ipf electronic opti-check Technical Documentation Manual page 288

Example 2 (overlapped, clocked processing)
The command comes after the second trigger → all processes up to trigger 1 and trigger 2 are completed,
SP/TE become effective after result 2.
1 SP / TE command
2
Trigger permitted
3 Trigger
4 Image acquisition
5 Image processing
6
Result
7 Value stored < 1 ms
