Cleaning - ipf electronic opti-check Technical Documentation Manual

16 Cleaning

Due to its compact design, the device is characterized by almost maintenance-free operation.
When used for the intended purpose, it is possible that the device may need to be cleaned from time to time.
Very clean optical surfaces (cover glass) are required for the consistent and reproducible operation of the
device.
For cleaning, use a soft, lint-free cloth to clean the surface of the cover glass with a gentle pressure, without
scratching.
To clean stubborn dirt, commonly available window cleaning agent is recommended.
ATTENTION!
Ensure that no residues of the cleaning agent or scratches remain on the glass. These
can permanently damage the reproducibility of the results from the device.
ATTENTION!
As so many cleaning agents are available, we hope you understand that we cannot test
every single one. Resistance to cleaning agents and areas of use depends upon the
specific application.
Cleaning agents must be tested on an discreet area of the device under application
conditions to evaluate if they are suitable.
Materials within the device with protection class IP 69K
Component, part
Housing
Seal (housing)
Seal bonding agent (primer)
Cover glass
Seal / adhesive (cover glass)
Seals (O-rings)
Press-fitted optical fibre
Sealing collar optical fibre
Screw cover (rear side)
Connector M12 / 12 pin
v2.8.2-K11
Material
Stainless steel 1.4404 (316L)
polymerized silicone rubber (CAF)
Silquest VS-142
(Silquest is a trademark of Momentive
Performance Materials Inc.)
PMMA
Silicone adhesive
Fluororubber (FPM)
Polycarbonate
Epoxy resin
Silicone
Stainless steel 1.4404 (316L)
319/332
Technical Documentation
opti-check
Classification
FDA, BfR
FDA, UL
FDA
FDA
FDA
ipf electronic GmbH
Lüdenscheid, Germany
