13.6.1 Binary job selection

For the device a maximum of four digital inputs are available for job selection.
It is possible to quickly switch between jobs 1 to 16 in this way.
The allocation of the levels to the selected job is as follows:
Binary job
selection - Bit
0
Job 1 Low
Job 2 High
Job 3 Low
Job 4 High
Job 5 Low
Job 6 High
Job 7 Low
Job 8 High
Job 16 High
NOTE
Please observe that this table relates to the configuration of the inputs as "active high". If
you have configured an input as "active low", you must invert the specified levels for this
input in the overview.
v2.8.2-K11
Binary job Binary job
selection - Bit selection - Bit
1 2
Low Low
Low Low
High Low
High Low
Low High
Low High
High High
High High
...
High High
234/332
Technical Documentation
Binary job
selection - Bit
3
Low
Low
Low
Low
Low
Low
Low
Low
High
