15.5.2.3 Group: Result data

This group is used to transfer the result data from job processing. The results datagram is configured during
job creation in the Application Suite in the step Configure interfaces → Output process interface.
Variants are available with payload capacities of 4/8/16/32/64/128/256/512 bytes. You should choose the
smallest possible variants for the volume of data you expect to handle. An unnecessarily large selection
reduces overall system performance.
The data corresponds to response to the "GD" command from the classic process interface.
Data element Direction
Device
Actual length of
PLC
the result data
Device
Result data
PLC
(<n> byte)
v2.8.2-K11
Type Length
(byte)
UINT16 2
OCTET- 4/8/16/32/64/128/256/512
STRING
302/332
Technical Documentation
Description
Length of data actually used in
ResultData
Result data for job processing (data
length corresponds with the selected
module)
