9.4 Device activation
Click on Activate device.
Confirm the question with Yes.
The Vision Sensor is now in Activated mode and processes the created job. The Statistics / Details are
shown on the right of the parametrization area.
NOTE
While the Vision Sensor is processing the job, you may continue to retrieve defect images
and to save images.
There is also the option to save the current job and all jobs to the PC via the Job menu
Click on Switch job..., to change to
a different job stored in the Vision
Sensor.
Click on Reset statistics to reset
the statistics values (number of
parts, number OK, NOK, number
of alarms).
v2.8.2-K11
Click on Configure Device to
return to Configuration mode and
to make new settings.
70/332
Technical Documentation
Click on Delete defect images to
delete stored defect images
(button only appears when you
click on Defect images in the
display options).
