12 Feature checks

All feature checks are described below. Note that not all feature checks are supported by all devices.
You can find an overview as to which Vision Sensors check which features under: Technical Data (Overview
of feature checks).
NOTE
The Application Suite CD features a range of application examples that provide you with
typical solutions for various inspection task and for the use of the individual feature
checks. After successful installation, the examples can be found in the subdirectory:
<installation path>\AppSuite\Samples
on your PC.
NOTE
Jobs are compatible between devices if they work with at least the same feature checks
and identical functions for the same field of view.
Feature checks from the identification area are not compatible between those devices
with and without Industrial Ethernet. Part location on contours is supported as an older
version on devices with integrated Industrial Ethernet.
NOTE
Most feature checks support the Teach function. Initially thereby the contours / edges of
the sample piece will be learned or switching thresholds set absolutely or in percent (±
10%) to the actually determined value. A relative amendment will be retained if possible
when the switching thresholds are altered manually.
The corresponding expected values will be imported during Teach in the case of
identification feature checks.
v2.8.2-K11
126/332
Technical Documentation
opti-check
ipf electronic GmbH
Lüdenscheid, Germany
