warning level range for the time set in Pr.1370 Detection time for PID limiting operation, the PID upper/lower limit pre- warning (Y219) signal or the Second PID upper/lower limit pre-warning (Y220) signal is output.
Page 466  PID dry run monitoring function (Pr.1370) • This function can prevent operation without water in the pipes by monitoring the flow rate (measured value) inside the pipes. When the flow rate decreases while the FU signal is ON, an output signal is sent for notification. •...
Page 467 • For the Y229 and Y230 signals, assign the functions using Pr.190 to Pr.196 (Output terminal function selection). Pr.190 to Pr.196 setting Output signal Positive logic Negative logic Y229 Y230 • To monitor the input pressure, set "69" in the monitor selection parameters. (0.1% increments) Parameter Setting Communication monitor code Pr.52, Pr.774 to...
Page 468 Initial value Setting Name Description range 0 (2) 1000 Frequency search only performed at the first start (1002) 1, 1001 Reduced voltage start only at the first start (no frequency search) Automatic restart after 3, 1003 Frequency search only performed at the first start (reduced impact restart) instantaneous power A700 10 (12)
Page 469  Connection (CS signal) • When the Selection of automatic restart after instantaneous power failure / flying start (CS) signal is assigned to the input terminal by setting "6" in Pr.178 to Pr.189 (Input terminal function selection), restart operation is enabled at turn-ON of the CS signal.
Page 470  Restart operation with frequency search (Pr.162 = "0, 2, 3, 10, 12, 13, 1000, 1002, 1003, 1010, 1012, or 1013", Pr.299) • When Pr.162 = "0 (initial value), 2, 3, 10, 12, 13, 1000, 1002, 1003, 1010, 1012, or 1013", the motor speed is detected at a power restoration so that the motor can re-start smoothly.
Page 471  Restart operation without frequency search (Pr.162 = "1, 11, 1001, or 1011") • When Pr.162 = "1 11, 1001, or 1011", reduced voltage start is used for the restart operation. In this method, the voltage is raised gradually while keeping the output frequency level at the level before an instantaneous power failure, regardless of the motor's coasting speed.
Page 472 • Inverter operation is sometimes hindered by the size of the moment of inertia (J) of the load or running frequency. Adjust this coasting time within the range 0.1 s to 30 s to match the load specification. • Set the waiting time when the sine wave filter is used (Pr.72 PWM frequency selection = "25") to 3 seconds or more. ...
Page 473 5.11.13 Automatic restart after instantaneous power failure/flying start with a PM motor When using the IPM motor MM-EFS or MM-THE4, the inverter operation can be restarted without stopping the motor operation. When the automatic restart after instantaneous power failure function is selected, the motor driving is resumed in the following situations: •...
Page 474  Selection of restart operation (Pr.162) • At a power restoration, the encoder detects the motor speed by a frequency search so that the inverter can re-start smoothly. • The encoder also detects the rotation direction so that the inverter can re-start smoothly even during the reverse rotation. •...
Page 475 0 to 32767 frequency search. Frequency search gain 9999 A711 The constant value of Mitsubishi Electric motor (SF-PR, SF-JR, SF- 9999 HR, SF-JRCA, SF-HRCA, MM-EFS, or MM-THE4) is used. The offline auto tuning automatically sets the gain required for the 0 to 32767 frequency search of the second motor.
Page 476 Set Pr.71 Applied motor according to the motor to be used. Motor Pr.71 setting SF-JR, SF-TH 0 (3, 4) SF-JR 4P 1.5 kW or lower 20 (23, 24) Mitsubishi Electric standard motor Mitsubishi Electric high-efficiency motor SF-HR 40 (43, 44) Others 0 (3, 4) SF-JRCA 4P, SF-TH (constant-torque)
Page 477 NOTE • It takes about 10 seconds for tuning to complete. (The time depends on the inverter capacity and motor type.) • Satisfy the required inverter start conditions to start offline auto tuning. For example, stop the input of the MRS signal. •...
Page 478 Perform an inverter reset and perform tuning again. Error display Error cause Countermeasures Forced end Set "11" in Pr.96 and retry. Inverter protective function operation Make the setting again. Set the acceleration/deceleration time longer. The current limit (stall prevention) function is activated. Set Pr.156 Stall prevention operation selection = "1".
Page 479 5.11.15 Power failure time deceleration-to-stop function This is a function to decelerate the motor to a stop when an instantaneous power failure or undervoltage occurs. Initial value Setting Name Description range Power failure time deceleration-to-stop function disabled Power failure stop 1, 2, 11, 12, Power failure time deceleration-to-stop function enabled.
Page 480 • The power failure time deceleration-to-stop function operates as follows at an input phase loss. Pr.261 Pr.872 Operation when an input phase loss occurs Operation continues Input phase loss (E.ILF) Operation continues 1, 2 Deceleration stop 21, 22 — Deceleration stop •...
Page 481  Power failure stop function (Pr.261 = "1, 11, or 21") • Even if power is restored during deceleration triggered by a power failure, deceleration stop is continued after which the inverter stays stopped. To restart operation, turn the start signal OFF then ON again. Pr.261 = "1"...
Page 482  Undervoltage avoidance function (Pr.261 = "11 or 12", Pr.294) • When "11 or 12" is set to Pr.261, the deceleration time is adjusted (shortened) to prevent an undervoltage from occurring during deceleration at occurrence of power failure. • Adjust the downward frequency slope and the response level using Pr.294 UV avoidance voltage gain. Setting a large value improves the response to the bus voltage.
Page 483 NOTE • When Pr.30 Regenerative function selection = "2" and the FR-HC2, FR-XC (in common bus regeneration mode), or FR-CV is used, the deceleration stop function is invalid at power failure. • If the "output frequency - Pr.262" at undervoltage or at power failure is a negative value, it is regarded as 0 Hz. (DC injection brake operation is performed without deceleration.) •...
Page 484 5.11.16 PLC function The inverter can be run in accordance with a sequence program. In accordance with the machine specifications, a user can set various operation patterns: inverter movements at signal inputs, signal outputs at particular inverter status, and monitor outputs, etc. Initial Setting Name...
Page 485 • The following shows the required conditions to enable the SQ signal. SQ signal Pr.414 setting Pr.338 setting Input via a communication virtual Input via an external (physical) terminal terminal 1, 11 — 2, 12 — — —: Not required to enable the SQ signal ...
Page 486  Copying the PLC function project data to USB memory • This function copies the PLC function project data to a USB memory device. The PLC function project data copied in the USB memory device can be copied to other inverters. This function is useful in backing up the parameter setting and for allowing multiple inverters to operate by the same sequence programs.
Page 487 Parameters referred to Pr.338 Communication operation command sourcepage 251 5.11.17 Trace function • The operating status of the inverter can be traced and saved on a USB memory device. • Saved data can be monitored by FR Configurator2, and the status of the inverter can be analyzed. Setting Name Initial value...
Page 488 Setting Name Initial value Description range 1038 Digital source selection (1ch) 1 A930 1039 Digital source selection (2ch) 2 A931 1040 Digital source selection (3ch) 3 A932 1041 Digital source selection (4ch) 4 A933 1 to 255 Select the digital data (I/O signal) for sampling on each channel. 1042 Digital source selection (5ch) 5 A934...
Page 489  Tracing procedure Preparing a USB memory device Select a USB memory device with ample capacity to store the necessary amount of trace data. When the trace function is used in the recorder mode, use a USB memory device with at least 1 GB of free space. Prior setting for tracing Set Pr.1021 to select a trace mode.
Page 490  Selection of sampling time (Pr.1022, Pr.1023) • The sampling time is determined by the sampling cycle and the number of data acquisition points. The number of data acquisition points differs between the memory mode and the recorder mode. • The sampling time in the memory mode varies depending on the settings in Pr.1022 Sampling cycle and Pr.1023 Number of analog channels.
Page 491  Analog source (monitor item) selection • Select the analog sources (monitor items) to be set to Pr.1027 to Pr.1034 from the following table. Trigger Trigger Setting Minus (-) Setting Minus (-) Monitor item level Monitor item level value display value display criterion...
Page 492 00023 00038 00105 00083 00126 00170 00250 00310 00380 00470 00620 00770 00930 01160 01800 02160 02600 03250 03610 04320 04810 05470 06100 06830 Model FR-F840-[] 0.75K 1.5K 2.2K 3.7K 5.5K 7.5K 15K 18.5K 22K 90K 110K 132K 160K 185K 220K 250K 280K 315K Trigger level reference current (A) 07700 08660 09620 10940 12120...
Page 493  Trigger setting (Pr.1025, Pr.1035 to Pr.1037, Pr.1046, Pr.1047) • Set the trigger generating conditions and the trigger target channels. Pr.1025 Selection of trigger Trigger generating conditions setting target channel Trace starts when inverter enters an fault status (protective function activated) —...
Page 494 • Trace operation can also be set in the trace mode on the operation panel. Monitor mode No function Sampling stop Parameter setting mode Sampling start Data transmission Function mode Trace method Forced trigger (Sampling stop)  Selection of trace operation by input terminal (TRG signal, TRC signal) •...
Page 495 • When copying the traced data to a USB memory device, the operating status of the USB host can be checked with the inverter LED. Refer to page 78 for an outline of the USB communication function. LED display status Operating status No USB connection.
Page 496: N) Communication Operation Parameters
5.12 (N) Communication operation parameters Refer Purpose Parameter to set page To start operation via Initial setting of operation via P.N000, P.N001, Pr.549, Pr.342, communication communication P.N013, P.N014 Pr.502, Pr.779 Initial setting of computer link To communicate via PU connector P.N020 to P.N028 Pr.117 to Pr.124 communication (PU connector)
Page 497 NOTE • Pins No. 2 and 8 provide power to the operation panel or parameter unit. Do not use these pins for RS-485 communication. • Do not connect the PU connector to the computer's LAN board, FAX modem socket, or telephone modular connector. The product could be damaged due to differences in electrical specifications.
Page 498 Do not use pins No. 2 and 8 of the communication cable. 5.12.2 Wiring and configuration of RS-485 terminals  RS-485 terminal layout Terminating resistor switch Initially-set to "OPEN". Set only the terminating resistor switch of the remotest inverter to the "100Ω" position. SDA1 SDB1 RDA1...
Page 499  System configuration of RS-485 terminals • Computer and inverter connection (1:1) Computer Computer Inverter Inverter RS-485 RS-485 RS-485 terminals terminals Maximum RS-232C ∗ ∗ interface/ 15 m cable terminals Converter Twisted pair cable Twisted pair cable ∗Set the terminating resistor switch to the "100Ω" position. •...
Page 500 • Wiring between a computer and multiple inverters for RS-485 communication Computer ∗2 ∗1 Station 0 Station 1 Station n Make connection in accordance with the Instruction Manual of the computer to be used with. Fully check the terminal numbers of the computer since they vary with the model. On the inverter most remotely connected with the computer, set the terminating resistor switch in the ON (100 Ω) position.
Page 501 5.12.3 Initial setting of operation via communication Set the action when the inverter is performing operation via communication. • Set the RS-485 communication protocol. (Mitsubishi inverter protocol / MODBUS RTU protocol) • Set the action at fault occurrence or at writing of parameters. Setting Name Initial value...
Page 502  Operation selection at a communication error (Pr.502, Pr.779) • For communication using RS-485 terminals or a communication option, operation at a communication error can be selected. The operation is active under the Network operation mode. • Select the stop operation at the retry count excess (Pr.335, enabled only when the Mitsubishi inverter protocol is selected) or at a signal loss detection (Pr.336, Pr.539).
Page 503 • The following charts show operations when a communication line error occurs. Pr.502 = "0" (initial value) Pr.502 = "1" Fault occurrence Fault removal Fault occurrence Fault removal Communication Communication fault fault Motor coasting Decelerates to stop Time Time Fault display Display Fault display Display...
Page 504 • The following charts show operations when a communication option fault occurs. Pr.502 = "0 (initial value) or 3" Pr.502 = "1 or 2" Fault occurrence Fault removal Fault removal Fault occurrence Fault Fault Motor coasting Decelerates to stop Time Time Fault display Fault display...
Page 505 CAUTION • When Pr.502 = "3" and a communication line error occurs, or Pr.502 = "4" and a communication line error or a communication option fault occurs, the operation continues. When setting "3 or 4" in Pr.502, provide a safety stop countermeasure other than via communication.
Page 506 5.12.4 Initial settings and specifications of RS-485 communication Use the following parameters to perform required settings for RS-485 communication between the inverter and a personal computer. • Use the PU connector on the inverter or RS-485 terminals as communication interface. •...
Page 507  Parameters related to RS-485 terminal communication Initial Name Setting range Description value 0 to 31 (0 to RS-485 communication Enter the station number of the inverter. *1*2 N030 station number (Same specifications as Pr.117) 247) 3, 6, 12, 24, 48, 96, RS-485 communication Select the communication speed.
Page 508 5.12.5 Mitsubishi inverter protocol (computer link communication) Parameter setting and monitoring, etc. are possible by using the Mitsubishi inverter protocol (computer link communication) via inverter PU connector and the RS-485 terminals.  Communication specifications • The communication specifications are shown in the following table. Related Item Description...
Page 509  Communication operation presence/absence and data format types • Data communication between the computer and inverter is made in ASCII code (hexadecimal code). • Communication operation presence/absence and data format types are as follows. Operation Operation Multi Parameter Inverter Parameter Symbol Operation Monitor...
Page 510 CR+LF code: When a computer transmits data to the inverter, some computers automatically provide either one or both of the codes CR (carriage return) and LF (line feed) at the end of a data group. In this case, the same setting is required for data sent from the inverter to the computer. Use Pr.124 or Pr.341 for the CR+LF code setting.
Page 511 • Instruction code Specify the processing request, for example, operation or monitoring, given by the computer to the inverter. Therefore, the operation or monitoring an item is enabled by specifying the corresponding instruction code. (Refer to page 515.) • Data Read/write data such as parameters transmitted from/to the inverter.
Page 512 • Error code If any error is found in the data received by the inverter, its error definition is sent back to the computer together with the NAK code. Error code Error item Error description Inverter operation The number of errors consecutively detected in Computer NAK error communication request data from the computer is greater than the permissible number of retries.
Page 513 Data check time Item Check time Monitoring, operation command, frequency setting (RAM) Less than 12 ms Parameter read/write, frequency setting (EEPROM) Less than 30 ms Parameter clear / All parameter clear Less than 5 s Reset command No reply  Retry count setting (Pr.121, Pr.335) •...
Page 514  Signal loss detection (Pr.122, Pr.336 RS-485 communication check time interval) • If signal loss is detected between the inverter and computer, the communication error (PU connector communication: E.PUE, RS-485 terminal communication: E.SER) will occur and the inverter output will be shut off. •...
Page 515  Programming instructions • When data from the computer has any error, the inverter does not accept that data. Hence, in the user program, always insert a retry program for data error. • All data communication, for example, run command or monitoring, are started when the computer gives a communication request.
Page 516 General flowchart Port open Communication setting Time out setting Send data processing ○Data setting ○Sum code calculation ○Data transmission Receive data waiting Receive data processing ○Receive data processing ○Screen display CAUTION • Always set the communication check time interval before starting operation to prevent hazardous conditions. •...
Page 517 Number of Read/ Instruction Item Data description data digits write code (format) Output H0000 to HFFFF: Output frequency in 0.01Hz increments (The display can 4 digits (B and frequency / Read be changed to the rotations per minute using Pr.37 and Pr.144. (Refer to E/D) speed page...
Page 518 Number of Read/ Instruction Item Data description data digits write code (format) All parameters return to initial values. Whether to clear communication parameters or not can be selected according to the data. • Parameter clear H9696: Parameters including communication parameters are cleared. H5A5A: Parameters other than communication parameters are cleared.
Page 519  List of calibration parameters Instruction code Instruction code Name Name Read Write Extended Read Write Extended Terminal 2 frequency setting Terminal 1 gain command (902) bias frequency (920) (torque) Terminal 2 frequency setting Terminal 1 gain (torque) (902) bias (920) Terminal 2 frequency setting Current output bias signal...
Page 520 The Inverter run enable signal is in the initial status for the separated converter type. JOG operation/automatic restart after instantaneous power failure/start self-holding selection/reset cannot be controlled over a network, so in the initial status bit 8 to bit 11 are invalid. To use bit 8 to bit 11, change the signal by Pr.185, Pr.186, Pr.188, or Pr.189 (Input terminal function selection) (page 373) (A reset can be executed by the instruction code HFD.)
Page 521 Combination of data 1 and data 2 for reply Data type Data 1 Data 2 Remarks Inverter status monitor Output frequency Inverter status monitor (extended) is same as instruction code H79. (extended) (speed) (Refer to page 519.) Replies the monitor item specified in instruction Inverter status monitor code HF3 for special monitor.
Page 522  Communication specifications • The communication specifications are shown in the following table. Item Description Related parameter Communication protocol MODBUS RTU protocol Pr.549 Conforming standard EIA-485 (RS-485) — Number of connectable units 1: N (maximum 32 units), setting is 0 to 247 stations Pr.331 Selected among 300/600/1200/2400/4800/9600/19200/38400/57600/76800/ Communication speed...
Page 523 • Normal response After the query from the master is received, the slave executes the request function, and returns the corresponding normal response to the master. • Error Response When an invalid function code, address or data is received by the slave, the error response is returned to the master. This response is appended with an error code that indicates the reason why the request from the master could not be executed.
Page 524  Function code list Message Read/ Broadcast format Function name Code Outline write communication reference page The data of the holding registers is read. The various data of the inverter can be read from MODBUS registers. System environmental variable (Refer to page 528.) Read holding register...
Page 525  Example) Read the register values of 41004 (Pr.4) to 41006 (Pr.6) from slave address 17 (H11). Query message Slave address Function Starting address No. of points CRC check (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) Normal response (Response message)
Page 526  Diagnostics (diagnosis of functions) (H08 or 08) • A communication check can be made since the query message is sent and the query message is returned as it is as the return message (subfunction code H00 function). Subfunction code H00 (Return query data) •...
Page 527  Example) Write 0.5 s (H05) to 41007 (Pr.7) and 1 s (H0A) to 41008 (Pr.8) of slave address 25 (H19). Query message Slave Function Starting address No. of registers Byte count Data CRC check address (8 bits) (8 bits) (8 bits) (8 bits) (8 bits)
Page 528 NOTE • No response is also returned in the case of broadcast communication. • Error response (Response message) a. Slave address b. Function c. Exception code CRC check H80 + Function (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) Message Description Slave address...
Page 529  MODBUS register • The following shows the MODBUS registers for system environment variables (read/write), real time monitor items (read), parameters (read/write), fault history data (read/write), and model information monitor items (read). • System environment variables Register Definition Read/write Remarks 40002 Inverter reset Write...
Page 530 Writing is available depending on the Pr.79 and Pr.340 settings. For the details, refer to page 250. Restrictions in each operation mode conform with the computer link specification. • Real time monitor Refer to page 305 for the register numbers and monitor items of the real time monitor. •...
Page 531 Register Name Read/write Remarks 42124 PID display bias analog value Read/write Analog value (%) set in C43 (934) C43 (934) PID display bias analog value (terminal Analog value (%) of the current (voltage) applied to 43934 Read analog value) terminal 4 C44 (935) 41935 PID display gain coefficient Read/write...
Page 532  Alarm (LF) signal output (communication error warning) • During a communication error, the Alarm (LF) signal is output by open collector output. Assign the terminal to be used using any of Pr.190 to Pr.196 (Output terminal function selection). Master Alarm data Alarm data Alarm data...
Page 533  Signal loss detection (Pr.539 RS-485 communication check time interval) • If signal loss is detected between the inverter and the master, the Communication fault (inverter) (E.SER) will occur and the inverter output will be shut off. • When the setting is "9999", communication check (signal loss detection) is not made. •...
Page 534 5.12.7 BACnet MS/TP protocol Using BACnet MS/TP protocol, communication operation and parameter setting are available from the RS-485 terminals of the inverter. Initial value Name Setting range Description 0, 5 to 14, 17, 18, 20, 23 to 81: BACnet reception status Operation panel main 25, 34, 38, 40 to 45, 50 to 82: BACnet token pass counter (Displays the count of...
Page 535  Communication specifications • The specifications conform to the BACnet standard of physical medium EIA-485. Item Description Physical medium EIA-485 (RS-485) Connection port RS-485 terminals (PU connector is not available.) Data transfer method NRZ encoding Baud rate 9600 bps, 19200 bps, 38400 bps, 57600 bps, 76800 bps, 115200 bps Start bit Fixed to 1 bit Data length...
Page 536  BACnet reception status monitor (Pr.52) • Set Pr.52 = "81" to monitor the BACnet communication status on the operation panel. Monitor LF signal Status Description value output Idle Never had BACnet communication. Automatic baud rate recognition. Automatic baud rate (Communication error during automatic baud rate recognition is not recognition counted.)
Page 537  Supported property of BACnet standard object type R: Read only, W: Read/Write (Commandable values not supported), C: Read/Write (Commandable values supported) Object support condition Property Analog Analog Analog Binary Binary Binary Network Device input Output Value Input Output Value Port APDU Timeout Application Software Version...
Page 538  Details of the supported properties • The details of the properties supported by the network port are as follows. Property Details Shows the maximum number of frames that the inverter can transmit while it owns the token. When Max Info Frames a value is written, it is reflected to the Pr.727 setting.
Page 539 • ANALOG OUTPUT Present Value Object Identifier Object Name Description Unit Access Type Controls actual output current level of terminal FM/CA. Control is available when Pr.54 FM/CA terminal function percent Terminal FM (CA) (98) selection = "85" (Setting range: 0% to 200%) Controls actual output voltage level of terminal AM.
Page 540 Present Value Object Identifier Object Name Description Unit Access Type Set the PID action set point. PID set point no-units This object is the set point during PID operation if Pr.128 = "60 or (95) 61". (Setting range: 0.00 to 100.00) Set the PID measured value.
Page 541 • BINARY OUTPUT Present Value Description Object Identifier Object Name Access Type (0: Inactive, 1: Active) Represents actual output of terminal RUN. Terminal RUN CMD C Available when Pr.190 RUN terminal function selection = "82 or 182". Controls actual output of terminal SU. Terminal SU CMD Available when Pr.191 SU terminal function selection = "82 or 182".
Page 542 • BINARY VALUE Present Value Object Identifier Object Name Description Access Type Inverter running Represents the Inverter running (RUN) signal status. Inverter operation Represents the Inverter operation ready (RY) signal status. ready Alarm output Represents the Alarm (LF) signal status. Fault output Represents the Fault (ALM) signal status.
Page 543 • System environment variables Register Definition Read/write Remarks The data is written as an operation mode setting for writing. 40010 Operation mode / inverter setting Read/write The data is read as the operation mode status for reading. [Operation mode / inverter setting] Mode Read value Write value...
Page 544 Register Name Read/write Remarks C18 (920) 41920 Terminal 1 gain command (torque) Read/write 42110 Terminal 1 gain (torque) Read/write Analog value (%) set in C19 (920) C19 (920) Terminal 1 gain (torque) Analog value (%) of voltage applied to 43920 Read (terminal analog value) terminal 1...
Page 545 (This annex is part of this Standard and is required for its use.) BACnet Protocol Implementation Conformance Statement Date: 1st Jul 2014 Vendor Name: Mitsubishi Electric Corporation Product Name: Inverter Product Model Number: FR-F820-1, FR-F820-2, FR-F840-1, FR-F840-2, FR-F842-1, FR-F842-2, FR-F846-1, FR-F846-2,...
Page 546 List of proprietary properties and for each its property identifier, datatype, and meaning List of any property range restrictions Dynamic object creation and deletion is not supported. To check the object types supported by the FR-F800 series, refer to page 537.
Page 547 Character Sets Supported: Indicating support for multiple character sets does not imply that they can all be supported simultaneously. ISO 10646 (UTF-8) ISO 8859-1 /Microsoft DBCS ISO 10646 (UCS-2) ISO 10646 (UCS-4) JIS X 0208 Gateway Options: If this product is a communication gateway, describe the types of non-BACnet equipment/networks(s) that the gateway supports: If this product is a communication gateway which presents a network of virtual BACnet devices, a separate PICS shall be provided that describes the functionality of the virtual BACnet devices.
Page 548 5.12.8 USB device communication A personal computer and an inverter can be connected with a USB cable. Setup of the inverter can be easily performed with FR Configurator2. The inverter can be connected easily to a personal computer by a USB cable. Initial Name Setting range...
Page 549 5.12.9 Automatic connection with GOT When the automatic connection is enabled in the GOT2000 series, the inverter can communicate with the GOT2000 series with only setting the station number and connecting the GOT. This eliminates the need for the communication parameter setting.
Page 550 NOTE • If the automatic recognition cannot be performed, initial setting in Pr.999 is required. • For connecting the inverter to the GOT2000 series using the RS-485 terminal block, set Pr.549 Protocol selection = "0 (initial value) or 1". • For connection to a device other than the GOT2000 series, initial setting in Pr.999 is required. •...
Page 551  Backup/restore operation • The GOT backs up all applicable data in all the inverters that can be identified with the network numbers and station numbers in the controller list file. • The GOT restores all relevant data of the inverters selected based on the network numbers and station numbers using the backup data.
Page 552: (G) Control Parameters
5.13 (G) Control parameters Refer to Purpose Parameter to set page To set the starting torque manually Manual torque boost P.G000, P.G010 Pr.0, Pr.46 Base frequency, base frequency P.G001, P.G002, To set the motor constant Pr.3, Pr.19, Pr.47 voltage P.G011 To select the V/F pattern matching the Load pattern selection P.G003...
Page 553 Initial value for the FR-F820-00046(0.75K) or lower and FR-F840-00023(0.75K) or lower. Initial value for the FR-F820-00077(1.5K) to FR-F820-00167(3.7K) and the FR-F840-00038(1.5K) to FR-F840-00083(3.7K). Initial value for the FR-F820-00250(5.5K), FR-F820-00340(7.5K), FR-F840-00126(5.5K), and FR-F840-00170(7.5K). Initial value for the FR-F820-00490(11K) to FR-F820-01540(37K), and the FR-F840-00250(11K) to FR-F840-00770(37K). Initial value for the FR-F820-01870(45K), FR-F820-02330(55K), FR-F840-00930(45K), and FR-F840-01160(55K).
Page 554 As a result, the inverter output may be shut off due to overload. A caution is required especially in case of Pr.14 Load pattern selection = "1" (variable torque load). • When using the Mitsubishi Electric constant torque motor, set Pr.3 to 60 Hz. Pr.19...
Page 555 5.13.3 Load pattern selection Optimal output characteristics (V/F characteristics) for application or load characteristics can be selected. Setting Name Initial value Description range For constant-torque load For variable-torque load Load pattern selection G003 Excitation current low-speed scaling factor (Refer to page 555.) 12 to 15...
Page 556 5.13.4 Excitation current low-speed scaling factor Magnetic flux Magnetic flux Magnetic flux Under Advanced magnetic flux vector control, the excitation current scaling factor in the low-speed range can be adjusted. Name Initial value Setting range Description Excitation current low-speed scaling factor: Pr.86 0, 1 Refer to page 554...
Page 557 • An excitation current low-speed scaling factor set in the parameter shown in the table is used according to the Pr.14 setting and other conditions. During forward rotation During reverse rotation Pr.14 setting RT signal OFF RT signal ON RT signal OFF RT signal ON 0, 1 Pr.86...
Page 558 5.13.5 Energy saving control Magnetic flux Magnetic flux Magnetic flux The inverter will automatically perform energy saving operation without setting detailed parameters. This control method is suitable for applications such as fans and pumps. Name Initial value Setting range Description Normal operation Energy saving Energy saving operation...
Page 559 5.13.6 Adjustable 5 points V/F By setting a desired V/F characteristic from the start up to the base frequency or base voltage with the V/F control (frequency voltage/frequency), a dedicated V/F pattern can be generated. The optimal V/F pattern matching the torque characteristics of the facility can be set. Name Initial value Setting range...
Page 560 NOTE • The adjustable 5 points V/F is enabled under V/F control. • When Pr.19 Base frequency voltage = "8888 or 9999", setting of Pr.71 = "2" is not available. To set "2" in Pr.71, set the rated motor voltage in Pr.19. •...
Page 561 5.13.8 DC injection brake • Adjust the braking torque and timing to stop the motor using the DC injection brake. By the DC injection brake operation, DC voltage is applied to the motor to prevent rotation of the motor shaft. When a motor shaft is rotated by external force, the motor shaft does not go back to the original position.
Page 562 • For the X13 signal input, set "13" in any parameter from Pr.178 to Pr.189 to assign the function. When Pr. 11 = "8888" Time Pr.12 DC injection Time brake voltage ON OFF X13 signal NOTE • The X13 signal is disabled during PM motor control. ...
Page 563 5.13.9 Output stop function The motor coasts to a stop (inverter output is shutoff) when the inverter output frequency falls to Pr.522 setting or lower. Setting Name Initial value Description range 0 to 590 Hz Set the frequency to start coasting to a stop (output shutoff). Output stop frequency 9999 G105...
Page 564 NOTE • When the output stop function is enabled (Pr.522 ≠ "9999"), the DC injunction brake operation is disabled and the motor coasts to stop when the output frequency drops to the Pr.522 setting or lower. • The motor starts acceleration again at Pr.13 Starting frequency (0.01 Hz under PM motor control) when the command value exceeds Pr.522 + 2 Hz again if the start signal remains ON while the motor is coasting after the frequency drops to the Pr.522 setting or lower.
Page 565  To coast the motor to a stop • Set the time required to shut off the output after the start signal is turned OFF in Pr.250. When "1000 to 1100" is set, output is shut off after a lapse of the (Pr.250 - 1000) seconds. •...
Page 566 NOTE • By setting Pr.250 = "0 to 100, 1000 to 1100", the motor will coast to a stop when the start command is turned OFF. • The STF and STR signals are assigned to terminals STF and STR in the initial status. The STF signal can be assigned to terminal STF only using Pr.178 STF terminal function selection, and the STR signal can be assigned to terminal STR only using Pr.179 STR terminal function selection.
Page 567 Pr.75 Reset selection/disconnected PU detection/PU stop selectionpage 196 Pr.178 to Pr.189 (Input terminal function selection)page 373 Pr.261 Power failure stop selectionpage 478 Pr.502 Stop mode selection at communication errorpage 500 5.13.11 Regenerative brake selection and DC feeding mode • For operation with frequent starts and stops, the regenerative power can be consumed by using the optional brake unit (FR-BU2, BU, or FR-BU).
Page 568 • FR-F842-07700(355K) or higher Regeneration unit Pr.30 setting Without regenerative function (FR-CC2) 10 (initial value), 110 Brake unit 11, 111 (FR-CC2+FR-BU2 (MT-BR5)) High power factor converter (FR-HC2) 2, 102 While the power is supplied only to the control circuit with Pr.30 = "100 or higher", the inverter reset is not performed when the power is supplied to the main circuit.
Page 569 NOTE • For details on connecting the brake unit, high power factor converter (FR-HC2), multifunction regeneration converter (FR-XC), or power regeneration common converter (FR-CV), refer to page 80. For details of each option, refer to the Instruction Manual of each option. •...
Page 570  Selection between resetting or not resetting during power supply to main circuit (Pr.30 = "100, 101, 102, 110, 111, 120, or 121") • Inverter reset is not performed if Pr.30 = "100" or more, and supplying power to the main circuit (input through terminals R/L1, S/L2, and T/L3) is started when power is supplied only to the control circuit (input through terminals R1/L11 and S1/ L12, or 24 V external power supply input).
Page 571 Signal name Name Description Parameter setting To operate with DC feeding, turn ON the X70 signal. When the inverter output is shutoff due to power failure, it will be possible to start up 200 ms after turning ON the X70 signal. (Automatic DC feeding operation Set "70"...
Page 572 • Operation example at the time of power failure occurrence 1 AC power supply DC power supply Control power supply AC power supply Y85(MC) STF(STR) Motor Output coasting frequency (Hz) Time Approx. 200ms Back up operation • Operation example at the time of power failure occurrence 2 (when the AC power supply is restored) Control power supply Power restoration AC power supply...
Page 573  Power supply specification for DC feeding (standard models and IP55 compatible models) Rated input DC voltage 283 to 339 VDC 200 V class Permissible fluctuation 240 to 373 VDC Rated input DC voltage 537 VDC to 707 VDC 400 V class Permissible fluctuation 457 VDC to 777 VDC NOTE...
Page 574  Regeneration avoidance operation (Pr.882, Pr.883) • When the regenerative voltage increases, the DC bus voltage will rise, which may cause an overvoltage fault (E.OV[]). The regenerative status can be avoided by detecting this rise of bus voltage, and raising the frequency when the bus voltage level exceeds Pr.883 Regeneration avoidance operation level.
Page 575 • Set the frequency around the motor rated slip frequency. Increase the setting value if the overvoltage protection function (E.OV[]) is activated at the start of deceleration. Synchronized speed at the time of base frequency – rated rotation speed Rated motor slip frequency = ×...
Page 576 • Increased magnetic excitation deceleration will be disabled when Pr.661 = "0". When "8888 or 9999" is not set in Pr.19 under V/F control, increased magnetic excitation deceleration will be enabled even when Pr.661 = "0". • When the DC bus voltage exceeds the increased magnetic excitation deceleration operation level during the deceleration, excitation is increased in accordance with the setting value in Pr.661.
Page 577 5.13.14 Slip compensation Under V/F control, the slip of the motor is estimated from the inverter output current to maintain the rotation of the motor constant. Setting Name Initial value Description range 0.01% to Set the rated motor slip. Rated slip 9999 G203 0, 9999...
Page 578 5.13.15 Speed smoothing control The output current (torque) of the inverter sometimes becomes unstable due to vibration caused by mechanical resonance. Such vibration can be suppressed by reducing fluctuation of the output current (torque) by changing the output frequency. Setting Name Initial value Description...
Page 579: Parameter Clear / All Parameter Clear
5.14 Parameter clear / All parameter clear • Set "1" to Pr.CLR Parameter clear or ALL.CL All parameter clear to initialize all parameters. (Parameters cannot be cleared when Pr.77 Parameter write selection = "1".) • Pr.CLR does not clear calibration parameters or the terminal function selection parameters. •...
Page 580: 5.15 Copying And Verifying Parameters On The Operation Panel
581.) NOTE • When the copy destination is other than the FR-F800 series or when parameter copy is attempted after the parameter copy reading was stopped, the product series error " " appears. • Refer to the parameter list on page 668 for the availability of parameter copy.
Page 581  Writing parameter settings stored in the operation panel to the inverter Operating procedure Connect the operation panel to the destination inverter. Selecting the parameter setting mode Press to choose the parameter setting mode. (The parameter number read previously appears.) Selecting the parameter Turn to "...
Page 582 5.15.2 Parameter verification • Whether the parameter settings of inverters are the same or not can be checked. Operating procedure Copy the parameter settings of the verification source inverter to the operation panel according to the procedure on page 579. Detach the operation panel from the source inverter and attach it to the verification target inverter.
Page 583: 5.16 Copying And Verifying Parameters Using A Usb Memory
5.16 Copying and verifying parameters using a USB memory • Inverter parameter settings can be copied to a USB memory device. • Parameter setting data stored in a USB memory device can be copied to another inverter or verified to see if they differ from the parameter settings of another inverter.
Page 584 NOTE • When parameter settings are copied to the USB memory without specifying a parameter setting file number in the USB memory, numbers are automatically assigned. • Up to 99 files can be saved in the USB memory. When the USB memory already has 99 files, attempting copying of another file to the USB memory causes the file quantity error (rE7).
Page 585 After setting Pr.989, perform setting of Pr.9, Pr.30, Pr.51, Pr.56, Pr.57, Pr.61, Pr.70, Pr.72, Pr.80, Pr.82, Pr.90 to Pr.94, Pr.453, Pr.455, Pr.458 to Pr.462, Pr.557, Pr.859, Pr.860, and Pr.893 again. • When the copy destination is other than the FR-F800 series or when parameter copy is attempted after the parameter copy reading was stopped, the model error "...
Page 586  Procedure for verifying parameters in the USB memory Operating procedure Copy the parameter settings of the verification source inverter to the USB memory according to the procedure on page 583. Move the USB memory device to the inverter to be verified. Turning ON the power of the inverter The operation panel is in the monitor mode.
Page 587: Checking Parameters Changed From Their Initial Values (Initial Value Change List)
5.17 Checking parameters changed from their initial values (initial value change list) Parameters changed from their initial values can be displayed. Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode. Selecting the parameter setting mode Press to choose the parameter setting mode.
Page 588 CHAPTER 6 PROTECTIVE FUNCTIONS Inverter fault and alarm indications........................588 Reset method for the protective functions ......................589 Check and clear of the fault history ........................590 List of fault displays ..............................592 Causes and corrective actions..........................594 Check first when you have a trouble........................612 Downloaded from ManualsNet.com search engine...
Page 589 PROTECTIVE FUNCTIONS This chapter explains the "PROTECTIVE FUNCTIONS" that operate in this product. Always read the instructions before use. Inverter fault and alarm indications • When the inverter detects a fault, depending on the nature of the fault, the operation panel displays an error message or warning, or a protective function is activated to shut off the inverter output.
Page 590 Reset method for the protective functions Reset the inverter by performing any of the following operations. Note that the accumulated heat value of the electronic thermal relay function and the number of retries are cleared (erased) by resetting the inverter. The inverter recovers about 1 second after the reset is released.
Page 591 Check and clear of the fault history The operation panel stores the past eight fault records which appears when a protective function is activated. (Fault history)  Check for the fault history Parameter setting mode Monitor mode Function mode Fault history mode [Operation for displaying fault history] The last eight fault records can be displayed.
Page 592  Fault history clearing procedure • Set Err.CL Fault history clear = "1" to clear the fault history. Operating procedure Turning ON the power of the inverter The operation panel is in the monitor mode. Selecting the parameter setting mode Press to choose the parameter setting mode.
Page 593 List of fault displays If the displayed message does not correspond to any of the Operation panel Refer following or if you have any other problem, contact your sales Name indication to page representative. Fan alarm  Error message Internal fan alarm •...
Page 594  Data code 200 or more Operation panel Data Refer Name indication code to page Operation panel Data Refer Communication option Name indication code to page fault (HA1) USB communication fault (HC8) (HA4) Safety circuit fault (HC9) (HA5) User definition error by the (HCA) PLC function (HA6)
Page 595 Causes and corrective actions  Error message A message regarding operational troubles is displayed. Output is not shut off. Operation panel HOLD indication Name Operation panel lock Description Operation lock is set. Operation other than is invalid. (Refer to page 202.) Check point --------------...
Page 596 Operation panel indication Name USB memory device operation error • An operation command was given during the USB memory device operation. Description • A copy operation (writing) was performed while the PLC function was in the RUN state. • A copy operation was attempted for a password locked project. •...
Page 597 • Check that parameter copy to the operation panel was not interrupted by switching OFF the power or by disconnecting the operation panel. • Perform parameter copy and parameter verification between inverters of the same model (FR-F800 series). Corrective action •...
Page 598  Warning Output is not shut off when a protective function is activated. Operation panel FR-LU08 indication OL indication Name Stall prevention (overcurrent) • When the output current of the inverter increases, the stall prevention (overcurrent) function is activated. • The following section explains about the stall prevention (overcurrent) function. When the inverter output current exceeds the stall prevention level (Pr.22 Stall prevention operation level, etc.), this function stops the increase in frequency until the During acceleration...
Page 599 Operation panel FR-LU08 indication PS indication Name PU stop • The motor is stopped using under the mode other than the PU operation mode. (To enable Description under the mode other than the PU operation mode, set Pr.75 Reset selection/disconnected PU detection/PU stop selection.
Page 600 Operation panel FR-LU08 indication CF indication Name Continuous operation during communication fault Appears when the operation continues while an error is occurring in the communication line or communication Description option (when Pr.502 = "4"). • Check for a break in the communication cable. Check point •...
Page 601  Fault When a protective function is activated, the inverter output is shut off and a Fault signal is output. Operation panel E.OC1 FR-LU08 indication OC During Acc indication Name Overcurrent trip during acceleration When the inverter output current reaches or exceeds approximately 170% (LD rating) / 148% (SLD rating) of the Description rated current during acceleration, the protection circuit is activated and the inverter output is shut off.
Page 602 Operation panel E.OC3 FR-LU08 indication OC During Dec indication Name Overcurrent trip during deceleration or stop When the inverter output current reaches or exceeds approximately 170% (LD rating) / 148% (SLD rating) of the Description rated current during deceleration (other than acceleration or constant speed), the protection circuit is activated and the inverter output is shut off.
Page 603 Operation panel E.OV3 FR-LU08 indication OV During Dec indication Name Regenerative overvoltage trip during deceleration or stop If regenerative power causes the inverter's internal main circuit DC voltage to reach or exceed the specified Description value, the protection circuit is activated to stop the inverter output. The circuit may also be activated by a surge voltage produced in the power supply system.
Page 604 Operation panel E.IPF FR-LU08 indication Instant Pwr failure indication Name Instantaneous power failure (Standard models and IP55 compatible models only) If a power failure occurs (or when power input to the inverter is shut off) for longer than 15 ms , the instantaneous power failure protective function is activated to shut off the inverter output in order to prevent the control circuit from malfunctioning.
Page 605 Operation panel E.OLT FR-LU08 indication Stall prevention STP indication Name Stall prevention stop Magnetic flux Magnetic flux Magnetic flux If the output frequency has fallen to 0.5 Hz by stall prevention operation and remains for 3 seconds, a fault (E.OLT) appears and the inverter is shut off. OL appears while stall prevention is being activated. Description During speed control, a fault (E.OLT) appears and the inverter output is shut off if the frequency value converted from the motor rotation speed drops to 1.5 Hz or lower by stall prevention operation and the output torque...
Page 606 Operation panel E.GF FR-LU08 indication Ground Fault indication Name Output side earth (ground) fault overcurrent The inverter output is shut off if an earth (ground) fault overcurrent flows due to an earth (ground) fault that Description occurred on the inverter's output side (load side). Check point Check for a ground fault in the motor and connection cable.
Page 607 Operation panel E.OP1 FR-LU08 indication Option1 Fault indication Name Communication option fault Description The inverter output is shut off if a communication line error occurs in the communication option. • Check for an incorrect option function setting and operation. • Check that the plug-in option is plugged into the connector securely. Check point •...
Page 608 Operation panel E.RET FR-LU08 indication Retry count excess indication Name Retry count excess The inverter output is shut off if the operation cannot be resumed properly within the number of retries set in Pr.67 Description Number of retries at fault occurrence. This function is available when Pr.67 is set. This protective function is not available in the initial setting (Pr.67 = "0").
Page 609 Operation panel E.CDO FR-LU08 indication OC detect level indication Name Abnormal output current detection The inverter output is shut off if the output current exceeds the Pr.150 Output current detection level setting. Description This functions is available when "1" is set in Pr.167 Output current detection operation selection. When the initial value (Pr.167 = "0") is set, this protective function is not available.
Page 610 Operation panel E.SAF FR-LU08 indication Safety circuit fault indication Name Safety circuit fault • The inverter output is shut off when a safety circuit fault occurs. • The inverter output is shut off if the either of the wire between S1 and SIC or S2 and SIC becomes non- conductive while using the safety stop function.
Page 611 Operation panel E.PCH FR-LU08 indication Pre-charge fault indication Name Pre-charge fault The inverter output is shut off when the pre-charge time exceeds Pr.764 Pre-charge time limit. The inverter output is shut off when the measured value exceeds Pr.763 Pre-charge upper detection level during pre- Description charging.
Page 612 Operation panel FR-LU08 indication — indication Name 24 V external power supply operation Description Blinks when the main circuit power supply is off and the 24 V external power supply is being input. Check point • Power is supplied from a 24 V external power supply. •...
Page 613 Check first when you have a trouble • If the cause is still unknown after every check, it is recommended to initialize the parameters, set the required parameter values and check again. 6.6.1 Motor does not start Check Refer to Possible cause Countermeasure point...
Page 614 Check Refer to Possible cause Countermeasure point page Check the start command source, and input a start signal. A start signal is not input. PU operation mode: External operation mode: STF/STR signal Turn ON only one of the forward and reverse rotation start signals Both the forward and reverse rotation start (STF or STR).
Page 615 Check Refer to Possible cause Countermeasure point page Increase the Pr.0 setting by 0.5% increments while observing the Under V/F control, Pr.0 Torque boost rotation of a motor. setting is not appropriate. If that makes no difference, decrease the setting. Check the Pr.78 setting.
Page 616 6.6.2 Motor or machine is making abnormal acoustic noise Check Refer to Possible cause Countermeasure point page Input Take countermeasures against EMI. Disturbance due to EMI when the signal frequency or torque command is given Parameter Increase the Pr.74 Input filter time constant setting if steady through analog input terminal 1, 2, or 4.
Page 617 6.6.5 Motor rotates in the opposite direction Check Refer to Possible cause Countermeasure point page Main The phase sequence of output terminals U, V Connect the output side terminals (terminals U, V, and W) circuit and W is incorrect. correctly. The start signals (STF and STR signals) are Check the connection.
Page 618 6.6.8 Speed varies during operation Under Advanced magnetic flux vector control, the output frequency varies between 0 and 2 Hz as the load fluctuates. This is a normal operation and not a fault. Check Refer to Possible cause Countermeasure point page Load The load varies during an operation.
Page 619 6.6.10 Operation panel (FR-DU08) display is not operating Check Refer to Possible cause Countermeasure point page Main circuit The power is not input. Input the power. Control circuit Front The operation panel is not properly Check if the inverter front cover is installed securely. cover connected to the inverter.
Page 620 6.6.12 Speed does not accelerate Check Refer to Possible cause Countermeasure point page The start command or frequency command Check if the start command and the frequency command are — is chattering. correct. The wiring length is too long for the analog Input frequency command, causing a voltage Perform the bias and gain calibration for the analog input.
Page 621 6.6.14 Power lamp is not lit Check Refer to Possible cause Countermeasure point page Main Check for secure wiring and installation. circuit The wiring or installation is inadequate. The power lamp is lit when power is supplied to the control circuit (R1/ Control L11, S1/L21).
Page 622 CHAPTER 7 PRECAUTIONS FOR MAINTENANCE AND INSPECTION Inspection item..............................622 Measurement of main circuit voltages, currents, and powers................632 Downloaded from ManualsNet.com search engine...
Page 623 PRECAUTIONS FOR MAINTENANCE AND INSPECTION This chapter explains the precautions for maintenance and inspection of this product. Always read the instructions before use. For the precautions for maintenance and inspection of the separated converter type inverter, refer to the FR-F802 (Separated Converter Type) Instruction Manual (Hardware).
Page 624 7.1.3 Daily and periodic inspection Inspection Corrective action Area of Inspection Check interval Description at fault inspection item by user occurrence Daily Periodic Surrounding Check the surrounding air temperature, humidity, dirt, Improve the ○ environment corrosive gas, oil mist, etc. environment.
Page 625 Oil component of the heat dissipation grease used inside the inverter may leak out. The oil component, however, is not flammable, corrosive, nor conductive and is not harmful to humans. Wipe off such oil component. It is recommended to install a voltage monitoring device for checking the voltage of the power supplied to the inverter. One to two years of periodic inspection cycle is recommended.
Page 626  Module device numbers and terminals to be checked Tester polarity Tester polarity Continuity Continuity R/L1 R/L1 R/L1 R/L1 S/L2 S/L2 Converter module S/L2 S/L2 T/L3 T/L3 T/L3 T/L3 Inverter module (Assuming that an analog meter is used.) Converter module Inverter module R/L1 S/L2...
Page 627 7.1.6 Replacement of parts The inverter consists of many electronic parts such as semiconductor devices. The following parts may deteriorate with age because of their structures or physical characteristics, leading to reduced performance or fault of the inverter. For preventive maintenance, the parts must be replaced periodically. Use the life check function as a guidance of parts replacement.
Page 628  Replacement procedure of the cooling fan The replacement interval of the cooling fan used for cooling the parts generating heat such as the main circuit semiconductor is greatly affected by the surrounding air temperature. When unusual noise and/or vibration are noticed during inspection, the cooling fan must be replaced immediately.
Page 629  Installation (FR-F820-00105(2.2K) to 04750(110K), FR-F840-00083(3.7K) to 03610(160K)) After confirming the orientation of the fan, install the fan so that the "AIR FLOW" arrow faces up. AIR FLOW <Fan side face> Connect the fan connectors. FR-F820-00105(2.2K) to 00250(5.5K) FR-F820-00340(7.5K) to 00770(18.5K) FR-F840-00083(3.7K), 00126(5.5K) FR-F840-00170(7.5K) to 00380(18.5K) FR-F820-00930(22K), 01250(30K)
Page 630  Removal (FR-F840-04320(185K) or higher) Remove the screws attaching the fan cover, then remove the cover itself. Disconnect the fan connector, then remove the fan block itself. Remove the fan fixing screws, and remove the fan. Fan *1 Fan block Fan cover Fan connection connector...
Page 631  Smoothing capacitors A large-capacity aluminum electrolytic capacitor is used for smoothing in the DC section of the main circuit, and an aluminum electrolytic capacitor is used for stabilizing the control power in the control circuit. Adverse effects from ripple currents deteriorate capacitors.
Page 632 7.1.7 Removal and reinstallation of the control circuit terminal block This product has a removable control circuit terminal block, which can be replaced with a new one or a control terminal option.  Removal and reinstallation Loosen the two installation screws at the both side of the control circuit terminal block. (These screws cannot be removed.) Slide down the control circuit terminal block to remove it.
Page 633 NOTE • Do not tilt the terminal block while tightening the screws or removing it from the inverter. (Otherwise, a stress applied to the control circuit terminal block or the control circuit connector may cause damage to them.) • After replacing the control terminal block, connect the jumper connector to the correct position in accordance with the control logic of input signals.
Page 634  Measuring points and instruments Item Measuring point Measuring instrument Remarks (reference measured value) Between R/L1 and S/L2, Input voltage Commercial power supply. Within permissible AC S/L2 and T/L3, or T/L3 and voltage fluctuation. (Refer to page 638.) R/L1 Input current Line current at R/L1, S/L2, Digital power meter (designed for and T/L3...
Page 635 7.2.1 Measurement of powers Use digital power meters (for inverter) both on the inverter's input and output sides. 7.2.2 Measurement of voltages  Inverter input side Use digital power meters (for inverters) for the input side voltage.  Inverter output side When using a measuring instrument, use a digital power meter for inverters as the inverter outputs PWM-controlled square wave voltage.
Page 636 7.2.7 Insulation resistance test using megger • For the inverter, conduct the insulation resistance test on the main circuit only as follows and do not perform the test on the control circuit. (Use a 500 VDC megger.) NOTE • Before performing the insulation resistance test on the external circuit, disconnect the cables from all terminals of the inverter so that the test voltage is not applied to the inverter.
Page 637 MEMO 7. PRECAUTIONS FOR MAINTENANCE AND INSPECTION 7.2 Measurement of main circuit voltages, currents, and powers Downloaded from ManualsNet.com search engine...
Page 638 CHAPTER 8 SPECIFICATIONS Inverter rating................................638 Motor rating................................641 Common specifications............................646 Outline dimension drawings..........................648 Downloaded from ManualsNet.com search engine...
Page 639 15.5 15.5 The applicable motor capacity indicated is the maximum capacity applicable for use of the Mitsubishi Electric standard 4-pole motor. The rated output capacity is the value with respect to 220 V output voltage. The percentage of the overload current rating is the ratio of the overload current to the inverter's rated output current. For repeated duty, allow time for the inverter and motor to return to or below the temperatures under 100% load.
Page 640 Forced air Approx. mass (kg) The applicable motor capacity indicated is the maximum capacity applicable for use of the Mitsubishi Electric standard 4-pole motor. The rated output capacity is the value with respect to 440 V output voltage. The percentage of the overload current rating is the ratio of the overload current to the inverter's rated output current. For repeated duty, allow time for the inverter and motor to return to or below the temperatures under 100% load.
Page 641 The applicable motor capacity indicated is the maximum capacity applicable for use of the Mitsubishi Electric standard 4-pole motor. The rated output capacity is the value with respect to 440 V output voltage. The percentage of the overload current rating is the ratio of the overload current to the inverter's rated output current. For repeated duty, allow time for the inverter and motor to return to or below the temperatures under 100% load.
Page 642 Motor rating 8.2.1 Premium high-efficiency IPM motor [MM-EFS (1500 r/min specification)]  Motor specifications 200 V class MM-EFS[]1M(-S10) Motor model 400 V class MM-EFS[]1M4(-S10) 200 V class 00046 00077 00105 00167 00250 00340 00490 00630 00770 00930 01250 01540 01870 02330 FR-F820-[] (0.75K)
Page 643  Motor torque characteristic The torque characteristics of the premium high-efficiency IPM motor MM-EFS (1500 r/min) series driven by the inverter are shown in graph form as follows. Short time(60s) maximum torque 83.3% (100% reference torque at 1800 r/min rating) 66.7% Continuous operation torque...
Page 644 8.2.2 Premium high-efficiency IPM motor [MM-EFS (3000 r/min specification)]  Motor specifications 200 V class MM-EFS[]3 Motor model 400 V class MM-EFS[]34 200 V class 00046 00077 00105 00167 00250 00340 00490 00630 FR-F820-[] (0.75K) (1.5K) (2.2K) (3.7K) (5.5K) (7.5K) (11K) (15K) Compatible...
Page 645 NOTE • The torque characteristic is when the armature winding temperature is 20°C, and the input voltage to the inverter is 200 VAC or 400 VAC. • Constant-speed operation cannot be performed for the speed of 300 r/min or less. •...
Page 646 NOTE • The motor can also be used for applications which require the rated speed of 1800 r/min. • The torque characteristic is when the armature winding temperature is 20°C, and the input voltage to the inverter is 200 VAC or 400 VAC.
Page 647 Common specifications Soft-PWM control / high carrier frequency PWM control (selectable among V/F control (Optimum Control method or function excitation control), Advanced magnetic flux vector control (Advanced optimum excitation control), and PM motor control) Output frequency range 0.2 to 590 Hz (400 Hz or less under Advanced magnetic flux vector control and PM motor control.) 0.015 Hz/60 Hz at 0 to 10 V/12 bits (terminals 2 and 4) 0.03 Hz/60 Hz at 0 to 5 V/11 bits or 0 to 20 mA/approx.
Page 648 Pulse train Max. 2.4 kHz via one terminal (for the indication of inverter output frequency). output (FM The item for monitoring can be changed using Pr.54 FM/CA terminal function selection. type inverter) Current output Max. 20 mADC via one terminal (for the indication of inverter output frequency). indication (CA type on external...
Page 649 Outline dimension drawings 8.4.1 Inverter outline dimension drawings FR-F820-00046(0.75K), FR-F820-00077(1.5K) 2×I6 hole Inverter model FR-F820-00046(0.75K) FR-F820-00077(1.5K) (Unit: mm) 8. SPECIFICATIONS 8.4 Outline dimension drawings Downloaded from ManualsNet.com search engine...
Page 650 FR-F820-00105(2.2K), 00167(3.7K), 00250(5.5K) FR-F840-00023(0.75K), 00038(1.5K), 00052(2.2K), 00083(3.7K), 00126(5.5K) 2×I6 hole 12.5 FR-F840-00023(0.75K) to 00052(2.2K) are not provided with a cooling fan. (Unit: mm) 8. SPECIFICATIONS 8.4 Outline dimension drawings Downloaded from ManualsNet.com search engine...
Page 651 FR-F820-00340(7.5K), 00490(11K), 00630(15K) FR-F840-00170(7.5K), 00250(11K), 00310(15K), 00380(18.5K) 2×I6 hole 12.5 Inverter model FR-F820-00340(7.5K), 00490(11K) FR-F840-00170(7.5K), 00250(11K) FR-F820-00630(15K) 101.5 FR-F840-00310(15K), 00380(18.5K) (Unit: mm) 8. SPECIFICATIONS 8.4 Outline dimension drawings Downloaded from ManualsNet.com search engine...
Page 652 FR-F820-00770(18.5K), 00930(22K), 01250(30K) FR-F840-00470(22K), 00620(30K) 2×I10 hole (Unit: mm) 8. SPECIFICATIONS 8.4 Outline dimension drawings Downloaded from ManualsNet.com search engine...
Page 653 FR-F820-01540(37K) FR-F840-00770(37K) 4×I20 hole for hanging 17 2×I10 hole (Unit: mm) 8. SPECIFICATIONS 8.4 Outline dimension drawings Downloaded from ManualsNet.com search engine...
Page 654 FR-F820-01870(45K), 02330(55K), 03160(75K), 03800(90K), 04750(110K) FR-F840-00930(45K), 01160(55K), 01800(75K), 02160(90K), 02600(110K), 03250(132K), 03610(160K) 2×I12 hole 4×Id hole Inverter model FR-F820-01870(45K), 02330(55K) FR-F840-00930(45K), 01160(55K), 01800(75K) FR-F820-03160(75K) FR-F820-03800(90K) , 04750(110K) FR-F840-02160(90K) , 02600(110K) FR-F840-03250(132K) , 03610(160K) Always connect a DC reactor (FR-HEL), which is available as an option. (Unit: mm) 8.
Page 655 FR-F840-04320(185K), 04810(220K) 4×I16 hole 3×I12 hole Always connect a DC reactor (FR-HEL), which is available as an option. (Unit: mm) 8. SPECIFICATIONS 8.4 Outline dimension drawings Downloaded from ManualsNet.com search engine...
Page 656 FR-F840-05470(250K), 06100(280K), 06830(315K) 3×I12 hole 4×I16 hole Always connect a DC reactor (FR-HEL), which is available as an option. (Unit: mm) Operation panel (FR-DU08, FR-LU08) Outline drawing Panel cutting dimension drawing 120 or more Panel 3.2max 27.8 Operation panel Parameter unit connection cable Air- (FR-CB2[ ])
Page 657 8.4.2 Dedicated motor outline dimension drawings  Premium high-efficiency IPM motor [MM-EFS (1500 r/min specification)] • 30K or lower Sliding distance Frame leg viewed from underneath Cross section C-C Outline dimension (mm) Output Frame Model (kW) number KA KD KG KL Q QK 7 0.75 162 62.5 50...
Page 658 NOTE • The drawings shown above are sample outline dimension drawings. The outer appearance may differ depending on the frame number.  Premium high-efficiency IPM motor [MM-EFS (3000 r/min specification)] Sliding distance Frame leg viewed from underneath Cross section C-C Outline dimension (mm) Output Frame...
Page 659 • 90 kW (KA) 4×IZ hole HOLES Outline dimension (mm) Frame number 250MD 545.5 317 250 535 203 174.5 30 712 100 157.5 603 130 168 50 1028 486 449 24 168 140 110 482.5 75m6 12 7.5 20 • 110 kW, 132 kW, 160 kW (KA) 4×IZ hole HOLES...
Page 660 CHAPTER 9 APPENDIX For customers replacing the conventional model with this inverter ..............660 International standards ............................661 Acquisition of type certification for ship classification standards (400 V class) ............662 Specification comparison between PM motor control and induction motor control ..........666 Parameters (functions) and instruction codes under different control methods............668 For customers using communication options manufactured by HMS..............685 Ready bit status selection (Pr.349, N240) ......................689 Downloaded from...
Page 661 APPENDIX APPENDIX provides the reference information for use of this product. Refer to APPENDIX as required. For customers replacing the conventional model with this inverter 9.1.1 Replacement of the FR-F700(P) series  Differences and compatibility with the FR-F700(P) series Item FR-F700(P) FR-F800 V/F control...
Page 662 • Parameter copy/verification function are not available.  Copying parameter settings • The FR-F700(P) series' parameter setting can be easily copied to the FR-F800 series by using the setup software (FR Configurator2). (Not supported by the setup software FR-SW3-SETUP or older.) 9.1.2...
Page 663 Acquisition of type certification for ship classification standards (400 V class) 9.3.1 Applicable models Structure/functionality Applicable inverter Standard model FR-F840-00023(0.75K) to 06830(315K) FR-F842-07700(355K) to 12120(560K) Separated converter type FR-CC2-H355K to H630K IP55 compatible model FR-F846-00023(0.75K) to 03610(160K)-C2 FR-F846-00023(0.75K) to 03610(160K)-C3 inverters are not applicable. 9.3.2 Details of type certification for standard model / Separated converter type...
Page 664  Recommended EMC filter (manufactured by Soshin Electric Co., Ltd.) The following section shows the specifications of recommended EMC filters to be used in combination with inverters.  Standard model Noise filter model Inverter model FR-F840-[] 00023(0.75K) 00038(1.5K) HF3010C-SZA 00052(2.2K) 00083(3.7K) HF3020C-SZA 00126(5.5K)
Page 665  Appearance examples and outline dimensions HF3300C-SJB HF3000C-SZA(10A-30A) HF3600C-SJB Noise filter model HF3010C-SZA HF3020C-SZA HF3030C-SZA HF3040C-SZA HF3050C-SZA HF3060C-SZA HF3080C-SZA HF3100C-SZA HF3150C-SZA HF3200C-SZA HF3250C-SZA HF3300C-SJB HF3600C-SJB HF31000C-SJB HF31200C-SJB HF31600C-SJB (Unit: mm) For details on this filter, contact Soshin Electric Co., Ltd. 9.3.3 Details of type certification for IP55 compatible model...
Page 666 • When the inverter is used in an environment with the surrounding air temperature exceeding 40°C, the rated output current must not exceed the value shown in the following table. Rated output current Inverter model Surrounding air Surrounding air FR-F846-[]-C2 temperature: 45°C temperature: 50°C 00023(0.75K)
Page 667 9.3.4 Wiring for compliance with EMC standards • When a power supply is provided for the control circuit separately from the main circuit and a capacitive device (such as an EMC filter or a radio noise filter) is connected, connect a noise filter (example: RTMN5006 manufactured by TDK- Lambda Corporation) to the control circuit power supply.
Page 668 Item PM motor control Induction motor control MM-EFS (1500 r/min specification) 15 kW or lower and MM-THE4: 0.018 Hz Terminals 2 and 4 MM-EFS (1500 r/min specification) 18.5 kW or 0.015 Hz (60 Hz rating) (0 to 10 V / 12 bits) higher : 0.025 Hz MM-EFS (3000 r/min specification): 0.036 Hz...
Page 669 Parameters (functions) and instruction codes under different control methods Instruction codes are used to read and write parameters in accordance with the Mitsubishi inverter protocol of RS-485 communication. (For RS- 485 communication, refer to page 505.) Function availability under each control method is shown as follows: ○: Available ×: Not available For Parameter copy, Parameter clear, and All parameter clear, ○...
Page 670 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Frequency jump 1B ○ ○ ○ ○ ○ ○ Frequency jump 2A ○ ○ ○ ○ ○ ○ Frequency jump 2B ○ ○...
Page 671 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Motor constant (R2) × ○ × ○ × ○ Motor constant (L1)/d-axis × ○ ○ ○ × ○ inductance (Ld) Motor constant (L2)/q-axis ×...
Page 672 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Acceleration/deceleration time ○ ○ ○ ○ ○ ○ switching frequency Stall prevention level at 0 V input ○ ○ × ○ ○ ○...
Page 673 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Multi-speed setting (speed 8) ○ ○ ○ ○ ○ ○ Multi-speed setting (speed 9) ○ ○ ○ ○ ○ ○ Multi-speed setting (speed 10) ○...
Page 674 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear ○ ○ ○ ○ ○ ○ BIN input bias ○ ○ ○ ○ ○ ○ BIN input gain Digital input and analog input compensation enable/disable ○...
Page 675 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Communication reset selection/ Ready bit status selection/Reset selection after inverter faults are ○ ○ ○ ○ ○ ○ cleared/DriveControl writing restriction selection Overspeed detection level ×...
Page 676 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Communication error occurrence count ○ ○ ○ × ○ ○ display Stop mode selection at ○ ○ ○ ○ ○ ○ communication error Maintenance timer 1 ○...
Page 677 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Output interruption cancel level ○ ○ ○ ○ ○ ○ Auxiliary motor operation selection ○ ○ ○ ○ ○ ○ Motor connection function selection ○...
Page 678 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Increased magnetic excitation ○ ○ × ○ ○ ○ current level Control circuit temperature signal ○ ○ ○ ○ ○ ○ output level Regeneration avoidance frequency ○...
Page 679 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Second PID action selection ○ ○ ○ ○ ○ ○ Second PID control automatic ○ ○ ○ ○ ○ ○ switchover frequency Second PID action set point ○...
Page 680 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Terminal 1 function assignment ○ ○ ○ ○ × ○ Current output filter ○ ○ ○ ○ ○ ○ Speed detection hysteresis ○...
Page 681 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear Terminal 1 bias command (torque) × × ○ ○ × ○ (919) Terminal 1 bias (torque) × × ○ ○ × ○ (919) Terminal 1 gain command (torque) ×...
Page 682 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear 1025 Trigger mode selection ○ ○ ○ ○ ○ ○ 1026 Number of sampling before trigger ○ ○ ○ ○ ○ ○ 1027 Analog source selection (1ch) ○...
Page 683 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear 1155 User parameter 6 ○ ○ ○ ○ ○ ○ 1156 User parameter 7 ○ ○ ○ ○ ○ ○ 1157 User parameter 8 ○...
Page 684 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear PID lower limit operation detection 1346 ○ ○ ○ ○ ○ ○ time 1361 Detection time for PID output hold ○ ○ ○...
Page 685 Instruction code Control method Parameter Name Read Write Extended Copy Clear Magnetic flux Magnetic flux Magnetic flux clear 1464 PID multistage set point 5 ○ ○ ○ ○ ○ ○ 1465 PID multistage set point 6 ○ ○ ○ ○ ○...
Page 686 For customers using communication options manufactured by HMS  List of inverter monitor items / command items The following items can be set using a communication option. 16-bit data Description Unit Type Read/ write H0000 No data H0001 Output frequency 0.01 Hz unsigned H0002...
Page 687 Description Unit Type Read/ write H003C Option output terminal status H003D Motor thermal load factor 0.1% unsigned H003E Transistor thermal load factor 0.1% unsigned H003F reserved H0040 PTC thermistor resistance unsigned H0041 Output power (with regenerative display) 0.1 kW unsigned H0042 Cumulative regenerative power 1 kWh...
Page 688  Waiting time for the communication line error output after a communication error Waiting time for the communication error output after a communication line error occurrence can be set. Minimum setting Name Setting range Initial value increments Communication error 0 to 999.8 s 0.1s execution waiting time Normal...
Page 689  Error reset and Ready bit status selection • An error reset command from a communication option can be invalidated in the External operation mode or the PU operation mode. • The status of Ready bit is selectable. Name Initial value Setting range Description Communication reset selection/...
Page 690 Ready bit status selection (Pr.349, N240)  To select the error reset operation at inverter failure • The status of Ready bit in communication data can be selected when a communication option (FR-A8ND, FR-A8NF, or FR-A8NL) is installed. • An error reset command from a communication option can be invalidated in the External operation mode or the PU operation mode.
Page 691 • FR-A8NF Inverter status monitor Name Description Pr.349 = "0, 1" 0: During an inverter reset / during startup after power-ON. N240 = "0" 1: During normal operation READY Reset cancel signal Pr.349 = "100, 101" 0: RY signal is OFF N240 = "1"...
Page 692 MEMO 9. APPENDIX 9.7 Ready bit status selection (Pr.349, N240) Downloaded from ManualsNet.com search engine...
Page 693 REVISIONS *The manual number is given on the bottom left of the back cover. Revision date Manual number Revision Jul. 2014 IB(NA)-0600547ENG-A First edition Aug. 2015 IB(NA)-0600547ENG-B Added • Setting values "7, 14, and 17" of Pr.554 PID signal operation selection •...
Page 694 FR-F800 Model Instruction Manual (Detailed) Model code 1A2-P82 HEAD OFFICE: TOKYO BUILDING 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN IB(NA)-0600547ENG-F(2111)MEE Printed in Japan Specifications subject to change without notice.

This manual is also suitable for:

Fr-f820-00046 Fr-f820-04750 Fr-f840-00023 Fr-f840-06830 Fr-f842-07700 Fr-f842-12120 ... Show all

Mitsubishi Electric FR-F800 Series Instruction Manual

Quick Links

Chapters

Related Manuals for Mitsubishi Electric FR-F800 Series

Summary of Contents for Mitsubishi Electric FR-F800 Series

This manual is also suitable for:
