15.3.1.4 Composite data type: Integer point

This composite data type is formed of two integer values, the x-coordinate and the y-coordinate.
Available format: Analogue integer
Portrayal: x coordinate <separator> y coordinate
Example: Value: (234, 123), Separator: „;"
Format
ASCII hex
ASCII dec
Binary

15.3.1.5 Composite data type: Float point

This composite data type is formed of two float values, the x-coordinate and y-coordinate.
Available format: Analogue float
Portrayal: x coordinate <separator> y coordinate
Example: Value: (234.02, 123.03), Separator: „;"
Format
ASCII (2 decimal
places)
ASCII (Exponent)
Decimal
Binary (Little Endian)
Binary (Big Endian)
v2.8.2-K11
Text representation
"EA;7B"
„234;123"
cannot be represented
Text representation
„234.02;123.03"
"+2.3402E+02;1.2303E+02" \2B \31 \30 \30 \32 \45 \2B \30 \30 \31
„234;123"
cannot be represented
cannot be represented
Transferred value (process interface)
\45 \41 \3B \37 \42
\32 \33 \34 \3B \31 \32 \33
\00 \ 00 \00 \EA \3B \00 \ 00 \00 \7B
Transferred value (process interface)
\32 \33 \34 \2E \30 \32 \3B \31 \32 \33 \2E
\30 \33
\31 \30
\1F \05 \6A \43 \3B \5C \0F \F6 \42
\43 \6A \05 \1F \3B \42 \F6 \0F \5C
