15.5.2.4 Group: Parameters

This group is used to transfer parameter data for the current job. It is configured during job creation in the
Application Suite in the step Configure interfaces → Input process interface.
Depending on the protocol variants are available with payload capacities of 4/8/16/32/64/128/256/512 bytes.
You should choose the smallest possible variants for the volume of data you expect to handle. An
unnecessarily large selection reduces overall system performance.
The data corresponds with the "SP" command in the classic process interface.
Data element Direction
PLC
Actual length of
the parameters
PLC
Parameter (<n>
byte)
v2.8.2-K11
Type Length
(byte)
device
UINT16 2
device
OCTET- 4/8/16/3
STRING 2/64/128
/256/512
Description
Length of data actually used in ParamData
Parameter data for the current job
