Offset and rotation

Offset only

Confirm your settings and return to the feature list with OK. Return to the feature list without making
any changes with Cancel.
This feature check has the following output values for the datagram at the process interface:
Output value
Result
Conformity
Text position
Text angle
v2.8.2-K11
Data type
Integer
Float point
Float
Description
Result of the feature check: "P" (Pass); "F" (Fail)
Match between the current object and the taught-
in model (%)
X – Separator – Y
