15.5.3.5 Depiction of the data elements on the PROFINET module

The following tables provide a brief overview of the arrangement of data elements in the individual modules.
15.5.3.5.1

Module: Control and status

Input data (device
Byte Data element
0 Handshake for
output data
1 Handshake for
input data
2 Device status
3 Current job number
4
5 Action status
6 Job results
7
8
9
10 Device alarms
11
12
13
Output data (PLC device)
Byte Data element
0 Handshake for
output data
1 Handshake for
input data
2 Device controller
3 Job selection
4 Reset statistics
5 Reset status
(actions)
