15.5 Process interface via Industrial Ethernet (device dependant)

It is possible to communicate with the Vision Sensor via various Industrial Ethernet protocols, such as
PROFINET using a PLC.

15.5.1 Mode of operation

The data transfer protocol is determined by the Industrial Ethernet specification.
The following data can be transmitted:
- General control and status data (triggers, pass / fail, active job, etc.)
- Result data (configuration in the case of job creation via the Output process interface)
- Job parameters (configuration in the case of job creation via the Input process interface)
- Additional trigger data
The data will be combined into logical groups. Data transmission of each group can be secured with a
handshake.
Mapping of the data in the PLC must be planned using the manufacturer-specific tool.
Undertake Configuration of the protocol to be used using the Application Suite. You can find the settings
options under: Device → Device settings → Process interface.
