Power on job: Here you can also choose which job will be loaded when the Vision Sensor is switched on.
This job is then marked with this symbol.
When jobs are switched by the binary method via the digital inputs, no job is active when the device is
switched on. In this case, the desired job is selected using the levels present at the inputs.
Save after job selection: Activate this function if you would like the most recently active job to be activated
the next time the device is started.
Transfer the jobs using the horizontal arrows and move jobs to the corresponding storage locations in the
device with the vertical arrows. You can also use the bottom button to enter the target position for the job
directly.
Use the cross to delete jobs.
